4OM-1603
3-141
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
601302 Noz stocker offset teaching
Error of XY-axis movement
-----
601303 Noz stocker offset teaching
Time-out in XY-axis movement
-----
601304 Noz stocker offset teaching
Error of HL-axis movement
-----
601305 Noz stocker offset teaching
Error of NL-axis movement
-----
601306 Noz stocker offset teaching
Error of L-axis movement
-----
601307 Noz stocker offset teaching
Error of HL/NL/L-axis movement
-----
601308 Noz stocker offset teaching
Nozzle stocker is not clamped
-----
601309 Noz stocker offset teaching
Error of Lighting On of P.C.B. Recognition Camera
-----
60130a Noz stocker offset teaching
Timeout of Lighting On of P.C.B. Recognition Camera
-----
60130b Noz stocker offset teaching
Error of Lighting Off of P.C.B. Recognition Camera
-----
60130c Noz stocker offset teaching
Time-out of Lighting Off of P.C.B. Recognition Camera
-----
60130d Noz stocker offset teaching
Error of image capture of Nozzle Stocker Mark
-----
60130e Noz stocker offset teaching
Time-out of image capture of Nozzle Stocker Mark
-----
60130f Noz stocker offset teaching
Error of Recognition Performance of Nozzle Stocker Mark
-----
601310 Noz stocker offset teaching
Time-out of Recognition Performance of Nozzle Stocker Mark
-----
4OM-1603
3-142
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
601311 Noz stocker offset teaching
Error of output-movement of Nozzle Stocker
-----
601401 TeachingComp.Recog.CameraMagnicationTeach
Time-out of communication with recognition.
Is there Network with Recognition? Please check.
601402 TeachingComp.Recog.CameraMagnicationTeach
Error of Recognition Command response
-----
601a01 Linear measure sensor correction re-teach
The linear measure reading is abnormal.
Pleaseconrmwhetherthenozzlehasadheredtotheposition.
601a02 Linear measure sensor correction re-teach
Offset correction can not be completed. Please use the big nozzle(HA05) teach
again and adjust the light & receive optical Axis
-----
601a03 Linear measure sensor correction re-teach
Nozzle can not be detected.
-----
601a04 Linear measure sensor correction re-teach
Line Sensor Control is abnormal.
-----
601a05 Linear measure sensor correction re-teach
Offset correction can not be completed. Please use the big nozzle(HA05) teach
again and adjust the light & receive optical Axis(All samples are E/R-Err7)
-----
601a06 Linear measure sensor correction re-teach
Offset correction can not be completed. Please use the big nozzle(HA05) teach
again and adjust the light & receive optical Axis(All samples are E/NR-Err8)
Offset correction can not be completed. Please use the big nozzle(HA05) teach
-----
601a07 Linear measure sensor correction re-teach
again and adjust the light & receive optical Axis(Edge detect error-Err9)
-----
601a08 Linear measure sensor correction re-teach
Offset correction can not be completed. Please use the big nozzle(HA05) teach
againandadjustthelight&receiveopticalAxis(Insufcientsamples-Err10)
-----
601a09 Linear measure sensor correction re-teach
Offset correction can not be completed. Please use the big nozzle(HA05) teach
againandadjustthelight&receiveopticalAxis(Insufcientcorrectingsamples-
Err14)
-----
601a0a Linear measure sensor correction re-teach
Offset correction can not be completed. Please use the big nozzle(HA05) teach
again and adjust the light & receive optical Axis(Fail to create correction-Err15)
-----
4OM-1603
3-143
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
601a0b Linear measure sensor correction re-teach
Offset correction can not be completed. Please use the big nozzle(HA05) teach
again and adjust the light & receive optical Axis(Accuracy check NG-Err16)
-----
601a0c Linear measure sensor correction re-teach
Offset correction can not be completed. Please use the big nozzle(HA05) teach
again and adjust the light & receive optical Axis(Fail to save-Err17)
-----
601a0d Linear measure sensor correction re-teach
The measurement value of the nozzle is not within 0.2mm to 0.6mm.
Adjust the height of the linear measure sensor otherwise, replace it.
601a0e Linear measure sensor correction re-teach
The linear measure control has an error.(err2, err3)
All E/NR Error. There is a possibility that Light Emitter or Receiver is broken.
601a0f Linear measure sensor correction re-teach
The linear measure control has an error.(err1)
Could be P.C.B. Error
601a10 Linear measure sensor correction re-teach
The linear measure control has an error.(err4)
A quantity of light emitter is dropping. There is a possibility of Light Emitter broken.
601a11 Linear measure sensor correction re-teach
No strobe response
PleaseconrmthewiringofHLS.Either,conrmP.C.B.address.
601f01 NL Axis offset teach
Error before Line Sensor measurement began
-----
601f02 NL Axis offset teach
ODD Noz is placed on Head, or error is detected during linear measure sensor.
-----
601f03 NL Axis offset teach
Error of NS-axis movement
-----
601f04 NL Axis offset teach
Error of DD-axis movement
-----
601f05 NL Axis offset teach
Error of NL-axis movement
-----
601f06 NL Axis offset teach
Error of DD/NS-axis movement
-----
601f07 NL Axis offset teach
Time-out when Line Sensor measurement began
-----
601f08 NL Axis offset teach
Read Time-out of Line Sensor measurement
-----
