4OM-1603
3-19
3. Error IDs and Remedial Procedures : Chap.3
1109-001
Error ID Error Name, Description, Cause, and Remedy
406B01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pick-up miss cmpnt is detected on Tray pallet (Block2)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406C01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pick-up miss cmpnt is detected on Tray pallet (Block2)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406D01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pick-up miss cmpnt is detected on Tray pallet (Block2)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406E01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pick-up miss cmpnt is detected on Tray pallet (Block2)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
407001 Detecting Head1 nozzle descending
Invalid detection of head1 nozzle descending
Please perform a zeroing.
407101 Detecting Head2 nozzle descending
Invalid detection of head2 nozzle descending
Please perform a zeroing.
407201 Pass Line detect(Head1)
Invalid detection of Pass line(Head1)
Please perform a zeroing.
407301 Pass Line detect(Head2)
Invalid detection of Pass line(Head2)
Please perform a zeroing.
408001 Nozzle interference detect adjacent to multi-functional head
Emergency stopped a head because a nozzle adjacent to it interfered.
Please perform a zeroing.
408301 Feeder opening sensor (Block 1) detect
The feeder opening sensor (Block 1) was shaded.
-----
408401 Feeder opening sensor (Block 2) detect
The feeder opening sensor (Block 2) was shaded.
-----
T4C3
4OM-1603
3-20
3. Error IDs and Remedial Procedures : Chap.3
1012-005
3.2 Data
Error ID Error Name, Description, Cause, and Remedy
410301 Pattern Program Error
Steps in converted pattern program is more
-----
410302 Pattern Program Error
There are Errors in converted pattern program(PCB recog steps Error.)
-----
410303 Pattern Program Error
The converted pattern program is not exist, the data is damaged.
-----
410304 Pattern Program Error
The error is found in the adsorption nozzle number of the conversion pattern
program.
-----
410305 Pattern Program Error
The error is found in the order of adsorption of the conversion system pattern
program.
-----
410306 Pattern Program Error
The error is found in the nozzle candidate number of the conversion pattern
program.
-----
410307 Pattern Program Error
The error is found in the adsorption lane number of the conversion pattern
program.
-----
410401 Data Error
The components library does not exist. Or, data is in loss.
-----
410402 Data Error
Data relating to nozzle does not exist. Or, data is in loss.
-----
410701 Program Error
It was a error setting of the sequence data.
-----
410801 2D bar code data Error
It was a error setting of the sequence data.
-----
410802 2D bar code data Error
Failed in start-up Sequence
-----
410803 2D bar code data Error
The error is found in coordinates calculation.
-----
4OM-1603
3-21
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
410804 2D bar code data Error
Could not continue for Errors.
-----
T4C4
