2-8 2 Basic operations 2. Star ting and stopping the machine This section explains routine procedures for starting and tur ning off the machine according to the flow charts below . Starting and turning off the machine Pr…
2-7
2
Basic operations
n
Program related errors
Code Error name and description
Ea8548
PLEASE CHECK FOR ANY ILLEGAL RUNNING CONDITION
State The operation condition settings are not adequate for the production.
Cause
Check followings. If all OK, please continue.
• Alignment should be [UseAlign].
• PrintFeedback should be [Use].
• Board Inspection JudgeMode should be [Normal Judge] or [Normal Judge & Exit Judge].
Action If no problem is found after the parameters described above have been checked, continue the operation.
Ea8555
DATA CHECK ERROR
State
Print inspection function is specified to work.
But all parameter of inspection execution for following
Cause
(1) Normal (All Board)
(2) Normal (Interval)
(3) After Dry Auto Cleaning
(4) After Wet Auto Cleaning
(5) After Manual Auto Cleaning
Action Please change the print inspection parameters 1 to 5 described above to “Use”.
Ea8556
DATA CHECK ERROR
State
Print inspection is specified to work for all Board.
But all objects are specified not to work for all Board on current "Inspection Execution Specification".
Check "Inspection Execution Specification" for all Board and "Execution Specification Number" of object data.
Cause The parameters are not set correctly.
Action
Please check the inspection execution condition settings for the normal operation (all boards) and check the
inspection condition No. of the object data.
Ea8590
BOARD TABLE PRINT HEIGHT ERROR
State The print action cannot be executed because the board table is not in the print height.
Cause
Please confirm the state of the board table and the board.
Please restart Auto-Running after Reset.
Action Please contact YAMAHA’s call-center.
Ea8928
DATA CHECK ERROR
State This machine is not supported Mask Standard Position "Rear".
Cause The parameters are not set correctly.
Action
Please set it to the following Mask Standard Position.
(1) Front
(2) Center
n
Mask related errors
Code Error name and description
Ea8629
Mismatch of detected mask size.
State The specified mask size is not matched with the detected mask size.
Cause
Possible causes:
(1) Detected mask has mismatch size specified in Board data.
(2) Mask positioner pin is not set correctly.
Action
1. Please set a mask with a specified size.
2. Please mount the mask positioning pins at their proper positions.
Ea8909
Mask is not clamped.
State The mask is not clamped.
Cause The mask is not clamped.
Action Please clamp the mask.
2-8
2
Basic operations
2. Starting and stopping the machine
This section explains routine procedures for starting and turning off the machine according to the flow charts
below.
Starting and turning off the machine
Program is loaded.
Return-to-origin dialog box appears.
Operation and production
Confirmation dialog box appears.
Move-to-origin dialog box appears.
Setup screen appears.
Return axes to origins
Turn on power switch
Check before operation
Perform return-to-origin
Press [Off] button on operation screen
Press emergency stop button
Turn off machine power switch
Specify operator
Starting the
machine
Turning off the
machine
63203-L3-00
2-9
2
Basic operations
2.1 Inspecting before operation
The table below shows checkpoints you should make before turning the power on.
e
w
WARNING
ALWAYS BE SURE TO PRESS THE EMERGENCY STOP BUTTON BEFORE STARTING THE INSPECTION.
n
Checkpoints before operation
Checkpoints Check items Refer to
Conveyor unit
Check that no foreign matter or debris is on the
conveyor unit.
Check that the push-up jigs or matrix pins are not set
in areas wider than the board width to be produced.
Check that no matrix pins come loose from the push-
up table.
"4. Conveyor unit" in Chapter 1
Mask camera
Check that no foreign matter is sticking to the mask
camera.
Extended exit
conveyor (option)
Check that no board remains on the conveyor.
Check that no solder and debris adheres to the
conveyor.
Check that the cover is closed.
Squeegee
Check that the squeegee knobs are securely
tightened.
Check that the squeegee scrapers have no
scratches, nicks and wear.
Check that no solder and grit are adhering to the
squeegee.
"3. Printing section" in Chapter 1
Cleaning unit
Check that the cleaner gauze roll is set correctly.
Check that the tank is refilled with cleaning alcohol
sufficiently.
"5. Cleaning unit" in Chapter 1
Mask frame
stopper positions
Check that the mask frame stopper positions are
correct.
"2. Compatible masks" in Appendix
Upper door
(safety door),
panels
Check that the upper door and panels are all closed.
Solder
Check that solder has returned to room temperature
and is well agitated and rolled.
Solder manufacturer's instruction
manual
