4OM-1603
2-37
3. Machine Information : Chap.2
1109-001
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
80f001 Auto Opn.Mode
Start Auto Opn.Mode.
-----
80f002 Auto Opn.Mode
Stop Auto Opn.Mode.
-----
80f003 Auto Opn.Mode
Stop Auto Opn.Mode.(Error stop)
-----
80f101 ACV Registration
Comp.Reld. execution.
-----
80f102 ACV Registration
Splicing execution.
-----
80f201 Auto Cover Locked
The safety door is locked for pass running.
Please stop the machine and move the head if there is a head on the conveyor.
There is an interference with PCB if a head is on the conveyor.
-----
80f202 Auto Cover Locked
Connector(Block1) of Feeder Base is taken off.
Do not take it off when Feeder Base is rising up. Please go on if it's on operating.
-----
80f203 Auto Cover Locked
Connector(Block2) of Feeder Base is taken off.
Do not take it off when Feeder Base is rising up. Please go on if it's on operating.
-----
80f204 Auto Cover Locked
Manual Movement and Load.
This operation will be done while [START] button is pushed.
Please push the button continuously before PCB moves to the proposal position.
-----
80f301 Barcode Detection
The bar code data is not read. Bar code ID is generated automatically.
-----
80f302 Barcode Detection
Illegal bar code ID. Bar code ID is generated automatically.
-----
80f401 FF func. for Print Pos Correction
Standard PCB Mounting will be executed without Print Pos. Correction because
the standard of Device's Coordinates for PP data in Printer differs from it in
Mounter.
-----
4OM-1603
2-38
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
80f402 FF func. for Print Pos Correction
Standard PCB Mounting will be executed without Print Pos. Correction because
Global Recognition of PP Data does not have 2 points.
-----
80f403 FF func. for Print Pos Correction
Standard PCB Mounting will be executed without Print Pos. Correction because
Unit PCB Recog or Local PCB Recog of PP Data is being used.
-----
80f404 FF func. for Print Pos Correction
Standard PCB Mounting will be executed without Print Pos. Correction because
could not receive Print Pos. Correction values normally.
-----
80f405 FF func. for Print Pos Correction
Standard PCB Mounting will be executed without Print Pos. Correction because
of time-out of receiving Print Pos. Correction values.
-----
80f501 Auto Cover Locked Start
After Auto Cover locked, it is stopped because NG Items are found by Free Check
beforeproductopreation.Pleaseconrmtheguideforstart-up.
-----
80f601 Feeder Base
Connector for Feeder Cart is not connected.
-----
80f602 Feeder Base
Not turned Feeder Cart on yet.
-----
80f603 Feeder Base
Communicating with Feeder.
-----
08f701 Library Tape feeding High-speed
It is necessary to take out and in a feeder if tape high-speed feeding is set
enable.
-----
08f801 Unit PCB recognition data transfer func.
There is a possibility that the operation changed to PCB recog. manual alignment
during data processing, or PCB which is being data processing is taken off.
Please change the same current program in the head mounter(Unit 1). Or, set unit
PCB recog. data communication of operation mode [Disable] for a moment, and
then set [Enable] in the head mounter(Unit 1).
-----
08f901 Nozzle auto. Replace
Nozzle is replaced automatically because of a lowering of pick-up rate.
-----
1109-001
4OM-1603
2-39
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
08f902 Nozzle auto. Replace
Pick-up rate of nozzle went down, and nozzle was replaced automatically. But
nozzle position teaching failed.
-----
08f903 Nozzle auto. Replace
Pick-up rate of nozzle went down, but it is interrupted to replace nozzle
automatically.
-----
08f904 Nozzle auto. Replace
Pick-up rate of nozzle went down. It planned to replace nozzle automatically, but
there was no place to store it.
-----
08f905 Nozzle auto. Replace
Pick-up rate of nozzle went down. It planned to replace nozzle automatically, but
there was no spare nozzle.
-----
08f906 Nozzle auto. Replace
Nozzle is replaced automatically because of a lowering of pick-up rate. There is
not spare nozzle anymore.
-----
08fa01 Automatic correction of missed standard mark
Standard mark position offset is automatically corrected.
-----
