5-14 5 Managing the data 3 Restore the s ystem data. When the “VgosSystemFullBackup” dialog box appears, check that the backup data is for the machi ne where you want to restore and click the [Next] button. The “ FLASH D…
5-13
5
Managing the data
1.3.2 Restoring a system full backup
To restore the system full backup data, use the dedicated software installed on a PC.
The following steps describe how to restore system data into a flash disk using the system full backup data
stored in a USB memory device.
n
Required components and devices
• Flash disk (parts No. and name: KHL-M4255-00 FLASH DISK)
• Data acquired by system full backup
• PC (Windows XP or later)
• Card reader or memory card adapter
c
CAUT ION
Always use a YAMAHA genuine flash disk. U sing other flash disks may cause malfunction.
n
NOTE
Use a PC with any of the following OS: Windows XP Professional (32 bits) / Windows Vista (32 bits) / Windows 7 (32 bits /
64 bits)
n
Restoring onto a USB memory device
1
Connect the USB memory to the PC.
1. Insert the USB memory containing the system full backup data into the USB port of the PC.
2. A dialog box appears asking you to select what you want Windows to do. Select “Using Windows
Explorer to open a folder to display a file” and click the [OK] button. The “REMOVABLE” screen then
appears.
TIP
If the data acquired by system full backup is stored on the network, select the folder containing the system full backup
data you want to restore.
2
Start the restore software.
1. Double-click the folder that was created by system full backup.
2. The folder contains three files. Double-click the “VgosSystemFullBackup.exe” file, and the restore
software starts up.
Starting the restore software
Double-click this file.
64544-L3-00
5-14
5
Managing the data
3
Restore the system data.
When the “VgosSystemFullBackup” dialog box appears, check that the backup data is for the machine
where you want to restore and click the [Next] button. The “FLASH DISK” dialog box then appears.
c
CAUTION
If a flash disk is connected to the PC , remove it and then click the [Next] button.
Checking the machine
Check here.
64545-L3-00
4
4onnect the flash disk.
When the flash disk is connected to the PC, it is detected by the PC and displayed in the dialog box.
The [Next] button becomes active, and click it to continue.
When flash disk is connected
Detected flash disk
64546-L3-00
c
CAUTION
• Windows Explorer may automatically start when a flash disk is connected to the PC.
If any application automatically starts, quit it.
• If the flash disk is not detected even after connecting it to the PC , remove the flash disk and then reconnect it again.
• Restoring will write the system full backup data over the data in the flash disk.
5-15
5
Managing the data
5
Check the settings for restore and start restoring the backup data.
1. When the “RESTORE” dialog box appears, check the flash disk drive and the path to the system full
backup data.
2. After checking, select the “Determine” check box, and the [Execute] button appears.
3. Click the [Execute] button to start the restore process.
Checking the restore settings and executing restore
Flash disk drive
Path to the system full backup data
“Determine” check box
[Execute] button
64547-L3-00
4. When finished restoring the system data, the “Success” dialog box appears. Click the [OK] button,
and the [Next] button in the “RESTORE” dialog box changed to the [Finish] button.
5. Click the [Finish] button to finish the restore process.
Restore process is complete
64548-L3-00
6
Install the flash disk into the machine.
Install the new flash disk containing the restored system data into the machine.
Restoring the system full backup data is now complete.
