4OM-1603 1-62 4. Maintenance Method : Chap.1 1003-001 • For the Nozzles for Middle-Size and Odd-Shape Components Procedure (1) Set the nozzle lter in the hole section. Hole Section Nozzle Filter F4A39-4 (2) Insert the …
4OM-1603
1-61
4. Maintenance Method : Chap.1
1012-003
(3) Orient the nozzle lter opening section to the lter insertion jig and insert the
nozzle into the guide section.
Note
Pay attention to the direction of the nozzle lter opening section.
F4A39-6
(4) Fix the nozzle by holding it from the side with your nger so that the nozzle
is not inclined.
Nozzle
Press it
from the side.
F4A39-7
(5) Push the sliding section to the main machine acrylic block end face and
insert the nozzle lter.
Acrylic Block End Face
Sliding Section
Push
F4A39-8
4OM-1603
1-62
4. Maintenance Method : Chap.1
1003-001
•
For the Nozzles for Middle-Size and Odd-Shape Components
Procedure
(1) Set the nozzle lter in the hole section.
Hole Section
Nozzle Filter
F4A39-4
(2) Insert the lter holding block into the opening section of the lter set.
Filter Holding Block
F4A39-5
(3) Orient the nozzle lter opening section to the lter insertion jig and insert the
nozzle into the guide section.
Note
Pay attention to the direction of the nozzle lter opening section.
Guide Section
F4A39-6
4OM-1603
1-63
4. Maintenance Method : Chap.1
1012-003
(4) Fix the nozzle ange holding its lower surface upward by nger so that the
nozzle is not inclined.
Nozzle
Press it
upward.
F4A39-7
(5) Push the sliding section to the main machine acrylic block end face and
insert the nozzle lter.
Acrylic Block End Face
Sliding Section
Push
F4A39-8
