5-15 5 Managing the data 5 Check the settings for restore and start restoring the backup data. 1. When the “RESTORE” dialog box appears, check the flash disk drive and the path to the system full backup data. 2. After ch…

5-14

Managing the data

Restore the system data.

When the “VgosSystemFullBackup” dialog box appears, check that the backup data is for the machine

where you want to restore and click the [Next] button. The “FLASH DISK” dialog box then appears.

CAUTION

If a ﬂash disk is connected to the PC , remove it and then click the [Next] button.

Checking the machine

Check here.

64545-L3-00

4onnect the flash disk.

When the flash disk is connected to the PC, it is detected by the PC and displayed in the dialog box.

The [Next] button becomes active, and click it to continue.

When flash disk is connected

Detected flash disk

64546-L3-00

CAUTION

• Windows Explorer may automatically start when a ﬂash disk is connected to the PC.

If any application automatically starts, quit it.

• If the ﬂash disk is not detected even after connecting it to the PC , remove the ﬂash disk and then reconnect it again.

• Restoring will write the system full backup data over the data in the ﬂash disk.

5-15

Managing the data

Check the settings for restore and start restoring the backup data.

1. When the “RESTORE” dialog box appears, check the flash disk drive and the path to the system full

backup data.

2. After checking, select the “Determine” check box, and the [Execute] button appears.

3. Click the [Execute] button to start the restore process.

Checking the restore settings and executing restore

Flash disk drive

Path to the system full backup data

“Determine” check box

[Execute] button

64547-L3-00

4. When finished restoring the system data, the “Success” dialog box appears. Click the [OK] button,

and the [Next] button in the “RESTORE” dialog box changed to the [Finish] button.

5. Click the [Finish] button to finish the restore process.

Restore process is complete

64548-L3-00

Install the flash disk into the machine.

Install the new flash disk containing the restored system data into the machine.

Restoring the system full backup data is now complete.

5-16

Managing the data

2. Creating the user database

Registering marks in the user database will prove convenient if they are not included in the YAMAHA

database or they are used very frequently.

The user database should be registered in the user area of the database. The user database area can be

from No. 1 to No. 149 for the mark database. The registered data in this area will be retained even if the

software version is upgraded.

2.1 Copying the data into the database

To copy the component or mark data you created into the user database, follow these steps.

Select the board data name.

Press the [Board] button on the Setup screen and select the board data.

Open the Mark screen.

Press the [Mark] button in the main menu button area.

Select the copy source data.

Line up the cursor with the mark data you want to copy from.

Open the database list.

Press the [Database] button on the [Basic] tab. The database list appears.

Database list

Copy source

[Database] button

64505-L3-10
