4OM-1603
3-66
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
441103 Tray Pallet Returning Error (Block2)
Elevator wave form setting error
-----
441104 Tray Pallet Returning Error (Block2)
Elevator operating error
-----
441201 Tray Pallet Returning Error (Block2)
Traverse pre-check error
-----
441202 Tray Pallet Returning Error (Block2)
Traverse movement position error
-----
441203 Tray Pallet Returning Error (Block2)
Traverse wave form setting error
-----
441204 Tray Pallet Returning Error (Block2)
Traverse operating error
-----
441206 Tray Pallet Returning Error (Block2)
No palette when the return begins.(B15411)
-----
441301 Tray Pallet Draw out Error (Block2)
Elevator pre-check error
-----
441302 Tray Pallet Draw out Error (Block2)
Elevator movement position error
-----
441303 Tray Pallet Draw out Error (Block2)
Elevator wave form setting error
-----
441304 Tray Pallet Draw out Error (Block2)
Elevator operating error
-----
441305 Tray Pallet Draw out Error (Block2)
Elevator abnormal stop
-----
441401 Tray Pallet Draw out Error (Block2)
Traverse pre-check error
-----
441402 Tray Pallet Draw out Error (Block2)
Traverse movement position error
-----
441403 Tray Pallet Draw out Error (Block2)
Traverse wave form setting error
-----
4OM-1603
3-67
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
441404 Tray Pallet Draw out Error (Block2)
Traverse operating error
-----
441405 Tray Pallet Draw out Error (Block2)
Traverse operating error
-----
441406 Tray Pallet Draw out Error (Block2)
No palette when drawing out begins. (B0511)
-----
441407 Tray Pallet Draw out Error (Block2)
Cannot detect the pallet to pull out(B15505, B15506)
Pleaseconrmwhetherthepalletinthemagazineissetproperly.Ifso,adjustthe
sensor, please.
441501 Move to Tray Elevator supply/exchange position error (Block2)
Elevator pre-check error
-----
441502 Move to Tray Elevator supply/exchange position error (Block2)
Elevator movement position error
-----
441504 Move to Tray Elevator supply/exchange position error (Block2)
Elevator operating error
-----
441602 Tray Feeder Zeroing Error (Block2)
Tray feeder zeroing Servo ON error
-----
441603 Tray Feeder Zeroing Error (Block2)
Traverse pallet search error
-----
441604 Tray Feeder Zeroing Error (Block2)
Elevator zeroing error
-----
441605 Tray Feeder Zeroing Error (Block2)
Elevator zeroing error
-----
441606 Tray Feeder Zeroing Error (Block2)
The palette was detected though there was no draw out history.
-----
441607 Tray Feeder Zeroing Error (Block2)
Elevator return steps movement error
-----
441608 Tray Feeder Zeroing Error (Block2)
Traverse pallet store error
-----
441609 Tray Feeder Zeroing Error (Block2)
Elevator zeroing pre-check error
-----
4OM-1603
3-68
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
44160a Tray Feeder Zeroing Error (Block2)
Pallet chuck close error
-----
44160b Tray Feeder Zeroing Error (Block2)
Rack shutter CLOSE error
-----
44160c Tray Feeder Zeroing Error (Block2)
Elevator zeroing error
-----
44160d Tray Feeder Zeroing Error (Block2)
EV1 step logs and step movement error
-----
44160e Tray Feeder Zeroing Error (Block2)
Ev2 step logs and step movement error
-----
44160f Tray Feeder Zeroing Error (Block2)
Traverse zeroing error
-----
441610 Tray Feeder Zeroing Error (Block2)
Traverse zeroing pre-check error
-----
441611 Tray Feeder Zeroing Error (Block2)
Pallet chuck CLOSE error
-----
441613 Tray Feeder Zeroing Error (Block2)
Pallet chuck OPEN error
-----
441614 Tray Feeder Zeroing Error (Block2)
Traverse recede operation error
-----
441615 Tray Feeder Zeroing Error (Block2)
The palette was not detected though there was a draw out history.
-----
441616 Tray Feeder Zeroing Error (Block2)
Rack shutter OPEN error(Upper Magazine)
-----
441617 Tray Feeder Zeroing Error (Block2)
Rack shutter OPEN error(Lower Magazine)
-----
441618 Tray Feeder Zeroing Error (Block2)
The other pallet was detected from pallet store position during pulling.
-----
441619 Tray Feeder Zeroing Error (Block2)
Traverse zeroing error
-----
