5-9
5
Managing the data
4
Start making a backup.
n
To make a system backup:
1. Press the [Backup] button.
2. A confirmation message appears asking if you want to make a backup file. Check the backup
destination and then press the [Yes] button.
System backup will start.
3. Another message appears when system backup is complete. Press the [OK] button to close the
message screen.
System backup
Check the backup destination.
64538-L3-00
4. When returned to the “System backup” screen, press the [Close] button to exit it.
n
To make system full backup:
1. Press the [Full Backup] button.
2. A confirmation message appears asking if you want to make a backup file. Check the backup
destination and then press the [Yes] button.
System full backup will start. It will take about 20 minutes to complete.
c
CAUTION
If you want to cancel the backup, press the ESC key on the keyboard.
The data being created will not be deleted even if the backup is cancelled (or fails).
5-10
5
Managing the data
3. Another message appears when system full backup is complete. Press the [OK] button to close the
message screen.
System full backup
Check the backup destination.
64539-L3-00
4. When returned to the “System backup” screen, press the [Close] button to exit it.
5. Check that three files were created in the destination folder.
These files are used to restore the system full backup.
Full backup data
64540-L3-00
c
CAUTION
The files created by system full backup contain the machine settings, network settings, and board data, so keep them
very carefully.
5-11
5
Managing the data
1.3 Restoring the system data
System data can be restored by using either the system backup data or system full backup data.
1.3.1 Restoring a system backup
The system backup data can be restored on the machine.
The following steps describe how to restore the machine setting information using the system backup data
stored in a USB memory device.
1
Press the [System Backup] button on the Setup screen.
The "System backup" screen appears.
Starting the “System backup” screen
64541-L3-00
2
Restore the system backup data.
1. Insert the USB memory device that contains the system backup data, into the USB port on the
machine, and then press the [Restore] button on the "System backup" screen.
2. The "Media Select" screen appears. Select the system backup data you want to restore and press
the [OK] button.
Selecting the system backup data
64542-L3-00
