1 - 17
Student Guide SIPLACE HF/HF3
Edition 09/2005 2 Overview
17
2.2.6 Axis Unit HF machine
The axis unit contains the servo boards, axis boards, power supplys (+/-15V,+5V), ballast circuit
and anti-crash board. The flexible axis (Servo) unit will be equipt with servo boards according the
machine configuration.
Fig. 2.2 - 8 Axis unit HF
(1) Power supply +/-15V, +5V
(2) Ballast circuit board
(3) Power supply +/-15V
(4) Anti crash board
(5) Fan unit
(6) Axis board A363
(7) Servo board X-Axis Placement area 1/2
(8) Servo board Y-Axis Placement area 1/2
(9)
Brake board for each X and Y Axis
A9 -> A16
Servo boards according Machine configuration
X
1
Z
RV
X
2
Z
T1
Y
1
DP
RV
Y
2
DP
T1
S
1
F
RV
Z
T2
DP
T2
A9
S
RV
(Z
T2
)
BB1
A10
Z
T2
BB2
A11
Z
RV
(Z
T1
)
BB1
A12
Z
T1
BB2
A13
Fre e
(DP
T2
)
BB1
A15
DP
Rv
(DP
T1
)
BB1
A16
DP
T1
BB2
A14
DP
T2
BB2
1
2
3
4
5
6
7
9
8
9
7
9
8
9
Placement area 1
Gantry 1
Placement area 2
Gantry 3
1 - 18
Student Guide SIPLACE HF/HF3
2 Overview Edition 09/2005
18
2.2.7 Axis Units HF3 machine
The flexible axis unit will be equipt with servo boards depends the machine configuration.
2.2.7.1 Axis Unit Placement Area 1 HF3 machine
Fig. 2.2 - 9 Axis unit PA1 at HF 3
Legend
(1) DC/DC converter 5V/15A for Axis unit (2)
Ballast circuit board
(3) DC/DC converter +/-15V for gantries and
head interface, 5V CAN BUS
(4) Anti crash board
(5) Fan unit (blow downwards) (6) Axis boards
(7)
Servo boards X-Axis Placement area 1 for gan-
tries 1/4
(8) Servo boards Y-Axis Placement area 1 for gan-
tries 1/4
(9) Brake board for each X and Y Axes (10) Servo boards Star-/Z-/DP-Axes gantries 1/4
1
2
3
4
5
6
7
9
8
9
7
9
8
9
Placement area 1
Gantry 1
Placement area 1
Gantry 4
5
10
10
1 - 19
Student Guide SIPLACE HF/HF3
Edition 09/2005 2 Overview
19
2.2.7.2 Axis Unit Placement Area 2 HF3 machine
The axis unit in the placement area 2 is prepared also for two gantrys, for a future machine gen-
eration with 4 gantrys.
Fig. 2.2 - 10 Axis unit PA2
Legend
(1) DC/DC converter 5V/15A for Axis unit (2)
Ballast circuit board
(3) DC/DC converter +/-15V for gantrys and
headinterface, 5V CAN BUS
(4) Anti crash board
(5) Fan unit (blow downwards) (6) Axis boards
(7)
Servo boards X-Axis Placement area 2 for gan-
try (2/)3
(8) Servo boards Y-Axis Placement area 2 for
gantry (2/)3
(9) Brake board for each X and Y Axes (10) Servo boards Z/D-Axes Placement area 2 for
TWIN head3
1
2
3
4
5
6
7
9
8
9
7
9
8
9
Placement area 2
Gantry 2 not used
Placement area 2
Gantry 3
5
10
