4OM-1603
2-8
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
015007 Nozzle Location Check
The different type nozzle is already set(Head1).
Please remove it.
015008 Nozzle Location Check
The different type nozzle is already set(Head2).
Please remove it.
015009 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Set type "FF01"or "FF02" nozzle as Nozzle2 on Head.
01500A Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Set type "FF01"or "FF02" nozzle as Nozzle2 on Head.
01500B Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Set type "VF02" nozzle on calibrate position.
01500C Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Set type "VF02" nozzle on Head.
01500D Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Set type "HA09" or "VF02" nozzle on Head.
01500E Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Set type "HA09" or "VF02" nozzle on Head.
01500F Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Please set type "HA09" nozzle in the stocker position where nozzle can change.
015010 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Please set type "HA09" nozzle in the stocker position where nozzle can change.
015011 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Please set type "FF01" or "FF02" nozzle in the stocker position where nozzle can
change.
015012 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Please set type "FF01" or "FF02" nozzle in the stocker position where nozzle can
change.
015013 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Please set type "BF02" nozzle in the stocker position where nozzle can change.
015014 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Please set type "BF02" nozzle in the stocker position where nozzle can change.
1109-006
4OM-1603
2-9
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
015015 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).
Please set type "FA04" nozzle in the stocker position where nozzle can change.
015016 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).
Please set type "FA04" nozzle in the stocker position where nozzle can change.
015017 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head1).Pleasesettype"BF02"or"HA09"
nozzle in the stocker position where nozzle can change.
015018 Nozzle Location Check
NotfoundttingnozzleforTeaching(Head2).Pleasesettype"BF02"or"HA09"
nozzle in the stocker position where nozzle can change.
015101 Nozzle location teaching, check the position of nozzle on head
No found nozzle (Head1). Or, the different Nozzle could be arranged.
015102 Nozzle location teaching, check on the position of nozzle on head
No found nozzle (Head2). Or, the different Nozzle could be arranged.
015201 Teaching check the conveyor
No P.C.B. on Conveyor. Please put P.C.B. in.
015202 Teaching check the conveyor
Please set P.C.B. positioning. Please set it again after cancel positioning if P.C.B.
positioning is already done.
015203 Teaching check the conveyor
Please push Conveyor Width Moving.
015301 ODD Head Nozzle stocker check
There does not exist stocker that can replace nozzle (Block1).
015302 ODD Head Nozzle stocker check
There does not exist stocker that can replace nozzle (Block2).
016001 Tray teaching
Traverse of Tray is not drawn out (Block1). Draw out Traverse.
016002 Tray teaching
Tray Traverse is not drawn out (Block2). Draw out Traverse.
016101 Coplanarity Teaching
"Coplanarity Detection" of Test Operation Mode is set "No". Execute it after
cancelling Test Operation Mode.
016201 Coplanarity Test
Please pickup part.
017009 Teaching Check on the position of Glass jig
Not found Glass Jig for Teaching. Please check that Glass Jig is set in its position.
017201 Nozzle set-up (Block1)
Nozzle Placement/Store mode of Stocker(Block2) is not possible to operate.
Please specify Stocker(Block1).
017202 Nozzle set-up (Block1)
High nozzle cannot be stored while Odd nozzle is placed. Please restart after
returning all Odd Nozzle.
1109-006
4OM-1603
2-10
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
017203 Nozzle set-up (Block1)
High nozzle cannot be stored while Odd nozzle is placed. Please restart after
returning all Odd Nozzle.
017204 Nozzle set-up (Block1)
Because of interference with Nozzle which is already placed, it cannot be placed.
Do not place Nozzle in the front and rear of two Odd nozzle placed.
017205 Nozzle set-up (Block1)
Placement/Storeisimpossibleinthepositionforthespeciedstocker.
017206 Nozzle set-up (Block1)
It is impossible to place it because of interfering in the placed nozzle. Please do
not place a nozzle before or after placing ODD nozzle.
017301 Nozzle set-up (Block2)
Nozzle Placement/Store mode of Stocker(Block1) is not possible. Please set
Stocker (Block2).
017302 Nozzle set-up (Block2)
High nozzle cannot be stored while Odd nozzle is placed. Please restart after
returning all Odd Nozzle.
017303 Nozzle set-up (Block2)
High nozzle cannot be stored while Odd nozzle is placed. Please restart after
returning all Odd Nozzle.
017304 Nozzle set-up (Block2)
Because of interference with Nozzle which is already placed, it cannot be placed.
Do not place Nozzle in the front and rear of two Odd nozzle placed.
017305 Nozzle set-up (Block2)
Placement/Storeisimpossibleinthepositionforthespeciedstocker.
017306 Nozzle set-up (Block2)
It is impossible to place it because of interfering in the placed nozzle. Please do
not place a nozzle before or after placing ODD nozzle.
017401 Button for inserting power
Can not supply power while Line Sensor program is on writing. Operate it after
writing completely.
017501 Operationmodesetconrmation
"Feeder Connection" or "Feeder Serial Communication" of Test Operation Mode is
set. Execute it after reset Operation Mode.
017601 Inching movement
Perform zeroing.
017602 Inching movement
Please push the Feeder Base Ready SW
017603 Inching movement
Close the safety door of multi-tray, and press the Ready button.
017604 Inching movement
The range is out of movable Range.
017605 Inching movement
HL-axis is fallen. There is a possibility of collision between Noz and axis.
Please perform zeroing of HL-axis or move it to origin position.
