About Instruction The instruction manual of this machine is written for those who operate this machine. Please read this manual carefully for correct operations and pay special attention to safety precautions. After read…
Printing guide
1. Flow of printing condition setting E-1
2. Data and condition setting E-2
2.1 Material and setup information E-2
2.2 Alignment offset setting E-4
2.3 Rolling E-5
2.4 Printing and production conditions E-6
3. Details of each parameter item E-7
3.1 Board clamp E-7
3.1.1 Edge clamp pressure E-7
3.1.2 Backup jig E-8
3.2 Board and mask mark recognition (Mark position) E-8
3.3 Alignment offset E-8
3.4 Squeegee (Rolling) E-9
3.4.1 Squeegee speed E-9
3.4.2 Squeegee pressure E-9
3.4.3 Attack angle (degree (°)) E-9
3.5 Solder supply interval E-10
3.6 Detach pattern E-10
3.6.1 Board separation speed E-10
3.6.2 Board separation distance E-11
3.7 Cleaning E-11
3.7.1 Cleaning interval E-11
3.7.2 Cleaning repeat E-11
3.7.3 Cleaning speed E-11
4.
Causes of troubles predicted from symptoms (Appendix)
E-12
4.1 Positional deviation E-12
4.2 Blur E-12
4.3 Insufficient filling E-12
4.4 Solder spread, solder bridge E-13
4.5 Scraping trouble E-13
4.6 Solder enlargement E-13
4.7 Solder chipping, mask remaining E-13
Index
About Instruction
The instruction manual of this machine is written for those who operate
this machine.
Please read this manual carefully for correct operations and pay
special attention to safety precautions.
After reading through this manual, please use this manual as an
occasional reference and keep it within reach.
About this manual
Contents
1. About this manual i
1.1 Revision record i
1.2 Contents of each chapter ii
1.3 Page layout iii
i
About this manual
1. About this manual
This manual is intended for machine operators, and mainly describes how to handle and operate YAMAHA
surface mounters and related equipment.
To use the machines safely and correctly, be sure to read this manual thoroughly before use.
c
CAUTION
Before using the machines, always read the "Safety instructions" in this manual and comply with instructions and rules
regarding safety.
c
CAUTION
The contents of these manuals are subject to change without prior notice. Please be sure to contact our sales office or
representative to obtain the latest information on part names and part numbers.
1.1 Revision record
Major revisions in this manual (Version 2.00) are described below.
Version No. Description of revision Issue date
1.00 YSP user's manual first edition Jul. 2009
1.10
Description of cleaner vacuum pressure gauge was added.
Description of mask stopper pin storing position was added.
Description of squeegee installation was added.
Printing guide was added.
Nov. 2009
1.20 Typing errors, etc. were corrected. Jun. 2010
1.20
Description of blocking the solder printer's solvent pump was added.
The method of replacing the YSP squeegee scraper was changed.
Sep. 2010
1.30
Description of replacing the blower hose was added.
Description of adjusting the conveyor belt tension was added.
Production history details were modified.
Sep. 2011
2.00
Some warning labels are added to "Safety-3 Warning labels" .
"7-6 Replacing the conveyor belt" was added.
"4-8 Graphic alignment" was revised.
"8-2.5 Inspecting and cleaning the air/mist filter" was added.
"7-5.3 Cleaning and replacing the filter for the mask vacuum chuck" was
added.
Some mis-writings were revised.
Jan. 2018
