QD004-18 5. Transmission NXT Programming Manual 147 5. Transmission 5.1 Introduction Transmission is used to send data between Fuji Flexa and the NXT machines. The most common use of Transmission is to send jobs to the m…
4. Part Data Settings QD004-18
146 NXT Programming Manual
MEMO:
QD004-18 5. Transmission
NXT Programming Manual 147
5. Transmission
5.1 Introduction
Transmission is used to send data between Fuji Flexa and the NXT machines. The most
common use of Transmission is to send jobs to the modules on the NXT. Transmission for
the NXT does not require outside communication programs such as an NTCC or SECS/
GEM host server. If transmitting from Job Builder, a basic data check of the job is
performed during transmission.
The NXT is different from previous Fuji machines in that the job is sent to the modules, not
recipes. In addition, there is only two positions for jobs, current job and next job. On NXT
machines with double conveyors, there is an additional set of separate positions for jobs for
the second lane. It is possible to run the machine with two different jobs, one for lane 1 and
the other for lane 2.
The NXT does not have any calibration data or spec data like previous Fuji machines.
Special NXT data and configuration settings is received, managed, and transmitted to the
machine through Accessory Software. Refer to the Accessory Software Operation Manual
for more details on this subject.
5. Transmission QD004-18
148 NXT Programming Manual
5.2 Transmitting
5.2.1 Transmitting a job from Job Builder
Follow the procedures below to transmit a currently opened global job to the NXT from
within Job Builder. Be sure to save the job before transmitting.
1. Select [Transmit] from the [Tools] menu.
Note: The currently opened job can only be transmitted to the line that is used in the job.
2. The [Transmit Options] dialog box displays. Select the desired options and click [OK].
3. Select the machine to which to transmit and click [Start].
4. In the [Lane Job Selection] dialog box, specify any changes you wish to make for the
jobs to send to the lanes and click [OK].
5. During transmission, the [Transmit] dialog box displays. This dialog box displays the
transmission status. If any errors occur, click [Error Details] to display further
information about the errors. Click [Close] to close the dialog box when transmission is
completed.
Note: The lane to which the job is transmitted is determined by the lane for which the job was
optimized for the NXT machine.
Note: The job name displays in the list of programs at the machine with the job name and a T for
the top side and B for the bottom side and the revision displays before these items.
5.2.2 Dragging and dropping jobs to transmit
Follow the procedures below to transmit a job to the NXT by dragging and dropping the job
in the Transmission Control view.
1. With the Transmission Control window displayed in Director, drag the desired job from
the global directory in the job pane and drop it on either the NXT line, machine, or lane
in the Factory/Line pane.
Note: If the job is dropped on a lane, then that line, machine, and lane are automatically selected
in the [Transmit Job] dialog box. If the job was just dropped on the NXT machine, then both
lanes for the NXT are automatically selected.
2. The [Transmit Job] dialog box displays. In [Job:], the selected job is automatically
selected. Select the side of the panel to transmit.
3. The line and machine that the job was dropped on is automatically selected. The
machines that can be transmitted to have a small panel icon to the left of the machine
nickname. The machines for which the job is not ready to be transmitted or jobs that are
from the local job directory have small panel icon with a red X across it.
Note: A job from the local job directory cannot be transmitted to any NXT machines. Only jobs
from the global job directory can be transmitted.
4. Select the lanes to which to send the job from the [Lane] drop-down list. If the job was
dropped on a lane, then that lane is automatically selected.
5. Select any desired options from the bottom of the dialog box and click [Send] to transmit.
