QD004-18 3. Job Builder
NXT Programming Manual 5
3. Job Builder
3.1 Introduction
Job Builder is used to create and edit jobs. Most of the procedures for the NXT are the
same as previous Fuji machines. This chapter lists the general steps for creating jobs for
the various data types. The Job Builder procedures that are different or unique for the NXT
are also provided in this chapter. Part data settings for the NXT are covered in detail in 4.
"Part Data Settings".
3.2 General Steps to Creating NXT Jobs
This section provides a basic roadmap of procedures for creating jobs for the NXT based
upon the different methods of entering data in the job.
These roadmaps listed are only for general reference and are only designed to help in the
job creation process. There are cases when more or less steps are required depending on
the situation.
The details for performing the unique NXT steps listed in the following procedures are in the
following sections. The name in the steps that are marked (NXT) are based on the name
of that item in this manual. For details on procedures that are not marked (NXT), refer to
the Fuji Flexa User Manual, Chapter 2. The procedure can be determined based upon the
name of the corresponding step.
3.2.1 Starting by changing an existing job
Follow the steps below when changing a job that is currently complete for other machine
types into a job with an NXT line. Generating recipes is not necessary for the NXT unless
one wants to view reports. Because this job was already completed using other machines,
panelizing, and importing data is not required.
1. Open the existing job.
2. Change the current line to the new NXT line. (NXT)
3. Enter the machine configuration and process data. (NXT)
4. Enter auto backup pin data. (NXT, only for equipped machines)
5. Change certain part data for the NXT. (NXT)
6. Line balance the work load. (NXT)
7. Optimize the job. (NXT)
8. Generate reports. (NXT)
3.2.2 Starting by manually entering sequence data
If no outside data files are available, it is possible to create a job completely through data
entry. Follow the roadmap below to create a basic job through manual data entry.
Generating recipes is not necessary for the NXT unless one wants to view reports.
1. Create a job manually.
2. Add a line to the job.
3. Job Builder QD004-18
6 NXT Programming Manual
3. Enter the machine configuration and process data. (NXT)
4. Enter auto backup pin data. (NXT, only for equipped machines)
5. Import part data into the job or create part data in the job. (NXT)
6. Add parts.
7. Import mark data into the job or create mark data in the job.
8. Create mark sequences.
9. Assign marks to machines.
10.Panelize the panel (Panel Management).
11.Line balance the work load. (NXT)
12.Optimize the job. (NXT)
13.Generate reports. (NXT)
3.2.3 Starting by importing centroid CAD data
Follow the roadmap below to create a basic job by importing centroid CAD data.
Generating recipes is not necessary for the NXT unless one wants to view reports.
1. Create a job manually.
2. Import the centroid CAD data.
3. Import the BOM file.
4. Import any existing part data into the job.
5. Create any missing part data. (NXT)
6. Import mark data into the job.
7. Add a line to the job.
8. Enter the machine configuration and process data. (NXT)
9. Enter auto backup pin data. (NXT, only for equipped machines)
10.Panelize the panel (Panel Management).
11.Line balance the work load. (NXT)
12.Optimize the job. (NXT)
13.Generate reports. (NXT)
3.2.4 Starting by importing CCIMF files with part data
It is possible to create a job completely through importing generated CCIMF files with part
data. Follow the roadmap below to create a job by importing CCIMF files with part data.
Generating recipes is not necessary for the NXT unless one wants to view reports.
1. Create a job by importing CCIMF data.
2. Change the current line to the new NXT line. (NXT)
3. Enter the machine configuration and process data. (NXT)
QD004-18 3. Job Builder
NXT Programming Manual 7
4. Enter auto backup pin data. (NXT, only for equipped machines)
5. Change certain part data for the NXT. (NXT)
6. Panelize the panel (Panel Management).
7. Line balance the work load. (NXT)
8. Optimize the job. (NXT)
9. Generate reports. (NXT)
3.2.5 Starting by importing MCSIMF files
It is possible to create a job completely through importing generated MCSIMF program and
part data files. Follow the roadmap below to create a job by importing MCSIMF files.
Generating recipes is not necessary for the NXT unless one wants to view reports.
1. Create a job by importing MCSIMF data.
2. Import the MCS part data into the job (only necessary if part data was not imported in
step 1).
3. Change the current line to the new NXT line. (NXT)
4. Enter the machine configuration and process data. (NXT)
5. Enter auto backup pin data. (NXT, only for equipped machines)
6. Change certain part data for the NXT. (NXT)
7. Panelize the panel (Panel Management).
8. Line balance the work load. (NXT)
9. Optimize the job. (NXT)
10.Generate reports. (NXT)
3.2.6 Starting by importing Allegro CAD data
Follow the roadmap below to create a basic job by importing Allegro CAD data. Generating
recipes is not necessary for the NXT unless one wants to view reports.
1. Create a job manually.
2. Import the Allegro CAD data.
3. Import the BOM file.
4. Import any existing part data into the job.
5. Create any missing part data. (NXT)
6. Import mark data into the job.
7. Perform a verify check
8. Add a line to the job.
9. Enter the machine configuration and process data. (NXT)
10.Enter auto backup pin data. (NXT, only for equipped machines)
