4OM-1603

3-134

3. Error IDs and Remedial Procedures : Chap.3

1109-006

Error ID Error Name, Description, Cause, and Remedy

600401 Head Rotate center offset teach

Can not recognize Glass Jig

PleaseconrmthatGlassJigissetonGlassJigplace.(Checkitbecausethereis

a possibility that nozzle is not on head, or vacuum is not "ON".)

600402 Head Rotate center offset teach

Error of Recognition Command response.

-----

600403 Head Rotate center offset teach

Error of coordinates calculation.

-----

600404 Head Rotate center offset teach

Error when Jig pickup began

-----

600405 Head Rotate center offset teach

Error in the movement of Jig pickup

-----

600406 Head Rotate center offset teach

Error when Jig store began

-----

600407 Head Rotate center offset teach

Error in the movement of Jig store

-----

600408 Head Rotate center offset teach

Error when HL-axis and NL-axis began zeroing.

-----

600409 Head Rotate center offset teach

Error while HL-axis and NL-axis are on zeroing

-----

60040a Head Rotate center offset teach

Error when DD-axis began to rotate

-----

60040b Head Rotate center offset teach

Error while DD-axis is rotating

-----

60040c Head Rotate center offset teach

Error of Data set for XY Beam.

-----

60040d Head Rotate center offset teach

Error of moving for XY Beam.

-----

60040e Head Rotate center offset teach

Time-out in XY Beam

-----

60040f Head Rotate center offset teach

Time-out of communication with recognition

-----

4OM-1603

3-135

3. Error IDs and Remedial Procedures : Chap.3

1109-006

Error ID Error Name, Description, Cause, and Remedy

600410 Head Rotate center offset teach

Error when L-axis began zeroing

-----

600411 Head Rotate center offset teach

Error while L-axis is on zeroing

-----

600412 Head Rotate center offset teach

Error when Z-axis began to rotate

-----

600413 Head Rotate center offset teach

Error while Z-axis is rotating

-----

600414 Head Rotate center offset teach

Error when L-axis began to drop

-----

600415 Head Rotate center offset teach

Error when L-axis is dropping

-----

600416 Head Rotate center offset teach

-----

600501 Reference mark position teach

Could not recognize Glass Jig in CTR Fly Recognition.

PleaseconrmthatGlassJigissetonGlassJigplace.(Checkitbecausethereis

a possibility that nozzle is not on head, or vacuum is not "ON".)

600502 Reference mark position teach

Error of Recognition Command response in case of CTR Fly Recognition

-----

600503 Reference mark position teach

Could not recognize Standard Mark

-----

600504 Reference mark position teach

Error of Recognition Command response in case of Standard Mark Recognition

-----

600505 Reference mark position teach

Error of coordinates calculation of CTR Fly Recognition

-----

600506 Reference mark position teach

Error when Jig pickup of CTR Fly Recognition began

-----

600507 Reference mark position teach

Error of the movement of Jig pickup of CTP Fly Recognition

-----

600508 Reference mark position teach

Error when Jig store of CTR Fly Recognition began

-----

4OM-1603

3-136

3. Error IDs and Remedial Procedures : Chap.3

1109-006

Error ID Error Name, Description, Cause, and Remedy

600509 Reference mark position teach

Error of the movement of Jig store of CTR Fly Recognition

-----

60050a Reference mark position teach

Error when HL-axis, NL-axis of CTR Fly Recognition began zeroing.

-----

60050b Reference mark position teach

Error while HL-axis, NL-axis of CTR Fly Recognition is zeroing.

-----

60050c Reference mark position teach

Error when DD-axis of CTR Fly Recognition began to rotate.

-----

60050d Reference mark position teach

Error while DD-axis of CTR Fly Recognition is rotating.

-----

60050e Reference mark position teach

Error of Data set for XY Beam of CTR Fly Recognition

-----

60050f Reference mark position teach

Error of moving for XY Beam.

-----

600510 Reference mark position teach

Time-out in XY Beam movement

-----

600511 Reference mark position teach

Time-out in communication with Recognition

-----

600512 Reference mark position teach

Error of coordinates calculation of Standard Mark Recognition

-----

600513 Reference mark position teach

Error of moving for XY Beam.

-----

600514 Reference mark position teach

Time-out in XY Beam movement

-----

600515 Reference mark position teach

Time out in communication with Recognition

-----

600601 Nozzle position offset teach

Could not recognize nozzle

PleaseconrmthatNozzleisplacedandexactNozzlearrangementdataisset.

600602 Nozzle position offset teach

Error of Recognition Command response.

-----
