4OM-1603
4-4
3. Recognition Error IDs and Remedial Procedures : Chap.4
1012-005
Recognition Error ID Description of Recognition Error
02200615 "Lead Pitch" in "Lead Group 5" is smaller than "Lead Width".
02200616 "Lead Pitch" in "Lead Group 6" is smaller than "Lead Width".
02200617 "Lead Pitch" in "Lead Group 7" is smaller than "Lead Width".
02200618 "Lead Pitch" in "Lead Group 8" is smaller than "Lead Width".
02200621 "Missing Lead Start" in "Lead Group 1" is large.
02200622 "Missing Lead Start" in "Lead Group 2" is large.
02200623 "Missing Lead Start" in "Lead Group 3" is large.
02200624 "Missing Lead Start" in "Lead Group 4" is large.
02200625 "Missing Lead Start" in "Lead Group 5" is large.
02200626 "Missing Lead Start" in "Lead Group 6" is large.
02200627 "Missing Lead Start" in "Lead Group 7" is large.
02200628 "Missing Lead Start" in "Lead Group 8" is large.
02200631 "Full Length" in "Lead Group 1" is smaller than "Lead Length".
02200632 "Full Length" in "Lead Group 2" is smaller than "Lead Length".
02200633 "Full Length" in "Lead Group 3" is smaller than "Lead Length".
02200634 "Full Length" in "Lead Group 4" is smaller than "Lead Length".
02200635 "Full Length" in "Lead Group 5" is smaller than "Lead Length".
02200636 "Full Length" in "Lead Group 6" is smaller than "Lead Length".
02200637 "Full Length" in "Lead Group 7" is smaller than "Lead Length".
02200638 "Full Length" in "Lead Group 8" is smaller than "Lead Length".
02200641 "Lead Width" is small.
02200642 "Lead Length" is small.
02200643 "Full Length" is small.
02200644 "Lead Pitch" is narrow.
02200645 The lead-to-lead distances are short.
02200646 The total of "# of Leads" (lead data) is large.
02200701 "# of Groups" (elctd data) is improper.
02200702 No detection is set in all "Insp Condtn" text boxes.
02200703 Elctd # of Rows or # of Cols is improper.
02200704 "Electrode" is overlapped.
02200711 "Elctd Row or Col Pitch" in "Elctd Group 1" is larger than "Elctd Dim".
02200712 "Elctd Row or Col Pitch" in "Elctd Group 2" is larger than "Elctd Dim".
02200713 "Elctd Row or Col Pitch" in "Elctd Group 3" is larger than "Elctd Dim".
02200714 "Elctd Row or Col Pitch" in "Elctd Group 4" is larger than "Elctd Dim".
02200715 "Elctd Row or Col Pitch" in "Elctd Group 5" is larger than "Elctd Dim".
02200716 "Elctd Row or Col Pitch" in "Elctd Group 6" is larger than "Elctd Dim".
02200717 "Elctd Row or Col Pitch" in "Elctd Group 7" is larger than "Elctd Dim".
02200718 "Elctd Row or Col Pitch" in "Elctd Group 8" is larger than "Elctd Dim".
02200719 "Elctd Row or Col Pitch" in "Elctd Group 9" is larger than "Elctd Dim".
0220071a "Elctd Row or Col Pitch" in "Elctd Group 10" is larger than "Elctd Dim".
0220071b "Elctd Row or Col Pitch" in "Elctd Group 11" is larger than "Elctd Dim".
0220071c "Elctd Row or Col Pitch" in "Elctd Group 12" is larger than "Elctd Dim".
0220071d "Elctd Row or Col Pitch" in "Elctd Group 13" is larger than "Elctd Dim".
0220071e "Elctd Row or Col Pitch" in "Elctd Group 14" is larger than "Elctd Dim".
0220071f "Elctd Row or Col Pitch" in "Elctd Group 15" is larger than "Elctd Dim".
02200720 "Elctd Row or Col Pitch" in "Elctd Group 16" is larger than "Elctd Dim".
4OM-1603
4-5
3. Recognition Error IDs and Remedial Procedures : Chap.4
1012-005
Recognition Error ID Description of Recognition Error
02200721 "Elctd Row or Col Pitch" in "Elctd Group 17" is larger than "Elctd Dim".
02200722 "Elctd Row or Col Pitch" in "Elctd Group 18" is larger than "Elctd Dim".
02200723 "Elctd Row or Col Pitch" in "Elctd Group 19" is larger than "Elctd Dim".
02200724 "Elctd Row or Col Pitch" in "Elctd Group 20" is larger than "Elctd Dim".
02200725 "Elctd Row or Col Pitch" in "Elctd Group 21" is larger than "Elctd Dim".
02200726 "Elctd Row or Col Pitch" in "Elctd Group 22" is larger than "Elctd Dim".
02200727 "Elctd Row or Col Pitch" in "Elctd Group 23" is larger than "Elctd Dim".
02200728 "Elctd Row or Col Pitch" in "Elctd Group 24" is larger than "Elctd Dim".
02200729 "Elctd Row or Col Pitch" in "Elctd Group 25" is larger than "Elctd Dim".
0220072a "Elctd Row or Col Pitch" in "Elctd Group 26" is larger than "Elctd Dim".
0220072b "Elctd Row or Col Pitch" in "Elctd Group 27" is larger than "Elctd Dim".
0220072c "Elctd Row or Col Pitch" in "Elctd Group 28" is larger than "Elctd Dim".
0220072d "Elctd Row or Col Pitch" in "Elctd Group 29" is larger than "Elctd Dim".
0220072e "Elctd Row or Col Pitch" in "Elctd Group 30" is larger than "Elctd Dim".
02200741 Electrode position superposed in different electrode group.
02200742 "Elctd Dim" is small.
02200743 "Elctd Row or Col Pitch" is narrow.
02200744 The electrode-to-electrode distance is short.
02200751 "Missing Start Row or Col" in "Elctd Group 1" is large.
02200752 "Missing Start Row or Col" in "Elctd Group 2" is large.
02200753 "Missing Start Row or Col" in "Elctd Group 3" is large.
02200754 "Missing Start Row or Col" in "Elctd Group 4" is large.
02200755 "Missing Start Row or Col" in "Elctd Group 5" is large.
02200756 "Missing Start Row or Col" in "Elctd Group 6" is large.
02200757 "Missing Start Row or Col" in "Elctd Group 7" is large.
02200758 "Missing Start Row or Col" in "Elctd Group 8" is large.
02200759 "Missing Start Row or Col" in "Elctd Group 9" is large.
0220075a "Missing Start Row or Col" in "Elctd Group 10" is large.
0220075b "Missing Start Row or Col" in "Elctd Group 11" is large.
0220075c "Missing Start Row or Col" in "Elctd Group 12" is large.
0220075d "Missing Start Row or Col" in "Elctd Group 13" is large.
0220075e "Missing Start Row or Col" in "Elctd Group 14" is large.
0220075f "Missing Start Row or Col" in "Elctd Group 15" is large.
02200760 "Missing Start Row or Col" in "Elctd Group 16" is large.
02200761 "Missing Start Row or Col" in "Elctd Group 17" is large.
02200762 "Missing Start Row or Col" in "Elctd Group 18" is large.
02200763 "Missing Start Row or Col" in "Elctd Group 19" is large.
02200764 "Missing Start Row or Col" in "Elctd Group 20" is large.
02200765 "Missing Start Row or Col" in "Elctd Group 21" is large.
02200766 "Missing Start Row or Col" in "Elctd Group 22" is large.
02200767 "Missing Start Row or Col" in "Elctd Group 23" is large.
02200768 "Missing Start Row or Col" in "Elctd Group 24" is large.
02200769 "Missing Start Row or Col" in "Elctd Group 25" is large.
0220076a "Missing Start Row or Col" in "Elctd Group 26" is large.
0220076b "Missing Start Row or Col" in "Elctd Group 27" is large.
0220076c "Missing Start Row or Col" in "Elctd Group 28" is large.
4OM-1603
4-6
3. Recognition Error IDs and Remedial Procedures : Chap.4
1012-005
Recognition Error ID Description of Recognition Error
0220076d "Missing Start Row or Col" in "Elctd Group 29" is large.
0220076e "Missing Start Row or Col" in "Elctd Group 30" is large.
02200771 "Elctd#ofRowsor#ofCols"in"ElctdGroup1"isnotsufcient.
02200772 "Elctd#ofRowsor#ofCols"in"ElctdGroup2"isnotsufcient.
02200773 "Elctd#ofRowsor#ofCols"in"ElctdGroup3"isnotsufcient.
02200774 "Elctd#ofRowsor#ofCols"in"ElctdGroup4"isnotsufcient.
02200775 "Elctd#ofRowsor#ofCols"in"ElctdGroup5"isnotsufcient.
02200776 "Elctd#ofRowsor#ofCols"in"ElctdGroup6"isnotsufcient.
02200777 "Elctd#ofRowsor#ofCols"in"ElctdGroup7"isnotsufcient.
02200778 "Elctd#ofRowsor#ofCols"in"ElctdGroup8"isnotsufcient.
02200779 "Elctd#ofRowsor#ofCols"in"ElctdGroup9"isnotsufcient.
0220077a "Elctd#ofRowsor#ofCols"in"ElctdGroup10"isnotsufcient.
0220077b "Elctd#ofRowsor#ofCols"in"ElctdGroup11"isnotsufcient.
0220077c "Elctd#ofRowsor#ofCols"in"ElctdGroup12"isnotsufcient.
0220077d "Elctd#ofRowsor#ofCols"in"ElctdGroup13"isnotsufcient.
0220077e "Elctd#ofRowsor#ofCols"in"ElctdGroup14"isnotsufcient.
0220077f "Elctd#ofRowsor#ofCols"in"ElctdGroup15"isnotsufcient.
02200780 "Elctd#ofRowsor#ofCols"in"ElctdGroup16"isnotsufcient.
02200781 "Elctd#ofRowsor#ofCols"in"ElctdGroup17"isnotsufcient.
02200782 "Elctd#ofRowsor#ofCols"in"ElctdGroup18"isnotsufcient.
02200783 "Elctd#ofRowsor#ofCols"in"ElctdGroup19"isnotsufcient.
02200784 "Elctd#ofRowsor#ofCols"in"ElctdGroup20"isnotsufcient.
02200785 "Elctd#ofRowsor#ofCols"in"ElctdGroup21"isnotsufcient.
02200786 "Elctd#ofRowsor#ofCols"in"ElctdGroup22"isnotsufcient.
02200787 "Elctd#ofRowsor#ofCols"in"ElctdGroup23"isnotsufcient.
02200788 "Elctd#ofRowsor#ofCols"in"ElctdGroup24"isnotsufcient.
02200789 "Elctd#ofRowsor#ofCols"in"ElctdGroup25"isnotsufcient.
0220078a "Elctd#ofRowsor#ofCols"in"ElctdGroup26"isnotsufcient.
0220078b "Elctd#ofRowsor#ofCols"in"ElctdGroup27"isnotsufcient.
0220078c "Elctd#ofRowsor#ofCols"in"ElctdGroup28"isnotsufcient.
0220078d "Elctd#ofRowsor#ofCols"in"ElctdGroup29"isnotsufcient.
0220078e "Elctd#ofRowsor#ofCols"in"ElctdGroup30"isnotsufcient.
02200791 Electrode Shape = Proper recognition data corresponded to the rectangle was
not set.
02200792 Electrode Shape = Proper recognition level corresponded to the rectangle was
not set.
02200793 This algorithm cannot be applicable to the rectangle in the electrode shape.
02200794 the electrodes are not set as all of them have the same shape.
02200801 "# of Groups" (form data) is improper.
02200802 Totalsof"thenumberofform"isnotsufcient.
02200803 No detection is set in all "Form Insp Condtn" text boxes.
02200804 "Direction of shape" of the edge shape is all parallel.
02200805 "Width of shape" is small.
02200806 "Height of shape" is small.
02200807 "Shape pitch" is small.
02200808 The interval of shape is narrow.
