5. Transmission QD004-18
150 NXT Programming Manual
6. Select the side of the panel to transmit using the [Panel Side] drop-down list.
7. Click [Set] to set the specified lane, job and side. The settings are displayed in the [JOB]
list.
8. Repeat setting the jobs for the different lanes until all jobs for the lanes have been
specified.
9. Select the line to transmit to from the [Line] drop-down list. The machines for that
specified line are displayed.
10.Select the machines to transmit to. The machines with a red X across the panel icon
cannot be selected.
11.After selecting the target machines for transmission, select any desired options from the
bottom of the dialog box.
12.Click [Send] to start transmitting the jobs to the specified lanes.
Note: Transmission is not possible to machines that have an error code number listed in the [Error
details] column. Select the machine in question and click the [Error details] button to display
the cause and remedy for the error.
Note: The NXT machine cannot be selected if the module configuration specified in Line Editor
does not match that specified in the job.
13.During transmission, the [Transmission Status] dialog box displays. This dialog box
displays the job and machines. The transmission status is displayed to the right of the
machine nickname. If any errors occur, click [Error Details] to display further information
about the errors. Click [Close] to close the dialog box when transmission is completed.
Note: The job name displays in the list of programs at the machine with the job name and a T for
the top side and B for the bottom side and the revision displays before these items.
QD004-18 5. Transmission
NXT Programming Manual 151
5.3 General Procedures
5.3.1 Changing the current job
The current job is the job that is used when production is started. The other job for the
selected lane is considered to be the next job. Follow the procedures below to change the
next job into the current job, however the machine must be at the main page for this
operation to be successful. If any other page is selected, then an error occurs when
performing the following procedures. The job can also be switched at the modules.
1. Double-click the factory folder from [Transmission Control] to display the target line, and
then double-click the line to display the machines in that line.
2. Double-click the machine name to display the lanes for that machine.
3. Double-click the lane for which to change the job and the current job and next job display
in a list.
4. Right-click the job name to be changed and select [Switch Recipe] from the shortcut
menu.
5. A dialog box displays with the status of the change. Click [OK] to close the dialog box.
5.3.2 Deleting a job from a machine
1. Double-click the factory folder from [Transmission Control] to display the target line, and
then double-click the line to display the machines in that line.
2. Double-click the machine name to display the lanes for that machine.
3. Double-click the lane for which to delete the job and the current job and next job display
in a list.
4. Right-click the job to be deleted and select [Delete] from the shortcut menu.
5. A dialog box displays with the status of the command. Click [OK] to close the dialog box.
5. Transmission QD004-18
152 NXT Programming Manual
MEMO:
