Chapter 8 Inspection and maintenance
This chapter explains checkpoints and procedures for daily and periodic inspections to use the machine safely and to prevent
possible trouble.
Before beginning inspection or maintenance work, be sure to read "1. Precautions" in this chapter and follow the instructions.
Contents
1. Precautions 8-1
2. Inspection and maintenance 8-2
2.1 Daily inspection 8-2
2.2 Periodic inspection (Weekly/Monthly) 8-3
2.2.1 Parts to be replaced during periodic replacement 8-3
2.2.2 Recommended grease 8-3
2.2.3 List of periodic inspection checkpoints 8-4
2.2.4 Parts recommended for periodic replacement 8-6
2.3 Adjusting the conveyor belt tension 8-7
2.3.1 Board carry-in and carry-out conveyors 8-7
2.3.2 Board clamp unit (board clamp table) 8-9
2.4 Inspecting and cleaning the air/mist filters 8-11
3. List of lubrication locations 8-13
3.1 X-, Y-, and Z-axis 8-13
3.1.1 X1-axis and X2-axis 8-13
3.1.2 Y-axis 8-14
3.1.3 Z-axis 8-14
3.2 Printing head 8-15
3.2.1 SY-axis 8-15
3.2.2 SZ-axis 8-15
3.3 Conveyor unit 8-16
3.3.1 PU-axis 8-16
3.3.2 MS-axis 8-16
3.3.3 W-axis (Conveyor auto width adjustment) 8-17
3.4 Vision camera unit 8-18
3.4.1 CX-axis 8-18
8-1
8
Inspection and maintenance
1. Precautions
Be sure to observe the following precautions when performing the inspection or maintenance work.
• Periodic inspection or maintenance work must be performed by or under the direction of person who has received
training from YAMAHA.
• Always turn off the power to the machine before inspecting mechanical components. If the power to the machine
needs to be turned on during inspection, make sure that no part of anyone's body comes within the machine
movement range.
• Be careful not to allow any foreign matter to enter the machine during inspection or maintenance work.
• Use only the lubricants and grease specified by YAMAHA or a YAMAHA sales representative.
• When replacing parts, always use parts approved by YAMAHA or a YAMAHA sales representative.
• Do not modify any parts in the machine. Modification may result in poor performance or threaten operator safety.
8-2
8
Inspection and maintenance
2. Inspection and maintenance
2.1 Daily inspection
To prevent unwanted trouble, the following points should be checked on a daily basis before and after using
the machine.
n
Daily checkpoints
Checkpoints Check items Refer to
Air pressure
Check the air pressure shown on its display is between 0.40MPa
and 0.41MPa.
"1.1 Air regulator unit"
in Appendix
Temperature
control unit
(option)
Check the drain tank once a day, especially in wet season with high
humidity, and drain the tank. When the tank is filled with water, an
alarm buzzer sounds and the Temperature control unit will stop after
10 minutes if left undrained.
Conveyor unit
Check that no foreign matter, solder or debris is on the conveyor
rail, edge clamp, board flap, push-up jig (machine using optional
push-up jigs), push-up plate, etc.
Check that no matrix pins come loose from the push-up table.
"4. Conveyor unit" in
Chapter 1
Extended
exit conveyor
(option)
Check that no board remains on the conveyor.
Check that no solder and debris adheres to the conveyor.
Squeegee
Squeegee head
Check that the mount knobs of the squeegee head are tightened
firmly.
Check that the squeegee is securely attached to the squeegee
holder. (The squeegee mount knobs are tightened firmly.)
Check that there are no scratches, nicks and wear on the scraper.
Check that there are no foreign matter, debris and solder adhesion.
Remove the squeegees after work and clean them with cleaning
paper or cloth. (When using a urethane squeegee, do not immerse
the squeegee in alcohol. The urethane scraper may expand.)
"3. Printing section"
in Chapter 1
Cleaning unit
Check that the cleaner gauze roll is set correctly. Check also that
the cleaner gauze is filled with cleaning alcohol.
"5. Cleaning unit" in
Chapter 1
Mask frame
stopper pin
position
Check that the mask frame stopper pin position is correct.
"2.1 Mask size and
mask stopper pin
position" in Appendix
Mask clamp Check that there are no foreign matter, debris and solder adhesion.
"3. Printing section"
in Chapter 1
Mask
Check that there are no foreign matter, debris, solder adhesion,
warp and scratches.
Mask manufacturer's
instruction manual
Solder
Check that solder has returned to room temperature and is well
agitated and rolled.
Solder manufacturer's
instruction manual
Touch screen
(option)
Check that there are no scratches or grime on the screen surface.
See "Precautions
when handling the
touch screen" below
l
Precautions when handling the touch screen
Take the following precautions when handling the touch screen (option).
• The touch screen surface is made of acrylic resin. Do not scratch its surface with a pointed tools or hard objects. Use
the finger pad to operate the buttons on the touch screen.
• To clean the touch panel surface, wipe gently with a soft cloth moistened with synthetic detergent diluted with water
and then wrung-out well. Never use volatile chemicals such as benzine, thinner or alcohol.
• To prevent dust adhesion due to static electricity, we recommend using an anti-electrostatic agent.
