4. Part Data Settings QD004-18 142 NXT Programming Manual Note: The p pattern is automatically converted if the old vision type is in the “generic” section. Note: The shaded areas represent the vision ty pes for which au…
QD004-18 4. Part Data Settings
NXT Programming Manual 141
4.7.2 Vision type compatibility table for the NXT
Vision Types New P Pattern Part Type Notes
Old NXT
10 60 Rectangular chips Select an appropriate vision type
based on part shape.
Override required (Note 1)
65 Aluminum electrolytic capacitors
180 Tantalum capacitors
123/124/
144
Leaded parts
11 61 Tantalum spragues
12 62 Resistor networks, MELFs
13 63 Tantalum spragues
(Polarity check performed)
20 180 (Old P Pattern) +1* Tantalum capacitors, SOTs Select an appropriate vision type
based on part shape.
Override input required (Note 2)
75 (Old P Pattern) +1* Power transistors
21 71 Trimmer resistors/trimmer capacitors
22 72 (Old P Pattern) +1* HEMT (0 degree)
23 73 (Old P Pattern) +1* HEMT (supplied at 45 degrees)
24 74 (Old P Pattern) +1* Trimmer resistors/trimmer capacitors
(Polarity check performed)
30 80 Round shaped parts
40 160 (Old P Pattern) +1* White body detection Select an appropriate vision type
based on part shape.
Override required (Note 3)
60/123/
124/152/
153/180/
252
(Old P Pattern) +1* Leaded part / part outline
100 (105) 123 (128) (Old P Pattern) +1* IC-type leaded parts
120 (125) 124 (129) 24->4, 34->14*
(Conversion not required for
others)
J-leaded parts
121 (126) 124 (129) As above J-leaded parts
122 (127) 124 (129) As above J-leaded parts
123 (128) 123 (128) As above IC-leaded parts
124 (129) 124 (129) As above J-leaded parts
130 (135) 230 (235) Conversion not required Black bodied BGA
131 (136) 231 (236) As above White bodied BGA
140 (145) 140 (145) As above Flip-chips
142 (147) - Black bodied irregular bump parts
143 (148) CCGA
144 (149) LGA
150 (155)
152 (Old P Pattern) +1* Black bodied connector Select an appropriate vision type
based on part color and image
quality. Override required (Note 4)
153 (Old P Pattern) +1* White bodied connector
4. Part Data Settings QD004-18
142 NXT Programming Manual
Note: The p pattern is automatically converted if the old vision type is in the “generic” section.
Note: The shaded areas represent the vision types for which automatic conversion is not
supported by the NXT machines. All other vision types are supported and therefore require
no additional data entry.
Note 1
Previously, it was possible to perform vision processing for all rectangular chips using vision
type 10, however, when using frontlighting, due to the influence of leads and so forth on the
body of the part, it is necessary to separate those parts previously supported by vision type
10 into four types as detailed in the table below.
151 (156) 151 (156) Conversion not required Mechanical chuck connectors
152 (157) 152 (157) As above Black bodied connector
153 (158) 153 (158) As above White bodied connector
160 (165) 160 (165) As above White bodied connector detection
170 170 As above Mechanical chuck part presence
check
180 (185) 180 (185) Conversion not required Tantalum capacitors, SOTs
181 Coil parts 2 leads at 45 degrees angles
230 (235) 230 (235) Conversion not required Black BGA
231 (236) 231 (236) As above White BGAs
232 (237) 230 (235) As above TBGA
233 (238) 233 (238) As above Black CSPs
234 (239) 234 (239) As above White CSPs
240 240 VPDplus (MPA) NXT V3.0 and higher
249 252 Diagonal cut shield parts No longer used. Certain parts
supported by 252.
252 252 Multi-purpose vision type (part
outline)
254 252 Odd-form parts Select an appropriate vision type
based on part shape.
Override required (Note 5)
Vision Types New P Pattern Part Type Notes
Old NXT
Vision type
for existing
machines
Vision type
for NXT
Part type Explanation
10 60 Rectangular chips Automatically converted to 60 if
no vision type value is specified
in the NXT override section
65 Aluminum electrolytic
capacitors
Element data not required
180 Tantalum capacitors Element data reguired
(*1) Leaded parts Element data required
QD004-18 4. Part Data Settings
NXT Programming Manual 143
*1: There are cases in which none of the vision types in the above table are applicable.
Some examples of such parts are rectangular parts other than rectangular chips, tantalum
capacitors, or aluminum electrolytic capacitors with multiple leads inside the edge of the
part body. In this case, select an appropriate vision type from 123, 124, 144, or 180 and
enter element information for the leads based on the shape of the part.
Note: Vision type 10 is automatically converted to 60, however, if another value has been
specified in the override vision type value for the NXT, this value will be used.
Note: Refer to Åu4.6.2NXT vision typesÅv for details on how to create lead data.
Note 2
Vision type 20 is used on existing machines to process SOT-type parts with few leads,
however, on the NXT machines, vision type 180 is used. A custom vision type is used for
power transistors.
Note: Vision type 20 is automatically converted to 180, however, if another value has been
specified in the override vision type value for the NXT, this value will be used.
Vision type
for existing
machines
Vision type
for NXT
Part type Explanation
20 180 Tantalum capacitors,
SOTs
Automatically converted to 180 if
no vision type value has been
specified in the NXT override
section.
75 Power transistors P_pattern automatically
converted
