1. Flow from starting up machine to production
3-4
Chapter 3 Flow from starting up machine to production
2
Set the carriage to the machine.
Before performing return-to-origin, set the carriage to the mounter, referring chapter 2, "4.1.3
Attaching the feeder exchange carriage on the mounter".
3
Perform return-to-origin.
The “Return to origin” screen appears on the display. Press the [Ready] button and then follow the
instructions on the screen to perform return-to-origin.
n
NOTE
If the machine is not yet ready for return-to-origin operation, the return-to-origin operation on the setup screen can be
performed before going through the procedure according to "1.4 Warming up the machine" in this chapter.
1. Flow from starting up machine to production
3-5
Chapter 3 Flow from starting up machine to production
1.3 Selecting the operator
Assign the operator who operates the machine.
Normally, register the operator names and operation authorities (and passwords, if necessary) in advance
and select the operator from those registered.
At the time of shipping, two operators or operator groups were registered - The “Administrator” (“A group of
administrators)” who have all the complete operation authorities and the “Default operator” (“A group of
default operators”) who have a fewer operation authorities.
TIP
Active menu buttons differ depending on the operation level setup. For example, when the machine is turned on with the
factory setup, the program starts up at an operation level called "Default Operator". This "Default Operator" level is set to
"Level 0" at the time of shipment to allow only basic operation items. This operation level can be changed as needed.
Operators and operation items can also be added and specified by setting the password and operation level.
For more details, see “Programming Manual".
1
Press the [Operator] button.
The ID WINDOW screen appears for specifying the operator.
[Operator] button
[Operator] button
24301-KMX-00
1. Flow from starting up machine to production
3-6
Chapter 3 Flow from starting up machine to production
2
Assign the operator.
1. Pull down the “Operators” (Group name) on the “ID window” (operator window) and select an
“Administrator” or “Operator”.
2. Select the “Operator”.
3. (If passwords are used) Enter the corresponding password.
4. Press the [OK] button. The initial screen (the setup screen before selecting a board) appears on
the display.
Specifying the operator
Select group name.
Enter password.
Select operator name.
24302-KMX-00
