QD004-18 3. Job Builder
NXT Programming Manual 7
4. Enter auto backup pin data. (NXT, only for equipped machines)
5. Change certain part data for the NXT. (NXT)
6. Panelize the panel (Panel Management).
7. Line balance the work load. (NXT)
8. Optimize the job. (NXT)
9. Generate reports. (NXT)
3.2.5 Starting by importing MCSIMF files
It is possible to create a job completely through importing generated MCSIMF program and
part data files. Follow the roadmap below to create a job by importing MCSIMF files.
Generating recipes is not necessary for the NXT unless one wants to view reports.
1. Create a job by importing MCSIMF data.
2. Import the MCS part data into the job (only necessary if part data was not imported in
step 1).
3. Change the current line to the new NXT line. (NXT)
4. Enter the machine configuration and process data. (NXT)
5. Enter auto backup pin data. (NXT, only for equipped machines)
6. Change certain part data for the NXT. (NXT)
7. Panelize the panel (Panel Management).
8. Line balance the work load. (NXT)
9. Optimize the job. (NXT)
10.Generate reports. (NXT)
3.2.6 Starting by importing Allegro CAD data
Follow the roadmap below to create a basic job by importing Allegro CAD data. Generating
recipes is not necessary for the NXT unless one wants to view reports.
1. Create a job manually.
2. Import the Allegro CAD data.
3. Import the BOM file.
4. Import any existing part data into the job.
5. Create any missing part data. (NXT)
6. Import mark data into the job.
7. Perform a verify check
8. Add a line to the job.
9. Enter the machine configuration and process data. (NXT)
10.Enter auto backup pin data. (NXT, only for equipped machines)
3. Job Builder QD004-18
8 NXT Programming Manual
11.Panelize the panel (Panel Management).
12.Line balance the work load. (NXT)
13.Optimize the job. (NXT)
14.Generate reports. (NXT)
3.2.7 Starting by importing Mentor CAD data
Follow the roadmap below to create a basic job by importing Mentor CAD data. Generating
recipes is not necessary for the NXT unless one wants to view reports.
1. Create a job manually.
2. Import the Mentor CAD data.
3. Import the BOM file.
4. Import any existing part data into the job.
5. Create any missing part data. (NXT)
6. Import mark data into the job.
7. Perform a verify check
8. Add a line to the job.
9. Enter the machine configuration and process data. (NXT)
10.Enter auto backup pin data. (NXT, only for equipped machines)
11.Panelize the panel (Panel Management).
12.Line balance the work load. (NXT)
13.Optimize the job. (NXT)
14.Generate reports. (NXT)
3.2.8 Starting by importing CR5000 (PWS/Board Designer) CAD
data
Follow the roadmap below to create a basic job by importing CR5000 CAD data.
Generating recipes is not necessary for the NXT unless one wants to view reports.
1. Create a job manually.
2. Import the CR5000 CAD data.
3. Import the BOM file.
4. Import any existing part data into the job.
5. Create any missing part data. (NXT)
6. Import mark data into the job.
7. Perform a verify check
8. Add a line to the job.
9. Enter the machine configuration and process data. (NXT)
QD004-18 3. Job Builder
NXT Programming Manual 9
10.Enter auto backup pin data. (NXT, only for equipped machines)
11.Panelize the panel (Panel Management).
12.Line balance the work load. (NXT)
13.Optimize the job. (NXT)
14.Generate reports. (NXT)
3.2.9 Starting by importing OrCAD CAD data
Follow the roadmap below to create a basic job by importing OrCAD CAD data. Generating
recipes is not necessary for the NXT unless one wants to view reports.
1. Create a job manually.
2. Import the OrCAD CAD data.
3. Import the BOM file.
4. Import any existing part data into the job.
5. Create any missing part data. (NXT)
6. Import mark data into the job.
7. Perform a verify check
8. Add a line to the job.
9. Enter the machine configuration and process data. (NXT)
10.Enter auto backup pin data. (NXT, only for equipped machines)
11.Panelize the panel (Panel Management).
12.Line balance the work load. (NXT)
13.Optimize the job. (NXT)
14.Generate reports. (NXT)
3.2.10 Starting by importing SFX-J1 CAD data
Follow the roadmap below to create a basic job by importing SFX-J1 CAD data. Generating
recipes is not necessary for the NXT unless one wants to view reports.
1. Create a job manually.
2. Import the SFX-J1 CAD data.
3. Import the BOM file.
4. Import any existing part data into the job.
5. Create any missing part data. (NXT)
6. Import mark data into the job.
7. Perform a verify check
8. Add a line to the job.
