QD004-18 3. Job Builder
NXT Programming Manual 11
8. Add a line to the job.
9. Enter the machine configuration and process data. (NXT)
10.Enter auto backup pin data. (NXT, only for equipped machines)
11.Panelize the panel (Panel Management).
12.Line balance the work load. (NXT)
13.Optimize the job. (NXT)
14.Generate reports. (NXT)
3.2.13 Starting by importing PanaCAD data
Follow the roadmap below to create a basic job by importing PanaCAD data. Generating
recipes is not necessary for the NXT unless one wants to view reports.
1. Create a job manually.
2. Import the PanaCAD data.
3. Import the BOM file.
4. Import any existing part data into the job.
5. Create any missing part data. (NXT)
6. Import mark data into the job.
7. Add a line to the job.
8. Enter the machine configuration and process data. (NXT)
9. Enter auto backup pin data. (NXT, only for equipped machines)
10.Panelize the panel (Panel Management).
11.Line balance the work load. (NXT)
12.Optimize the job. (NXT)
13.Generate reports. (NXT)
3. Job Builder QD004-18
12 NXT Programming Manual
3.3 NXT Job Settings
3.3.1 Changing the current line to a NXT line
It is easy to change any current line in a job to a new line. This step is required when making
jobs for the NXT by importing CCIMF or MCSIMF files into a job in Flexa or when changing
an existing job for other machines to a job for the NXT.
When adding the line, a line that has been previously setup for transmission is used. This
makes adding lines easier and more error free, because the basic NXT data already exists
and the NXT in the job will match the NXT for transmission. If the NXT lines have not been
setup for transmission, then this must be done before adding an NXT line to the job is
possible.
Changing the line for the top side of the panel.
1. Select the [Top] tab from the job information bar.
2. Right-click in the data area for [Top] and select [Select line…] from the shortcut menu.
The [Select Line] dialog box displays.
3. Select the factory for the desired line and select the desired NXT line from the list that
displays and click [OK]. The dialog box closes and the machines from the selected line
are added to the job.
Note: If there are no other Fuji machines in the line, then there most likely will only be one NXT
machine. For further details, refer to the chapter about setting up an NXT line in the NXT
Setup Manual.
When the line is added, the default machine data for each machine is also brought into the
job.
Changing the line for the bottom side of the panel.
1. Select [Flip Panel] from the [View] menu and then select the [Bottom] tab from the job
information bar.
2. Right-click in the data area for [Bottom] and select [Select line…] from the shortcut
menu. The [Select Line] dialog box displays.
3. Select the factory for the desired line and select the desired line from the list that
displays and click [OK]. The dialog box closes and the machines from the selected line
are added to the job.
Note: If there are no other Fuji machines in the line, then there most likely will only be one NXT
machine. For further details, refer to the chapter about setting up an NXT line in the NXT
Setup Manual.
When the line is added, the default machine data for each machine is also brought into the
job.
QD004-18 3. Job Builder
NXT Programming Manual 13
3.3.2 Adding an NXT line to a job
It is easy to add any current line to a job. This step is required with making new jobs for the
NXT.
When adding the line, a line that has been previously setup for transmission is used. This
makes adding lines easier and more error free, because the basic NXT data already exists
and the NXT in the job will match the NXT for transmission. If the NXT lines have not been
setup for transmission, then this must be done before adding an NXT line to the job is
possible.
Adding the NXT line for the top side of the panel.
1. Select the [Top] tab from the job information bar.
2. Right-click in the data area for [Top] and select [Select line…] from the shortcut menu.
The [Select Line] dialog box displays.
3. Select the factory for the desired line and select the desired NXT line from the list that
displays and click [OK]. The dialog box closes and the machines from the selected line
are added to the job.
Note: If there are no other Fuji machines in the line, then there most likely will only be one NXT
machine. For further details, refer to the chapter about setting up an NXT line in the NXT
Setup Manual.
When the line is added, the default machine data for each machine is also brought into the
job.
Adding the NXT line for the bottom side of the panel.
1. Select [Flip Panel] from the [View] menu and then select the [Bottom] tab from the job
information bar.
2. Right-click in the data area for [Bottom] and select [Select line…] from the shortcut
menu. The [Select Line] dialog box displays.
3. Select the factory for the desired line and select the desired line from the list that
displays and click [OK]. The dialog box closes and the machines from the selected line
are added to the job.
Note: If there are no other Fuji machines in the line, then there most likely will only be one NXT
machine. For further details, refer to the chapter about setting up an NXT line in the NXT
Setup Manual.
When the line is added, the default machine data for each machine is also brought into the
job.
