3. Label positions ix Safety instructions ► W arning/caution labels (machine inter nal) No. Label Meassage Measures 9 Electrical shock hazard Do not touch while power is supplied. 11 Machine damage Make sure push-up pins…
3. Label positions
viii
Safety instructions
█
Label positions (machine internal)
Warning/caution labels
Machine internal
HM head unit
RM head unit
Controller
11 [CAUTION]
Machine damaged
13 [CAUTION]
Strong magnetic field
13 [CAUTION] Strong magnetic field
12 [PROHIBITION] DO NOT touch
12 [PROHIBITION]
DO NOT touch
12 [PROHIBITION]
DO NOT touch
15 [WARNING]
Electrical shock hazard
9 [CAUTION]
Electrical shock hazard
12 [PROHIBITION]
DO NOT touch
12 [PROHIBITION] DO NOT touch
12 [PROHIBITION]
DO NOT touch
12 [PROHIBITION]
DO NOT touch
12 [PROHIBITION]
DO NOT touch
■ X-axis frame inner side
■ X-axis frame
■ X-axis frame
■ Y-axis linear scale
■ Z-axis linear
■ Y-axis linear guide
■ Fiducial camera
■ Fiducial camera
■ Side view camera
■ Scan camera unit
■ Scan camera
93013-YRM-00
3. Label positions
ix
Safety instructions
►
Warning/caution labels (machine internal)
No. Label Meassage Measures
9
Electrical shock hazard Do not touch while power is supplied.
11
Machine damage Make sure push-up pins are arranged
within specified area.
12
Adverse effects on component
mounting accuracy
Do not touch camera unit or apply
impacts to it.
13
Death, serious injury or equipment
malfunction
Observe precautions necessary due to
strong magnetic fields.
14
Unexpected accidents may occur if
safety mechanisms are disabled.
Do not remove or disassemble any
specified safety mechanism (protective
cover, safety cover, etc.).
15
Electrical shock hazard Before opening covers wait at least
100 seconds after turning power off.
4. Safety
x
Safety instructions
4. Safety
To ensure that the machine you purchased is used safely and correctly, always comply with the
instructions and rules in this manual regarding safety. However this manual cannot cover all items
regarding safety in detail. So it is extremely important that the operator or person handling the machine
make correct decisions regarding safety.
4.1 To ensure safety
To maintain the safety of the operator or person working with this machine, it is essential that it (including
external parts feeders) be installed correctly in compliance with the safety standards and conditions of that
country.
Complying with the safety regulations and laws of that country is the responsibility of the customer who
purchased this machine. The supervisor of this machine must take responsibility to ensure all measures have
been taken for machine safety.
4.1.1 Defining safety
1. Safety has priority over all other operations.
2. Safety is more important than any other task.
3. Safety is the foundation for work efficiency.
4. Safety begins with maintaining (keeping it neat and orderly) the work environment.
4.1.2 Causes of injuries and accidents
Most accidents are not something that occurs but something that are caused. So it is important to make an
effort NOT to cause accidents.
█
Hazardous actions
• Ignoring causes of accidents
• Working or operating equipment in cramped locations
• Working in locations or positions where safety cannot be ensured
• Unsafe machine operation and using equipment whose safety cannot be ensured
• Working or operating equipment at speeds where safety cannot be ensured
• Working or operating machines with safety equipment removed
• Performing work or tasks on top of a machine currently in operation
• Playing around or goofing off during work
• Performing maintenance or inspections without wearing safety gear
