Chapt er 3 Flo w f rom s t ar ting up ma chin e t o pro du c ti on Contents 1. Flow fr om star ting up machine t o production 3-1 1. 1 Pre-operation check 3-2 1.2 Star ting the machine 3-3 1.3 Selecting the operator 3-5 …
4. Preparing component tape
2-82
Chapter 2 Basic operation
4.2.4 Detaching SS feeder from carriage
1
Detach feeder from carriage.
1. Hold the bottom of SS feeder and pull the handle to near side of operator.
2. While keeping pulling the handle backward, pull the feeder straight out.
Feeder exchange carriage
Detaching SS feeder from carriage
Pull the handle to near side of operator
23239-KMX-00
2
Detach the reel.
Detach the reel from the reel holder of carriage.
Chapter 3 Flow from starting up
machine to production
Contents
1.
Flow from starting up machine to production 3-1
1.1 Pre-operation check 3-2
1.2 Starting the machine 3-3
1.3 Selecting the operator 3-5
1.4 Warming up the machine 3-7
1.5 Selecting the board data 3-9
1.6 Conveyor unit setup 3-10
1.6.1 Laying out push-up pins 3-11
1.6.2 Adjusting board hold plate position 3-15
1.6.3 Checking condition of clamping board 3-19
1.7 Preparing component tape (Tape feeder) 3-21
1.8 Confirming nozzles 3-22
1.9 Starting production 3-26
1.10 Ending production 3-27
1.11 Powering off the machine 3-28
1.12 Resuming operation from the stopped point 3-30
1. Flow from starting up machine to production
3-1
Chapter 3 Flow from starting up machine to production
1.
Flow from starting up machine to production
The following flow diagram shows the basic procedures from starting the machine, mounting
components and stopping the machine after finishing up the production.
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.9
1.10
1.11
1.12
1.8
Flow from starting up machine to production
Power on the machine.
Return the units to their origins.
Starting the machine
Pre-operation check
Selecting the operator
Warming up the machine
Selecting the board data
Conveyor unit setup
Preparing component tape (Tape feeder)
Start from this step if switching the production board data.
Check that the push-up pins, board
hold plate and state of securing board
in place are all right.
* Jumps to target page by clicking from 1.1 to 1.12 .
Click to return to this page.
Resuming operation from the stopped point
Starting production
Ending production
Powering off the machine
Check the operation speed.
Return the units to their origins.
Power off the machine.
Resume the operation where it left off.
Block skip
Confirming nozzles
Confirm the nozzle types.
Check the nozzle tip cleanness.
23300-KMX-00
