4OM-1603

1-5

1. Outline of Maintenance : Chap.1

1.2.2 Preparation for Lubrication

Prepare for the specied types of grease and lubrication tools.

SpeciedGreases

•

DAPHNE EPONEX GREASE No. 1 (IDEMITSU KOSAN)

•

MOLYNOC GREASE AP1 (JX Nippon Oil & Energy)

•

BARRIERTA IEL/V (NOK Klueber CO.,Ltd.)

Note

Before lubrication, wipe off old grease. Otherwise, the effect of grease and oil

will decrease.

Same Types of Lubricants

•

Grease Types equivalent to DAPHNE EPONEX GREASE No. 1

(IDEMITSU KOSAN)

Grease Names Makers

Alvania Grease No. 1 Showa Shell Sekiyu K.K

Multinoc Grease 1 JX Nippon Oil & Energy

Jomo Lisonix Grease No. 1 JX Nippon Oil & Energy

Dynamax No. 1 COSMO OIL LUBRICANTS

Lithtan 1 Exxon Mobil Corporation

MP Grease No. 1 KYGNUS

Gemico MP-1 Tonen General Sekiyu K.K

Multemp PS1 KYODOH YUSHI CO., LTD.

T4A1

•

Grease Types equivalent to MOLYNOC GREASE AP1

(JX Nippon Oil & Energy)

Grease Names Makers

DAPHINE Grease M No. 1 Idemitsu Kosan Co., Ltd.

Jomo Lisonix Grease M No. 1 JX Nippon Oil & Energy

COSMO MOLYBDEN GREASE

No. 1

COSMO OIL LUBRICANTS

BEACON Q2 Exxon Mobil Corporation

Gemico MD2 Tonen General Sekiyu K.K

M5 GREASE 1 KYGNUS

T4A2

1109-003

4OM-1603

1-6

1. Outline of Maintenance : Chap.1

Speciedlubricationtools

(1) Brush

Use a brush whose bristles do not come off if possible.

Notice

Do not use a brush for ball screws and splines.

(2) Vinyl Gloves

Use a pair of vinyl gloves to apply grease or oil by hand.

(3) Hand Grease Gun

Standard

：

KH-120

Part No.

：

228A022

Maker

：

Yamada Corporation

Note

Use this gun only for DAPHNE EPONEX GREASE No. 1.

Reference

Refer to the attached instruction manuals for the hand grease gun for the

usage.

F4A4

•

Attachment for Hand Grease Gun KH-120

Standard Shape Part No. Remarks

Type N

216M0440 THK

Type H

216M0439 THK

Type U

216M0438 THK

Type P

0920H11Q THK

SPK-3C

228A0021

Yamada

Corporation

T4A4

Note

It is not attached to the machine. Purchase it separately if necessary.

1007-004

4OM-1603

1-7

1. Outline of Maintenance : Chap.1

(4) Syringe

Maker: TERUMO

This gun can be used for two types of greases.

Use the syringes and the nozzle properly.

Two Types of Greases : DAPHNE EPONEX GREASE No. 1

MOLYNOC GREASE AP1

Appearance

F4A5

Standard Shape Part No. Remarks

Syringe

228A0171

Maker : TERUMO

10ml SS-10-LZ

Nozzle No.18

(Color : Green)

216A0451

Maker : SAN-EI TECH

Inside Diameter :

0.84

Tapered Nozzle #5118TT-B

Nozzle No.19

(Color : Brown)

0916D108

Maker : NIPRO

Inside Diameter :

0.79

Length : 65 mm Flat End

Nozzle No.49

0916D712 Length : 145 mm

T4A5

1003-003
