4. Preparing component tape 2-82 Chapter 2 Basic o pera tion 4.2.4 Detaching SS feeder from carriage 1 Detach feed er f rom carr iage. 1. Hold the bottom of SS feeder and pull the handle to near side of operator . 2. Whi…
4. Preparing component tape
2-81
Chapter 2 Basic operation
6
Detach feeder exchange carriage from machine.
Hold the handles of feeder exchange carriage and pull back straight to separate carriage from
machine.
Detaching feeder exchange carriage from machine
Feeder exchange carriage that is set SS feeders
Handles
23238-KMX-00
7
Close upper cover of machine.
8
Olose machine safety cover.
4. Preparing component tape
2-82
Chapter 2 Basic operation
4.2.4 Detaching SS feeder from carriage
1
Detach feeder from carriage.
1. Hold the bottom of SS feeder and pull the handle to near side of operator.
2. While keeping pulling the handle backward, pull the feeder straight out.
Feeder exchange carriage
Detaching SS feeder from carriage
Pull the handle to near side of operator
23239-KMX-00
2
Detach the reel.
Detach the reel from the reel holder of carriage.
Chapter 3 Flow from starting up
machine to production
Contents
1.
Flow from starting up machine to production 3-1
1.1 Pre-operation check 3-2
1.2 Starting the machine 3-3
1.3 Selecting the operator 3-5
1.4 Warming up the machine 3-7
1.5 Selecting the board data 3-9
1.6 Conveyor unit setup 3-10
1.6.1 Laying out push-up pins 3-11
1.6.2 Adjusting board hold plate position 3-15
1.6.3 Checking condition of clamping board 3-19
1.7 Preparing component tape (Tape feeder) 3-21
1.8 Confirming nozzles 3-22
1.9 Starting production 3-26
1.10 Ending production 3-27
1.11 Powering off the machine 3-28
1.12 Resuming operation from the stopped point 3-30
