4OM-1603
4-12
3. Recognition Error IDs and Remedial Procedures : Chap.4
1109-006
Recognition Error ID Description of Recognition Error
07200001 Nozzle not detected.
07200002 Nozzle not detected.
07200000 Others.
07300101 Edge not detected.
07300102 Nozzle not detected.
07300111 Nozzle not detected.
07300112 Nozzle not detected.
07300113 Nozzle not detected.
07300114 Nozzle not detected.
07300000 Others.
07800101 Nozzle size has exceeded the allowable range.
07800102 Nozzle size has exceeded the allowable range.
07800201 Check error
07800202 Check error
07800301 Nozzle position has exceeded the allowable range.
07800302 Nozzle position has exceeded the allowable range.
07800303 Nozzle position has exceeded the allowable range.
07800304 Nozzle position has exceeded the allowable range.
07800401 Nozzle size has exceeded the allowable range.
07800402 Nozzle size has exceeded the allowable range.
07800403 Nozzle position has exceeded the allowable range.
07800000 Others.
07900000 Others.
07e00001 Others.
07e00000 Others.
17000000 Others.
08000001 The nozzle is not stored.
08100001 The locator mark cannot be detected.
08100000 Others.
08200001 There are characters that cannot be detected.
08200000 Others.
08300000 Others.
08800000 Others.
08900000 Others.
08e00000 Others.
08000000 Others.
18000000 Others.
09000000 Others.
09000001 The detection result cannot judge the bad mark existence because of the vicinity
of the boundary value.
09100000 Others.
09100001 There is spots in the bad mark inspection area.
09e00000 Others.
19000000 Others.
0a000000 Lighting teaching Error
0a000001 Lighting teaching Error
4OM-1603
4-13
3. Recognition Error IDs and Remedial Procedures : Chap.4
1109-006
Recognition Error ID Description of Recognition Error
0a000002 Lighting teaching Error
0a000003 Lighting teaching Error
0a000004 Lighting teaching Error
0a000010 The front reverse side of the Jig is opposite
0a000011 Jig is not placed.
0a000012 The contrary or Jig are not placed for the front reverse side of Jig.
0a000013 Lighting teaching Error
0a000014 Jig is not correct.
0a000020 Lighting teaching Error
0a000030 Lighting teaching Error
0a000031 Lighting teaching Error
0a000032 Lighting teaching Error
0a000033 Lighting teaching Error
0a100000 CameramagnicationteachingError
0a100001 CameramagnicationteachingError
0a100002 CameramagnicationteachingError
0a100003 CameramagnicationteachingError
0a100004 CameramagnicationteachingError
0a100005 CameramagnicationteachingError
0a100006 CameramagnicationteachingError
0a200001 The Nozzle axis teaching Error
0a200002 The Nozzle axis teaching Error
0a200003 The Nozzle axis teaching Error
0a200004 The Nozzle axis teaching Error
0a200100 The Nozzle axis teaching Error
0a200000 The Nozzle axis teaching Error
0ae00000 Others.
0ae00001 Others.
1a000000 Others.
0b200000 The edge is not found.
0b200001 The edge is not found.
0b200002 The edge is not found.
0b200003 The edge is not found.
0b200004 The edge is not found.
0b300000 The edge is not found.
0b300001 The edge is not found.
0b300002 The edge is not found.
0b300003 The edge is not found.
0b300010 There is no lead.
0b300020 The range of the selection is not correct.
0b300021 There is no selected lead form.
0b300030 There is no lead group.
0b400000 Electrode is not found.
0b910000 The File not found.
0be00000 Others.
0b000000 Others.
4OM-1603
4-14
3. Recognition Error IDs and Remedial Procedures : Chap.4
1109-006
Recognition Error ID Description of Recognition Error
1b000000 Others.
0c000001 It can't be decoded to a character.
0c000000 Others.
0ce00000 Others.
1c000000 Others.
0d000000 Others.
0d000001 Cannot recognize Support pin existence.
0d100000 Others.
0d100001 Cannot recognize Support pin Jig
0de00000 Others.
1d000000 Others.
0f100001 Vision System Start processing error.(internal data construction)
0f100002 Vision System Start processing error.(internal data construction)
0f100101 Vision System Start processing error.(internal data construction)
0f100102 Vision System Start processing error.(internal data construction)
0f100103 Vision System Start processing error.(internal data construction)
0f100201 Vision System Start processing error.(internal data construction)
0f100301 Vision System Start processing error.(internal data construction)
0f100401 Vision System Start processing error.(internal data construction)
0f100000 Vision System Start processing error.(internal data construction)
0f200001 Vision System Start processing error.(Display)
0f200000 Vision System Start processing error.(Display)
0f300001 Vision System Start processing error.(Light)
0f300002 Vision System Start processing error.(Light)
0f300000 Vision System Start processing error.(Light)
0f400001 Vision System Start processing error.(Acquire)
0f400002 Vision System Start processing error.(Acquire)
0f400003 Vision System Start processing error.(Acquire)
0f400004 Vision System Start processing error.(Acquire)
0f400000 Vision System Start processing error.(Acquire)
0f500001 Vision System Start processing error.(Counter board)
0f500000 Vision System Start processing error.(Counter board)
