QD004-18 Glossary

NXT Programming Manual 203

and then adjusts the stencil position to compensate for any misalignment between the two.

MCSIMF format

An intermediary file format. MCS programs and part data translated by Port Wizard are

output as MCSIMF files.

MEdit

This is a special program used to edit jobs on NXT machines and perform special functions

such as simulation and skipping nozzles. This software is installed from the NXT

application installation CD-ROM.

menu bar

This displays below the title bar for programs. Commands are organized into groups and

these group names display on the menu bar. By clicking a name, the menu with the

commands for that group displays. Click an item to perform that command.

model name

The model name is a generic machine name that is used when using multiple lines with

identical line and machine configurations (including nozzles, parts supply unit, etc.). This

allows users to use the same recipe from machine to machine when producing identical

panels on multiple lines.

next job

An portion of the machine's memory is used to store the information for the next job that

has been sent to the machine. This job is usually the job that is to be produced after the

current job is completed. Only one job can be sent to the next job position in the machine

per lane.

non-relational mode

This is a mode used for part data. When this mode is used, the "Part Number", "Shape

Name" and "Package Name" data is all saved under the one file name. There is no

interlinking between the different part data. This mode prevents user from accidentally

editing package and shape data for various part at one time and is similar to Fuji's previous

host system, MCS. This mode is specified in Flexa Server Setup in the [System settings]

dialog box on the computer running the user server.

Nozzle Mapper

The Fuji Flexa component that is a conversion tool designed to convert the nozzle settings

for part data when importing Port Wizard translated CCIMF or MCSIMF data from F4G or

MCS into Job Builder.

optimization

The process where machine instructions are reordered so that the machine operates

optimally. Normally, the processing sequence and feeder positions are rearranged in a

manner that minimizes the machine’s working time.

Glossary QD004-18

204 NXT Programming Manual

package data

Data that describes packaging used for parts. The package data ís comprised of type,

dimensions, pitch, and other parameters that a machine needs to process that package for

the part that uses that data. This data is comprised of two groups of data, package

information, and package process.

Package Editor

The Fuji Flexa component that is used to create and edit package data. This editor is only

available if relational mode is enabled from the Flexa Server Setup.

package information

Data that has the settings that are used to describe the package. The package's pitch,

dimensions, and type are examples of settings found in package information. This is one

of the groups of data that makes up package data.

package library

The library in which package data is stored. This library is only accessible if relational mode

is enabled in Flexa Server Setup. The part data server manages access to this library.

package process

Data that has the settings on how the packaging using that data is to be processed by the

machine. Feeder options, reel diameter, and do advanced vacuum are examples of

settings found in package process. This is one of the groups of data that makes up package

data.

panel

The entire printed circuit board (PCB) upon which electronic components are placed. A

panel may be composed of one or more actual boards.

part data

All part data items. This refers to data for the part number, shape data, and package data

if relational mode is enabled. If it is not enabled, then shape data and package data is not

displayed.

part data server

This is a Fuji Flexa server ran on a computer and specifies the location of the part data files

and manages access to these files.

Part Editor

The Fuji Flexa component that is used to create and edit part data. If relational mode is

enabled from the Flexa Server Setup, this editor is used to create and edit part number

data. If non-relational mode is used, this editor is used to create and edit all part data

part library

The library in which part data is stored. The part data server manages access to this library

QD004-18 Glossary

NXT Programming Manual 205

part templates

These are sections of part data that have been created to be used for future part data

creation. Part templates can be imported into part data reducing the amount of data input

necessary when creating new data. After importing the template, only the data that differs

from the template needs to be edited. Templates can be created for "Shape Information",

"Shape Process", "Package Information" and "Package Process" data.

Part Template Editor

The Fuji Flexa component that is used to create and edit part templates.

recipe

Operation instructions for individual machines, created after the completion of line

balancing and optimization processing. In the past, Fuji has referred to recipes as

"Production programs".

relational mode

This is a mode used for part data. This mode allows a "Part number" to be linked to a

shared "shape" and "package". The relational mode allows multiple "part number" records

to use the same shape data record and/or package data, thus minimizing the size of the

libraries. In addtion, by editing a packaging or shape record that is accessed by multiple

part numbers, all the part data for all the part numbers are updated at one time. This is

similar to Fuji's previous host system, FujiCam. When this mode is active, three

components are used to create and edit the different data. This mode is specified in Flexa

Server Setup in the [System settings] dialog box on the computer running the user server

shape data

Data that describes a part's dimensions, the quantity and size of pins (leads), and other

parameters that a machine needs to process a part that uses that data. This data is

comprised of two groups of data, shape process and shape information.

Shape Editor

The Fuji Flexa component that is used to create and edit shape data. This editor is only

available if relational mode is enabled from the Flexa Server Setup.

shape information

Data that has the settings that are used to describe the part. The part's dimensions, the

quantity and size of pins (leads), and element information are examples of settings found

in shape information. This is one of the groups of data that makes up shape data.

shape library

The library in which shape data is stored. This library is only accessible if relational mode

is enabled in Flexa Server Setup. The part data server manages access to this library.

shape process

Data that has the settings on how a part using that data is to be processed by the machine.
