Glossary QD004-18

200 NXT Programming Manual

centroid CAD

This is a text file that has the coordinates and reference designators for parts. Each line in

the file has data for one part only. Sometimes other data is present such as the part number

and panel side.

coordinate data

Data that displays in Job Builder, that has the position data and other necessary settings

for each part, mark, and glue dot.

current job

This is the job that is to be produced when START is pushed. This job is loaded in the

machine memory. There can be one current different job for each lane or the jobs for all

lanes can be the same.

Director

The Fuji Flexa component that is used for data management, transmission, and managing

factory lines and machines. In addition, this provides easy access to many of the other Fuji

Flexa components

dynamic alternate feeder

When using Fujitrac Verifier, it is possible to use alternate feeders without having to specify

a fixed position for them in the job. When using this function and a parts out warning is

issued, the operator prepares an extra feeder with a new reel of parts that are going to run

out, verifies it in Fujitrax and then sets the feeder in any open slot in the same module. The

machine checks what parts are on the feeder and then automatically changes the feeder

into an alternate feeder. When parts run out on the original slot, the machine will pick from

the alternate feeder.

element

A group of leads on the same side of a part that have the same length, width, and pitch.

fiducial mark

A mark that is used to adjust the positioning when parts are placed on a board. Fiducial

marks are printed onto the substrate together with the circuit pattern, thereby creating a

constant indicator of the pattern's present location. There are 3 types of fiducial marks: part

fiducials, board fiducials, and panel fiducials.

Fuji Flexa

This a production line host system for creating, editing, transmitting recipes to Fuji SMT

machines. In addition to the recipe management functions, the system is used for

monitoring the production status of the machines and managing machine specific data.

QD004-18 Glossary

NXT Programming Manual 201

global job

A job that is saved on the Fuji Flexa job server and is accessible to all users of that user

server

glue mark

These are for glue machines only. At the beginning of production, trial check glue dots can

be produced by the machine to ensure that the glue volume is correct. The data for glue

mark is used to check the size of the trial check glue dots. If the trial check glue dots are

not the correct size, the glue application air pressure is adjusted.

Icon Bar

By default, this displays to the left of the Director window below the toolbar. The icon bar

is divided into groups, each is opened by clicking the group name on the gray button. By

clicking an item in the icon bar, it is possible to change the Director display, perform an

action, or open a program

job

All the data that is required for the production of a single panel, stored in a single group.

Job Builder

The Fuji Flexa component that is used to create and edit jobs.

job information bar

By default, this is positioned at the left side of the Job Builder window. This organizes the

data in a job into an easy to use format. The information in the bar is split into groups:

General, Part Data, Mark Data, and Top (Bottom). If relational mode for part data is

enabled then the tabs, Shape Data and Package Data also display. Data within a tab is

arranged in a hierarchical format.

job server

This is a Fuji Flexa server ran on a computer and specifies the location of the global jobs

and manages access to those jobs. This server retrieves jobs for users and also locks jobs

so that no other user can alter a job while it is opened by the first user.

line balance

A process whereby tasks are distributed among the machines on a production line. This is

performed to attempt to make the working time for each machine on the line to be as close

to each other as possible.

line configuration

Data describing the types of machines that make up lines and their special settings. This

Glossary QD004-18

202 NXT Programming Manual

also describes all of the lines for the factories and their order.

Line Editor

The Fuji Flexa component used to create and edit the line configuration.

Line Monitor

The Fuji Flexa component used to monitor the real time production performance of entire

lines and individual machines in the line configuration.

Line Reporter

The Fuji Flexa component used to generate production reports according to specified

settings. Reports can be prepared for obtained production data up to 7 days (i.e., 168

hours) prior to the time of report generation.

line server

This is a Fuji Flexa server ran on a computer and specifies the location of the line

configuration files and manages access to these files.

local job

A job that is stored on a local computer. This job is not managed by the job server and is

not accessible to any other users.

machine configuration

A file that specifies the configuration, process options, available nozzles and feeders for a

machine. Each machine in the line must have a configuration with the specific parameters

for that machine.

macro

Sets of instructions that are automatically performed when activated.

Macro Manager

The Fuji Flexa component used to create, modify, save, and run macros

mark data

There are five different types of mark data. They are fiducial marks, skip marks, glue marks,

mask marks, and panel ID marks

Mark Editor

The Fuji Flexa component used to create and edit mark data.

mark library

The library in which mark data is stored. The part data server manages access to this

library.

mask mark

These are marks used by printing machines to align the printing stencil with the board. The

printing machine inspects the fiducial marks on the board and mask marks on the stencil
