A1. Specifications A-1 Appendix A1. Specifications █ YRM20 specifications Item Specifications Operating ambient temperature Function guaranteed: 15 to 35°C Accuracy guaranteed: 20 to 28°C Operating ambient humidity 20 to …
A1. Specifications
A-1
Appendix
A1. Specifications
█
YRM20 specifications
Item Specifications
Operating ambient temperature
Function guaranteed: 15 to 35°C
Accuracy guaranteed: 20 to 28°C
Operating ambient humidity 20 to 80% (no condensation), optimal range: 50 to 60%
Noise level Under 78dB
Power requirement (voltage and frequency) 3-phase AC 200/208/220/240/380/400/416V +/- 10%, 50/60Hz
Power capacity 2.5kVA (Peak 5.4kVA) *
7
Breaker rating 30A*
8
Maximum current
55A*
9
Average power consumption
2.2kW
Power cable (conductor cross-section area) 6mm
2
or more
Overvoltage category *
1
Category III
Pollution degree *
1
Degree 2
Supply air pressure *
2
0.45MPa or more
Air consumption (ANR) *
6
RM • RM type : 60L/min (average); 270L/min (max.)*
10
HM • HM type : 260L/min (average); 320L/min (max.)*
10
FM • FM type : 160L/min (average); 270L/min (max.)*
10
Altitude 1000m or less above sea level
Board transport height *
3
900mm +/-10mm
Data
Number of mounting points *
4
32400 points
Number of component types 255 types per board
Number of fiducial marks *
5
128 sets per board
Board data capacity per one machine 500MB
*1: Conforms to IEC60664-1.
*2: This value is different from the air pressure setting of the machine(0.40MPa). Please supply clean and dry air treated with an air
dryer and air filter.
*3: Distance from the floor surface to the upper surface of conveyor belt.
*4: Decreases with the number of boards, blocks and fiducial marks.
*5: When using 2-point fiducial mode.
*6: Is a flow volume under condition of; Temperture: 20˚C, Relative humidity: 65%, Absolute pressure: 101.3kPa (1.03kgf/cm
2
or
760mmHg).
*7: When X and Y axes move at full speed.
*8: Includes the inrush current of the transformer.
*9: When 200V power is supplied.
*10: If the machine is equipped with eATS30 (option), add the air consumption of 30 L/min for each.
n
NOTE
See specification sheets for more detailed information not listed above.
A2. YAMAHA Service website for user
A-2
Appendix
A2. YAMAHA Service website for user
Our service information can be obtained through the Service Website. The following contents can be
available for example.
Item Contents
Important notification New/corrected service information
Manual download Download the operation/maintenance manuals
Support items Introduction of the list of maintenance tools, etc.
Training Informations about periodical training schedule
Vision recognition Recognition information of special parts such as coils
Troubleshooting Supporting informations for trouble solutions
Circuit/air path diagram Materials for investigation about the electrical troubles
Maintenance parts list List of maintenance target parts
n
NOTE
The user registration is necessary for using our Service website. The electronic certification and the first time password are
provided upon completing your registration.
Contact your sales representative for the detail of user registration.
