FK-9F98-34 XP Type II Series Training Text for Service Engineers
Edition 2.0 XP142E – Chapter 7 Operation and Accuracy Page 7 of 8
14. Load the reverse measurement holder in the conveyor and select [Conveyor Operation] –
[Load New Panel] to clamp the holder and board in the main table.
15. Select [Maintenance C] – [Accuracy Measurement] – and turn [Place Offset
Measurement Mode] ON.
16. Press [Select Program] – and select “ReverseAM-F-192.PGO”.
17. Select [Reverse Start] – [START] to start the measurement.
18. Once measurement is complete the “Accuracy Measurement Result” window opens.
Press [Side1 Offset] – [OK] to save the offsets.
19. Remove the holder from the conveyor and replace the tape on the glass board, repeating
steps 6 to 15 until the results are within the following tolerance:
Average 3∑
X
+/- 0.020 0.050
Y
+/- 0.020 0.050
Q
+/- 0.200 1.500
Side 2
1. Repeat for side 2 using “ReverseAM-R-192.PGO”.
Fuji Machine Mfg. Co., Ltd. Okazaki
SMT Equipment Quality Assurance Dept.
7 – 7 CS Section
FK-9F98-34 XP Type II Series Training Text for Service Engineers
Edition 2.0 XP142E – Chapter 7 Operation and Accuracy Page 8 of 8
NOTES:
