FK-9F98-34 XP Type II Series Training Text for Service Engineers
Edition 2.0 XP142E – Chapter 5 Peripheral Adjustments Page 6 of 14
9. Make sure the front sliding attachments on the jig are pulled to the rear of the jig (away
from the machine interior).
Side 1
F1
F2
D47 D49
10. Insert a 1.8mm diameter wire jig through both holes in the sliding attachments and adjust
the position of the sensor so that the point where the sensor beam is emitted is aligned
with the center of the wire jig.
11. Confirm that the fiber sensor attachment is securely fixed to the fiber sensor.
Make sure that it is not possible to turn
the fiber sensor attachment by hand
12. Now fine adjust the position of the sensors to find the position where the number on the
digital display is maximised. This maximum value should be greater than 3. If the value
is 3 or less check the fiber wiring and clean the sensor lens.
Side 1
F2 F1
13. After the sensors have been set at the optimum position turn the dial switch on the
sensor amplifier until “2P” flashes in the digital display.
Fuji Machine Mfg. Co., Ltd. Okazaki
SMT Equipment Quality Assurance Dept.
5 – 6 CS Section
FK-9F98-34 XP Type II Series Training Text for Service Engineers
Edition 2.0 XP142E – Chapter 5 Peripheral Adjustments Page 7 of 14
14. Press the dial once so that the “2” in “2P” flashes.
15. Block the sensor by hand and press the dial switch once. A number 1~100 will display
on the digital display, this must be greater than 10.
16. Press the dial switch once so that SET flashes in the mode display.
17. Turn the dial switch so that RUN flashes in the mode display.
18. Press the dial switch once to complete the adjustment.
19. Finally select [Maintenance A] – [I/O Check] and check the sensor operation by I/O.
Side 1
Sensor I/O Output when not
interrupted
Output when
interrupted
F1 X02C Side1TpsetDetect1 O (with buzzer) X
F2 X029 Side1TpSetDetect2 O (with buzzer) X
20. Repeat the whole procedure for the sensors and amplifiers at side 2.
Side 2
Sensor I/O Output when not
interrupted
Output when
interrupted
F1 X03C Side2TpSetDetect1 O (with buzzer) X
F2 X02B Side2TpSetDetect2 O (with buzzer) X
Fuji Machine Mfg. Co., Ltd. Okazaki
SMT Equipment Quality Assurance Dept.
5 – 7 CS Section
FK-9F98-34 XP Type II Series Training Text for Service Engineers
Edition 2.0 XP142E – Chapter 5 Peripheral Adjustments Page 8 of 14
5.4 MFU Interlock Sensors
1. Clamp the MFU and set two sensor adjustment jigs (Z9631ADEPJ8070) at slots D47
and D49 at side 1.
Attachment Plate
Z9631ADEPJ8070
Fuji Machine Mfg. Co., Ltd. Okazaki
2. Adjust the position of the interlock sensors so that the light beam goes through the holes
in the attachment plates.
Hole
Interlock Sensor
SMT Equipment Quality Assurance Dept.
5 – 8 CS Section
