1. Flow from starting up machine to production
3-2
Chapter 3 Flow from starting up machine to production
1.1 Pre-operation check
e
Check the following points before powering on the machine.
w
WARNING
BEFORE STARTING MAINTENANCE, MAKE ABSOLUTELY SURE TO POWER OFF THE MACHINE OR THE MACHINE IS IN
THE STATE THAT THE EMERGENCY STOP BUTTON IS PRESSED.
►
Pre-operation checklist
Check item Check point
Power supply
The specified power is connected to the power supply box located behind the
front lower right panel of the machine.
Supply air
The air supplied from factory with enough pressure (0.45Mpa or more)
* The pressure gauge can be checked after turning on the machine.
Safety cover The covers are closed.
Feeder Feeders are securely attached to the feeder plate and are not tilted.
No foreign objects are on the feeder and feeder plate. No used cover tape
remains. The feeder tail cover is closed.
Conveyor No chips or debris are on the conveyor.
No obstacles such as push-up pins are under the conveyor frame.
Head Each nozzle is correctly installed to the head.
Nozzle
The nozzle tips are not nicked, solder does not adhere to the nozzle tips, and
nozzle spring-action is smooth.
Empty tape dust box No empty tape pieces are in the empty tape dust box.
1. Flow from starting up machine to production
3-3
Chapter 3 Flow from starting up machine to production
1.2 Starting the machine
Proceed as follows to start the machine.
w
WARNING
THE SIGNAL LIGHT LIGHTS UP WHEN THE MACHINE STARTS UP THE OPERATION.
THE GREEN LAMP IS ON DURING OPERATION. THE YELLOW LAMP LIGHTS UP WHEN AN ERROR OR INTERLOCK
OCCURS, AND THE RED (OR WHITE) LAMP LIGHTS UP WHEN EMERGENCY STOP IS TRIGGERED.
NEVER PLACE ANY PART OF THE BODY IN THE HEAD MOVEMENT RANGE WHILE THE GREEN LAMP IS ON.
1
Turn the main switch ON.
Turn on the main switch at the front lower right of the machine, by turning it to the right. After the
system has started, the Initialization screen appears and the program necessary for machine
operation is loaded.
Main switch
ON
OFF
23301-KMX-00
Initialization screen
24300-KMX-00
1. Flow from starting up machine to production
3-4
Chapter 3 Flow from starting up machine to production
2
Set the carriage to the machine.
Before performing return-to-origin, set the carriage to the mounter, referring chapter 2, "4.1.3
Attaching the feeder exchange carriage on the mounter".
3
Perform return-to-origin.
The “Return to origin” screen appears on the display. Press the [Ready] button and then follow the
instructions on the screen to perform return-to-origin.
n
NOTE
If the machine is not yet ready for return-to-origin operation, the return-to-origin operation on the setup screen can be
performed before going through the procedure according to "1.4 Warming up the machine" in this chapter.
