YRM20_Ope_E.pdf - 第187页
1. Flow from starting up machine to production 3-7 Chapter 3 Flow from starting up machine to production 1.4 W arming up the machine After starting up the machine, we recommend w arming it up for about 10 minutes in most…
1. Flow from starting up machine to production
3-6
Chapter 3 Flow from starting up machine to production
2
Assign the operator.
1. Pull down the “Operators” (Group name) on the “ID window” (operator window) and select an
“Administrator” or “Operator”.
2. Select the “Operator”.
3. (If passwords are used) Enter the corresponding password.
4. Press the [OK] button. The initial screen (the setup screen before selecting a board) appears on
the display.
Specifying the operator
Select group name.
Enter password.
Select operator name.
24302-KMX-00
1. Flow from starting up machine to production
3-7
Chapter 3 Flow from starting up machine to production
1.4 Warming up the machine
After starting up the machine, we recommend warming it up for about 10 minutes in most cases. If less than
two hours has elapsed after the machine was last used, no warm-up is necessary.
1
Press the [Warm Up] button on the Setup screen.
The Warm-up screen then appears.
2
Enter a warm-up time.
Press the [Stop after time over] button and enter the warm-up time. Warm-up will automatically stop
when the warm-up time you set has elapsed. Normally, about a 10-minute warm-up is sufficient.
Warm-up time setting
[Setup] screen
[Stop after time over] button“Warm up” screen
[Warm Up] button
24303-KMX-00
1. Flow from starting up machine to production
3-8
Chapter 3 Flow from starting up machine to production
3
Start warming up the machine.
Press the [Start] button to start warm-up. The elapsed warm-up progress time and status appear in the
"Progress status" column.
c
CAUTION
If an abnormality occurs during warm-up, press the [Stop] button to stop operation immediately, check the cause of the
problem and eliminate it.
Warm-up time setting 2
Indicates progress.
[Start] button
[Stop] button
24304-KMX-00
4
Finish the warm-up.
Warm-up will automatically stop when the warm-up time you set is reached. Press the [Close] button,
and return to the previous screen.
