4OM-1603
2-11
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
017606 Inching movement
L1-axis is fallen. There is a possibility of collision between Noz and axis.
Please perform zeroing of L1-axis or move it to origin position.
017607 Inching movement
L2-axis is fallen. There is a possibility of collision between Noz and axis.
Please perform zeroing of L2-axis or move it to origin position.
017608 Inching movement
L3-axis is fallen. There is a possibility of collision between Noz and axis.
Please perform zeroing of L3-axis or move it to origin position.
017701 Zeroing (set axis)
Push Ready SW of Feeder Base.
017702 Zeroing (set axis)
Close the safety door of multi-tray, and press the Ready button.
018001 Recycling Conveyor (Block1)
RecycleConveyor(Block1)islledup.
018002 Recycling Conveyor (Block1)
The connection of Recycling Conveyor (Block1) differs from Cmpnt Arranging
Data. Or, it has multi-connection.
018003 Recycling Conveyor (Block1)
Recycling Conveyor (Block1) is on ready.
Please change to Auto Opn Mode after it is done.
018101 Recycling Conveyor (Block2)
RecyclingConveyor(Block2)islledup.
018102 Recycling Conveyor (Block2)
The connection of Recycling Conveyor(Block2) differs from Cmpnt Arranging
Data. Or, it has multi-connection.
018103 Recycling Conveyor (Block2)
Recycling Conveyor (Block2) is on Ready. Please change to Auto Opn Mode after
it is done.
018201 Multi-tray (Block1)
Close the safety door of multi-tray, and press a button [READY] of it. When multi-
tray [READY] does not change to [ON], press the button [READY] of Feeder.
018202 Multi-tray (Block1)
Pallet of multi-tray is drawn out. Execute zeroing all, and store the pallet.
018203 Multi-tray (Block1)
Multi-tray breaking out was detected. Execute zeroing all, and store the pallet.
018204 Multi-tray (Block1)
Press [READY] button of Feeder base, and supply the power of multi-tray.
018205 Multi-tray (Block1)
Close the safety door(Center) of multi-tray, and press [READY] button.
018206 Multi-tray (Block1)
Close the safety door(Lower) of multi-tray, and press [READY] button.
018207 Multi-tray (Block1)
Close the safety door(Upper) of multi-tray, and press [READY] button.
018208 Multi-tray (Block1)
ZeroingofTraverse-axisisnotnished.Performzeroingofmulti-tray.
1109-006
4OM-1603
2-12
2. Management Information : Chap.2
1109-006
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
018209 Multi-tray (Block1)
ZeroingofElevator1-axisisnotnished.Performzeroingofmulti-tray.
01820a Multi-tray (Block1)
ZeroingofElevator2-axisisnotnished.Performzeroingofmulti-tray.
01820b Multi-tray (Block1)
Pickup miss cmpnt(8mm) is detected.[B15417]
01820c Multi-tray (Block1)
Pickup miss cmpnt(14mm) is detected.[B15418]
01820d Multi-tray (Block1)
Pickup miss cmpnt(28mm) is detected.[B15419]
01820e Multi-tray (Block1)
Pallet Chuck claw is open.
01820f Multi-tray (Block1)
Pallet Error is detected.
018210 Multi-tray (Block1)
Magazine1 (Lower) Shutter on Traverse side is open.
018211 Multi-tray (Block1)
Magazine2 (Upper) Shutter on Traverse side is open.
018212 Multi-tray (Block1)
Access detecting Sensor (Right) : Cannot detect Elevator Unit
018213 Multi-tray (Block1)
Access detecting Sensor (Left) : Cannot detect Elevator Unit
018214 Multi-tray (Block1)
Pick-up miss cmpnt is detected.
018215 Multi-tray (Block1)
Traverse axis is not on origin. Please perform zeroing of multi-tray.
018216 Multi-tray (Block1)
Multi-tray is running. Please operate it after completion.
018217 Multi-tray (Block1)
Please supply Tray Cmpnt after all zeroing.
018301 Multi-tray (Block2)
Close the safety door of multi-tray, and press a button [READY] of it. When multi-
tray [READY] does not change to [ON], press the button [READY] of Feeder.
018302 Multi-tray (Block2)
Pallet of multi-tray is drawn out. Execute zeroing all, store the pallet.
018303 Multi-tray (Block2)
Pallet Error of Multi-tray is detected. Execute zeroing all, and store the pallet.
018304 Multi-tray (Block2)
Press [READY] button of Feeder base, and supply the power for Multi Tray.
018305 Multi-tray (Block2)
Close the safety door(Center) of multi-tray, and press [READY] button.
018306 Multi-tray (Block2)
Close the safety door(Lower) of multi-tray, and press [READY] button.
018307 Multi-tray (Block2)
Close the safety door(Upper) of multi-tray, and press [READY] button.
4OM-1603
2-13
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
018308 Multi-tray (Block2)
ZeroingofTraverse-axisisnotnished.Performzeroingofmulti-tray.
018309 Multi-tray (Block2)
ZeroingofElevator1-axisisnotnished.Performzeroingofmulti-tray.
01830a Multi-tray (Block2)
ZeroingofElevator2-axisisnotnished.Performzeroingofmulti-tray.
01830b Multi-tray (Block2)
Pickup miss cmpnt(8mm) is detected.[B15417]
01830c Multi-tray (Block2)
Pickup miss cmpnt(14mm) is detected.[B15418]
01830d Multi-tray (Block2)
Pickup miss cmpnt(28mm) is detected.[B15419]
01830e Multi-tray (Block2)
Pallet Chuck claw is open.
01830f Multi-tray (Block2)
Pallet Flying away is detected.
018310 Multi-tray (Block2)
Magazine1 (Lower) Shutter on Traverse side is open.
018311 Multi-tray (Block2)
Magazine2 (Upper) Shutter on Traverse side is open.
018312 Multi-tray (Block2)
Access detecting Sensor (Right) : Cannot detect Elevator Unit
018313 Multi-tray (Block2)
Access detecting Sensor (Left) : Cannot detect Elevator Unit
018314 Multi-tray (Block2)
Pick-up miss cmpnt is detected.
018315 Multi-tray (Block2)
Traverse axis is not on origin. Please perform zeroing of multi-tray.
018316 Multi-tray (Block2)
Multi-tray is running. Please operate it after completion.
018317 Multi-tray (Block2)
Please supply Tray Cmpnt after all zeroing.
018401 Multi-tray is not ready to zeroing (Block1)
Execute all zeroing.
018501 Multi-tray is not ready to zeroing (Block2)
Execute all zeroing.
018601 Warning of wiring error
Vacuum Pump 1CB Error
018602 Warning of wiring error
Monitor Error of DC load power
018603 Warning of wiring error
Beam1 CB Error Monitor Error
018604 Warning of wiring error
Beam2 CB Error Monitor Error
018701 Feeder Alternate
Illegal alternate setup of pattern program. Check the settings.
1109-006
