QD004-18 4. Part Data Settings
NXT Programming Manual 81
4.3.2 Shape Process tab
Section Name Comments Chg
Body Location Pin Length O
Part Pattern Tolerance X This is a VPDplus setting. X
Part Pattern Tolerance Y This is a VPDplus setting. X
Lead Check Point O
Quantity Check Limit O
Lead Brightness O
Process -
Nozzle
Minimum Diameter X
Maximum Diameter X
Name X
Load Check For NXT pressure control only O
Process -
Head
Target Heads For NXT only X
Process -
Pick
Do Auto Offset O
Offset X O
Offset Y O
Offset Q O
Offset Z O
Tray Pick Offset Z O
Soft Pick Speed O
Enable Pressure Sensor O
Do Prerotation NXT does not use this setting O
Do Prerotation for
Custom Nozzle
Custom and mechanical chucks only O
Do Part Height Check Used only with compatible heads O
Clamp Width For OF head O
Actual Pickup Body
Height
For OF head O
Clamp Margin For OF head O
Motor Gripping Force For OF head O
Process -
Pick -
Tolerance
Check
Tolerance X O
Tolerance Y O
Tolerance Q O
4. Part Data Settings QD004-18
82 NXT Programming Manual
Process -
Pick -
MTU
Shuttle Speed TU-LT has an extra setting O
Magazine Speed O
Process -
Place
Do Place Check Used only with compatible heads O
Offset X O
Offset Y O
Offset Z O
Pressure O
Transport Speed O
Transport Speed Z O
Transport Speed Q O
Soft Place Speed O
Place Motion Selection O
Placing Thrust Pressure O
Placement Wait Time O
Stack Placing Down
Speed
For PoP placement O
Stack Placing Up Speed For PoP placement O
Do Place Precision
Priority
For NXT only X
Process -
Error
Alt Feeder Trigger This setting is not used from the part
data. This setting for the NXT is set
through Accessory Software.
N/A
Dump Position O
Forcing Recovery Times
As 0
For NXT only O
Recovery Times O
Vision Vision Type Refer to Vision Type Details for details. O
Multi Camera X
Vision Height Offset For sidelight camera O
Vision Area Offset X For OF head X
Vision Area Offset Y For OF head X
Exposure Time
(VPDplus)
This is the VPDplus setting. X
Lighting Pattern
(VPDplus)
This is the VPDplus setting. X
Section Name Comments Chg
QD004-18 4. Part Data Settings
NXT Programming Manual 83
Settings that have blank comments have the same explanation and settings for multiple Fuji
machine types. Settings with the vision related comment affect the vision processing.
The settings for items with an O in the “Chg” column can be changed in MEdit. The settings
for items with an X in this column cannot be changed in MEdit. N/A means that this part
data setting is not set at the machine so any changes here are not reflected at the machine.
Pin Check Pin Check Mode X
Is Bottom Mark Present X
Is Bump Present X
Upper Left X X
Upper Left Y X
Lower Right X X
Lower Right Y X
Coplanarity Do Coplanarity Coplanarity check related setting. X
Coplanarity Editor Coplanarity check related setting. X
Flux Do Flux X
Dwell Time O
Slow Dipping Height O
Slow Dipping Down
Speed
O
Slow Dipping Up Speed O
Squeegee Height O
Do Dipping Check O
Solder
Paste
Do Check O
High Brightness O
Low Brightness O
Section Name Comments Chg
