FK-9F98-34 XP Type II Series Training Text for Service Engineers

Edition 2.0 XP142E – Chapter 1 Initial Adjustment Page 3 of 8

Fuji Machine Mfg. Co., Ltd.Okazaki

1.3 Lubrication

1. Apply lubricant to the following areas:

Lubrication points Lubrication Type

Y-axis ball screw Daphne Eponex No.2

Z-axis ball screw Daphne Eponex No.2

Spline Shaft Daphne Eponex No.2

Theta and R axes gears Daphne Eponex No.2

Conveyor ball screw Daphne Eponex No.2

Conveyor LM rail Daphne Eponex No.2

Sliding parts of lifter plate link arm Daphne Eponex No.2

Sliding parts of cutter link arm Daphne Eponex No.2

Cutter LM rail Daphne Eponex No.2

F and G axes cams Daphne Eponex No.2

Nozzle Pistons AFC Grease

Spool Axes AFC Grease

Conveyor Chain Biral T and D

Note: Apply anticorrosion spray to the machine base, brackets, and other metal surfaces, to prevent

rust.

Note: Do not over apply lubricant to the ball screws, helical gears, LM guide rails, or other parts of the

machine that rotate or move at high velocity. Over lubrication may result in the lubricant being flung

around the machine and interfering with the sensors, vision processing, and other aspects of the

machine operation.

SMT Equipment Quality Assurance Dept.

1 – 3 CS Section

FK-9F98-34 XP Type II Series Training Text for Service Engineers

Edition 2.0 XP142E – Chapter 1 Initial Adjustment Page 4 of 8

Fuji Machine Mfg. Co., Ltd.Okazaki

1.4 Belt Tension Measurement

1. Equipment: belt tension meter.

2. Press the emergency stop button to cut the 200-volt power supply to the servos and then

bring the Y and Z axes to the minus mechanical stoppers.

3. Refer to the following illustrations and check that the tension of each belt is within the

appropriate range:

Measure Y-axis

here at side 2

Measure Z-axis

here at side 1

Belt unit weight Belt width Belt span Frequency range

Y axis

0.4 gf/mm 15mm 130mm 145 –163 Hz

Z axis

0.2 gf/mm 8mm 110mm 206 – 228Hz

4. Finally check the tension of the fixed rail and adjustable rail conveyor belts, measure at the

point indicated in the photo below. Tension should be in the range 425 ~ 445 Hz.

Measure

Here

SMT Equipment Quality Assurance Dept.

1 – 4 CS Section

FK-9F98-34 XP Type II Series Training Text for Service Engineers

Edition 2.0 XP142E – Chapter 1 Initial Adjustment Page 5 of 8

Fuji Machine Mfg. Co., Ltd.Okazaki

1.5 Computer Connection

Note: at the time of publication of this manual the XP type II machine type is not officially

supported in the MCS/X, F4G or FujiCam host systems. Communication between the XP type

II and these hosts is possible but “machine type” should be set to XP141 or XP241.

Machine Side

1. Connect the LAN cable to the PC.

2. Remove the bottom left cover at the front of the machine, and connect the LAN cable to the

LAN port.

3. Select [Maintenance B] – [Start Up Settings]:

Target: Input the machine nickname.

Ethernet Address: Input the machine IP address.

4. After inputting the “Target” and “Ethernet Address” click on [Update] to save the new

settings and reboot the machine in order for them to take effect.
