4OM-1603
3-14
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
401B01 Feeder Opening Sensor(Block2)
The feeder opening sensor (Block2) was shaded. [B****]
Please remove the factor which is shading the feeder opening sensor (Block2),
and carry out zero return.
401C01 Detecting Feeder Disengaged Latch(Block1)
Disengaged Latch(Block1) was detected.
1. Open the cover.
2. Conrmsuppressor,DisengagedLatchandremovethePickupmisscmpnt.
3. Close the cover and then Lock it.
401D01 Detecting Feeder Disengaged Latch(Block2)
Disengaged Latch(Block2) was detected.
1. Open the cover.
2. Conrmsuppressor,DisengagedLatchandremovethePickupmisscmpnt.
3. Close the cover and then Lock it.
401E01 Cancelling the safety cover lock
The safety cover lock was released.
Close the safety cover and lock it.
401F01 Detecting interlock of Head1
Head1 interlock was detected.
Please perform a zeroing.
402001 Detecting interlock of Head2
Head2 interlock was detected.
Please perform a zeroing.
402101 Detecting air pressure down
Air pressure down was detected.
Check air pipe came off or bend, air compressor.
402201 Vacuum pump stop
Circuit breaker of Vacuum pomp was tripped.
Check vacuum pump and wiring.
402301 Beam1 Breaker Off
Circuit breaker of XY Beam1 was tripped.
Checkservoamplierandcables.
402401 Beam2 Breaker Off
Circuit breaker of XY Beam2 was tripped.
Checkservoamplierandcables.
402501 Over squeeze1 detected (Head1)
Over squeeze1 detected (Head1)[B05]
-----
402601 Over squeeze2 detected (Head1)
Over squeeze2 detected (Head1)[B05]
-----
402701 Over squeeze3 detected (Head1)
Over squeeze3 detected (Head1)[B05]
-----
402801 Pass Line1 Detected(Head1)
Pass Line1 detected(Head1)[B04]
-----
4OM-1603
3-15
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
402901 Pass Line2 Detected(Head1)
Pass Line2 detected(Head1)[B04]
-----
402A01 Pass Line3 Detected(Head1)
Pass Line3 detected(Head1)[B04]
-----
402B01 Nozzleoatup1detected(Block1)
Nozzleoatup1detected(Block1)[B1611]
ConrmNozzleofNozzleStocker1(Block1).
402C01 Nozzleoatup2detected(Block1)
Nozzleoatup1detected(Block1)[B1611]
ConrmNozzleofNozzleStocker2(Block1).
402D01 Over squeeze1 detected (Head2)
Over squeeze1 detected (Head2)[B05]
-----
402E01 Over squeeze2 detected (Head2)
Over squeeze2 detected (Head2)[B05]
-----
402F01 Over squeeze3 detected (Head2)
Over squeeze3 detected (Head2)[B05]
-----
403001 Pass Line1 Detected(Head2)
Pass Line1 detected(Head2)[B04]
-----
403101 Pass Line2 Detected(Head2)
Pass Line2 detected(Head2)[B04]
-----
403201 Pass Line3 Detected(Head2)
Pass Line3 detected(Head2)[B04]
-----
403301 Nozzleoatup1detected(Block2)
Nozzleoatup1(Block2)detected[B1611]
ConrmNozzleofNozzleStocker1(Block2).
403401 Nozzleoatup2detected(Block2)
Nozzleoatup2(Block2)detected[B1611]
ConrmNozzleofNozzleStocker2(Block2).
403501 Detecting Emergency stop (Block1)
Emergency stop(Block1) is detected
Drive after the power turns on.
403601 Tray Safety Door(Lower)(Block1)
Safety door (lower) of tray feeder unit opened.(Block1)[S0501]
Close the safety door(Lower) and operate it.
403701 Tray Safety Door(Upper)(Block1)
Safety door (upper) of tray feeder unit opened.(Block1)[S0502]
Close the safety door(Center) and operate it.
4OM-1603
3-16
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
403801 Tray Safety Door(Center)(Block1)
Safety door (center) of tray feeder unit opened.(Block1)[S0503]
Close the safety door(Upper) and operate it.
403901 Pallet Chuck Claw(Block1)
Chucking lever of pallet opened while elevator is moving.(Block1)
[B15407, B15408]
Check out detecting Sensor (B15407, B15408) of closing Chucking lever of pallet.
403A01 Palletyingaway(Block1)
Thepalletyingawaywhileelevatorismoving.(Block1)[B15406]
Check out detecting sensor (B15406) of breaking out Pallet and position of Pallet.
403B01 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Detect pickup miss components on the pallet. (Block1)[B15417]
Please open the main cover and remove pickup miss components on the pallet.
403C01 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Detect pickup miss components on the pallet. (Block1)[B15418]
Please open the main cover and remove the pickup miss components on tray
pallet.
403D01 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Detect pickup miss components on the pallet. (Block1)[B15419]
Please open the main cover and remove the pickup miss components on tray
pallet.
403E01 Detecting Lower Magazine rack shutter (Block1)
Open the rack shutter while lower elevator is moving.(Block1)[B15521][B15523]
[B15525]
Check out the sensor (B15521, B15523, B15525) of closing magazine rack
shutter.
403F01 Detecting Upper Magazine rack shutter (Block1)
Open the rack shutter while upper elevator is moving.(Block1)[B15527][B15529]
[B15531]
Check out the sensor (B15527, B15529, B15531) of closing magazine rack
shutter.
404001 Lower magazine positioning error(Block1)
Lower magazine positioning error(Block1) [B15526]
Check Magazine Clamp.
404101 Upper magazine positioning error(Block1)
Upper magazine positioning error.(Block1) [B15532]
Check Magazine Clamp.
404201 Shut-off Motor Breaker for Tray (Block1)
Tripped circuit breaker of motor (Block1).
Please turn on again after turning off and cancelling Trip mode.
404301 Shut-off safety relay of Elevator(Lower) (Block1)
Cut off safety relay of lower elevator (Block1).
Check the main circuit and safety door.
404401 Shut-off safety relay of Elevator(Upper) (Block1)
Cut off safety relay of upper elevator (Block1).
Check the main circuit and safety door.
