4OM-1603
2-16
2. Management Information : Chap.2
1109-006
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
030502 Misidenticationatypeofmulti-tray
TheconnectedTrayunit(Block2)doesn'tmatchsetupofDevice.Pleaseconrma
type of tray unit, and set it on Unit Exchange Screen.
030601 ConrmationofthepositionofNozStocker
Cannot use Noz stocker from the second to the forth line when full tray is used.
Please set the location of Noz stocker of Device (Block1) on Unit exchange
Screen.
030602 ConrmationofthepositionofNozStocker
Cannot use Noz stocker from the second to the forth line when full tray is used.
Please set the location of Noz stocker of Device (Block2) on Unit exchange
Screen.
030603 ConrmationofthepositionofNozStocker
Cannot use Noz stocker from the second to the forth line when full tray is used.
PleaseconrmthelocationofNozstockerofDevice(Block1).
030604 ConrmationofthepositionofNozStocker
Cannot use Noz stocker from the second to the forth line when full tray is used.
PleaseconrmthelocationofNozstockerofDevice(Block2).
030701 Conrmationof2DBarcodeData
MarkNo.ofOperatingParameter/2DBarCodedataisspeciedasAllSkip(0).
Please specify proper Mark No.
030801 Detect nozzle coming off multi-functional stocker
Machine (Block1) Detected that nozzle has come off the multi-functional stocker
of the 1st line.
030802 Detect nozzle coming off multi-functional stocker
Machine (Block1) Detected that nozzle has come off the multi-functional stocker
of the 4th line.
030803 Detect nozzle coming off multi-functional stocker
Machine (Block2) Detected that nozzle has come off the multi-functional stocker
of the 1st line.
030804 Detect nozzle coming off multi-functional stocker
Machine (Block2) Detected that nozzle has come off the multi-functional stocker
of the 4th line.
030901 Head nozzle dropped detect
Please lock the main safety cover. Please perform all-zeroing when the main
safety cover has already been locked.
050201 ConrmationofP.C.B.existence
Remove PCB from the conveyor. Please delete the PCB memory information on
the edit screen if it remains.
050202 ConrmationofP.C.B.existence
PCB is detected from Input position when Finish mode is set [Output].
Please PCB from conveyor.
050203 ConrmationofP.C.B.existence
PCB is detected from Output position when Finish mode is set [Input].
Please PCB from conveyor.
050204 ConrmationofP.C.B.existence
PCB is detected from Inlet sensor of input conveyor. Please remove PCB.
4OM-1603
2-17
2. Management Information : Chap.2
1109-006
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
050205 ConrmationofP.C.B.existence
The operation mode of Lane A is set [STOP].
Please remove P.C.B. when not transferred.
050206 ConrmationofP.C.B.existence
The operation mode of Lane B is set [STOP].
Please remove P.C.B. when not transferred.
050207 ConrmationofP.C.B.existence
There is a possibility that there are 2 sheets of PCB on the input conveyor. Please
remove PCB from Deceleration Sensor, or move it to Stop sensor, or delete the
PCB memory information.
050208 ConrmationofP.C.B.existence
There is a possibility that there are 2 sheets of PCB on the input conveyor in Lane
A. Please remove PCB from Deceleration Sensor, or move it to Stop sensor, or
delete the PCB memory information.
050209 ConrmationofP.C.B.existence
There is a possibility that there are 2 sheets of PCB on the output conveyor in
Lane B. Please remove PCB from Deceleration Sensor, or move it to Stop sensor,
or delete the PCB memory information.
05020a ConrmationofP.C.B.existence
There is a possibility that there are 2 sheets of PCB on the shuttle conveyor in
input side. Please remove PCB from Deceleration Sensor, or move it to Stop
sensor, or delete the PCB memory information.
05020b ConrmationofP.C.B.existence
There is a possibility that there are 2 sheets of PCB on the shuttle conveyor in
output side. Please remove PCB from Deceleration Sensor, or move it to Stop
sensor, or delete the PCB memory information.
05020c ConrmationofP.C.B.existence
There is PCB on the input sensor of Lane A.
Please return PCB to the input conveyor and run it.
05020d ConrmationofP.C.B.existence
There is PCB on the input sensor of Lane B.
Please return PCB to the input conveyor and run it.
05020e ConrmationofP.C.B.existence
There is PCB on the input sensor.
Please return PCB to the input conveyor and run it.
05020f ConrmationofP.C.B.existence
There is no PCB in the machine. Please position a PCB.
050210 ConrmationofP.C.B.existence
Please put PCB on the positioning conveyor, and start it.
050211 ConrmationofP.C.B.existence
Please remove PCB from input position.
Cutout PCB cannot be transferred from input position.
050212 ConrmationofP.C.B.existence
Please remove the substrate at the upstream position.
The substrate for weight to exceed 2.5kg cannot be transported simultaneously.
4OM-1603
2-18
2. Management Information : Chap.2
1109-006
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
050213 ConrmationofP.C.B.existence
Please remove the substrate at A lane upstream position.
The substrate for weight to exceed 2.5kg cannot be transported simultaneously.
050214 ConrmationofP.C.B.existence
Please remove the substrate at B lane upstream position.
The substrate for weight to exceed 2.5kg cannot be transported simultaneously.
050301 ConrmationofFirmwareversion
Firmware of transfer driver is not the latest version. Please update it.
050401 Manual transfer
P.C.B. (X>260mm) which is set by PP data is unable to take Input Position.
050402 Manual transfer
Please operate after removing P.C.B. from output conveyor. There is a possibility
of pushing and rising with Stopper.
050403 Manual transfer
It is impossible to take from Sensor Detection of Input Position.
Please put P.C.B. on Input Conveyor, or move it to Output position in Recovery
Menu.
050404 Manual transfer
PCB (X>260mm) which is set by PP data is unable to be taken in Input Conveyor.
050405 Manual transfer
There is PCB on Deceleration Sensor of Input Conveyor. There is a possibility that
PCB is inserted.
050406 Manual transfer
There is PCB on Deceleration Sensor of Shuttle Conveyor in Output side. There
is a possibility that PCB is inserted.
050407 Manual transfer
Lane A is not able to be set in Current Program. Please change Current Program
or change to Lane B.
050408 Manual transfer
Lane B is not able to be set in Current Program. Please change Current Program
or change to Lane A.
050409 Manual transfer
PCB Y size and Conveyor Width in Current Program are not equal. Please change
Current Program.
05040a Manual transfer
Cutout PCB cannot be taken in input position.
05040b Manual transfer
Please remove PCB from input position.
Cutout PCB cannot be transferred from input position.
05040c Manual transfer
Itisnotpossibletotransportittothespeciedposition.
05040d Manual transfer
It is not possible to operate because it interferes in the adsorption treatment
device.
05040e Manual transfer
It composes the device, and it is not possible to operate.
