4OM-1603 3-19 3. Error IDs and Remedial Procedures : Chap.3 1 109-001 Error ID Error Name, Description, Cause, and Remedy 406B01 Detecting pickup miss cmpnt on T ray Pallet (Block2) Pick-up miss cmpnt is detected on T ra…

100%1 / 379
4OM-1603
3-18
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
405201 Detecting upper Magazine rack shutter (Block2)
the rack shutter opening is detected during upper elevator moving.(Block2)
[B15527, B15529,B15531]
Check out the sensor of closing magazine rack shutter (B15527, B15529,
B15531).
405301 Lower magazine positioning error (Block2)
Lower magazine positioning error.(Block2)[B15526]
ConrmMagazineClamp.
405401 Upper magazine positioning error (Block2)
Upper magazine positioning error.(Block2)[B15532]
ConrmMagazineClamp.
405501 Shut-off Motor Breaker for Tray (Block2)
Tripped circuit breaker of motor (Block2)
Please turn on again after turning off and cancelling Trip mode.
405601 Shut-off safety relay of Elevator(Lower) (Block2)
Cut off safety relay of lower elevator (Block2).
Conrmthemaincircuitandsafetydoor.
405701 Shut-off safety relay of Elevator(Upper) (Block2)
Cut off safety relay of upper elevator (Block2).
Conrmthemaincircuitandsafetydoor.
405801 Released Elevator unit clamp(Block2)
Released elevator unit clamp(Block2)[B15426, B15428]
ConrmtheElevatorUnitClampSensor(B15426,B15428).
405901 Detecting pickup miss cmpnt of Tray Feeder Cart (Block2)
Pickup miss components was detected(Block2). [B15412]
1.Open the cover.
2.Conrmsuppressor,DisengagedLatchandremovethePickupmisscmpnt.
3.Close the cover and then lock it.
405A01 Detecting Feeder Disengaged Latch of Tray Feeder Cart(Block2)
Feeder Disengaged Latch is detected (Block2).[B15412]
1.Open the cover.
2.Conrmsuppressor,DisengagedLatchandremovethePickupmisscmpnt.
3.Close the cover and then lock it.
406701 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Pick-up miss cmpnt is detected on Tray pallet (Block1)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406801 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Pick-up miss cmpnt is detected on Tray pallet (Block1)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406901 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Pick-up miss cmpnt is detected on Tray pallet (Block1)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406A01 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Pick-up miss cmpnt is detected on Tray pallet (Block1)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
1109-006
4OM-1603
3-19
3. Error IDs and Remedial Procedures : Chap.3
1109-001
Error ID Error Name, Description, Cause, and Remedy
406B01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pick-up miss cmpnt is detected on Tray pallet (Block2)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406C01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pick-up miss cmpnt is detected on Tray pallet (Block2)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406D01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pick-up miss cmpnt is detected on Tray pallet (Block2)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406E01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pick-up miss cmpnt is detected on Tray pallet (Block2)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
407001 Detecting Head1 nozzle descending
Invalid detection of head1 nozzle descending
Please perform a zeroing.
407101 Detecting Head2 nozzle descending
Invalid detection of head2 nozzle descending
Please perform a zeroing.
407201 Pass Line detect(Head1)
Invalid detection of Pass line(Head1)
Please perform a zeroing.
407301 Pass Line detect(Head2)
Invalid detection of Pass line(Head2)
Please perform a zeroing.
408001 Nozzle interference detect adjacent to multi-functional head
Emergency stopped a head because a nozzle adjacent to it interfered.
Please perform a zeroing.
408301 Feeder opening sensor (Block 1) detect
The feeder opening sensor (Block 1) was shaded.
-----
408401 Feeder opening sensor (Block 2) detect
The feeder opening sensor (Block 2) was shaded.
-----
T4C3
4OM-1603
3-20
3. Error IDs and Remedial Procedures : Chap.3
1012-005
3.2 Data
Error ID Error Name, Description, Cause, and Remedy
410301 Pattern Program Error
Steps in converted pattern program is more
-----
410302 Pattern Program Error
There are Errors in converted pattern program(PCB recog steps Error.)
-----
410303 Pattern Program Error
The converted pattern program is not exist, the data is damaged.
-----
410304 Pattern Program Error
The error is found in the adsorption nozzle number of the conversion pattern
program.
-----
410305 Pattern Program Error
The error is found in the order of adsorption of the conversion system pattern
program.
-----
410306 Pattern Program Error
The error is found in the nozzle candidate number of the conversion pattern
program.
-----
410307 Pattern Program Error
The error is found in the adsorption lane number of the conversion pattern
program.
-----
410401 Data Error
The components library does not exist. Or, data is in loss.
-----
410402 Data Error
Data relating to nozzle does not exist. Or, data is in loss.
-----
410701 Program Error
It was a error setting of the sequence data.
-----
410801 2D bar code data Error
It was a error setting of the sequence data.
-----
410802 2D bar code data Error
Failed in start-up Sequence
-----
410803 2D bar code data Error
The error is found in coordinates calculation.
-----
