4OM-1603
3-122
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
4b4701 SV-NET Communication
Internal Error.
Please restart the machine.
4b4801 2D bar code Time-out
Time-out of Sequence
-----
4b4802 2D bar code Time-out
Time-out of Communication
-----
4b4901 Feeder Feeding Pitch Correction Error
Feeder Feeding Pitch is out of position, but Auto Correction for it failed.
Please do teaching pick-up position.
4b4a01 Recycle Conveyor is taken off.
Do not take off Recycle Conveyor, please.
-----
4b4a02 Recycle Conveyor is taken off.
There is a possibility that Noz bent. Do not take off Recycle Conveyor during
Disposal.
PleaseopentheCover,thenconrmwhetherNozdidnotbend.
4b4b01 Cutter Error
(AtnishingAutoRun)Cutteroperation(Rear)isnotcompletedwithinaspecied
time.
Please push Emergency Stop button.
4b4b02 Cutter Error
(AtnishingAutoRun)Cutteroperation(Front)isnotcompletedwithinaspecied
time.
Please push Emergency Stop button.
4b4c01 Flux dispensing Error
Flux dispensing sequence error
-----
4b4c02 Flux dispensing Error
Cannotdetectcomponentsexistenceafterdispensingux.Errorinuxsensor.
-----
4b4d01 Flux dispensing unit Error
Flux dispensing Unit stopped in emergency.
-----
4b4d02 Flux dispensing unit Error
Flux dispensing Unit is not set.
Pleasesetuxdispensingunittothedeterminedplace.
4b4d03 Flux dispensing unit Error
Motor alarm.
Pleasedetachuxdispensingunit,andconrmwhetherthereisafactorofload
or not.
4OM-1603
3-123
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
4b4d04 Flux dispensing unit Error
Flux dispensing was not completed within predetermined time.
1.Pleaseconrmrotationwith[rotation]button.
2.Pleaseconrmwhetherthevolumeofrotaryspeedisnot"0".
3.PleaseconrmwhetherRotationPhotosensorisresponsive.
4.Pleaseconrmwhethertimingbelthassomeproblems.
4b4e01 Flux material shortage
Nouxonthedrum.PleasesupplyFlux.
-----
4b4f01 Nocmpntafteruxdispensing(Sensor)
Could not detect cmpnt on nozzle tip. There is a possibility that picked-up cmpnt
is fallen on the drum.
Pleasedetachuxdispensingunit,andthenremovecomponentsonthedrum.
4b5001 Nocmpntafteruxdispensing(Recog)
Could not detect cmpnt on nozzle tip. There is a possibility that picked-up cmpnt
is fallen on the drum.
Pleasedetachuxdispensingunit,andthenremovecomponentsonthedrum.
4b5101 Recycle conveyor error
It was impossible to detect the Cmpnt passing the passing check sensor.
Please remove all the components on the recycle conveyor.
4b5102 Recycle conveyor error
Cmpnt remains on the recycle conveyor(Block1).
Please restart Auto Opn after removing the remained cmpnt.
4b5103 Recycle conveyor error
Cmpnt remains on the recycle conveyor(Block2).
Please restart Auto Opn after removing the remained cmpnt.
4b5201 Impossible disposal(Disposal box)
It is impossible to send cmpnt to disposal box for discard because it is too large.
Please carry out disposal after inserting the recycle conveyor.
4b5301 Disposal error
Error in the disposal
Please retry to dispose. Please remove the cmpnt in the head and restart up if
there is still an error.
4b5401 Library tape width check
The tape width in library and the feeder are not in agreement.
Please check the library and feeder.
-----
4b5501 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.
-----
4b5601 Head type error
The set type and the installed type for head1 are different.
Please restart it after matching a set type to the head type.
Please check the DIP switch on installed PCB on the head after shut down.
There is possibility that communication system has error.
4OM-1603
3-124
3. Error IDs and Remedial Procedures : Chap.3
1109-001
Error ID Error Name, Description, Cause, and Remedy
4b5602 Head type error
The set type and the installed type for head2 are different.
Please restart it after matching a set type to the head type.
Please check the DIP switch on installed PCB on the head after shut down.
There is possibility that communication system has error.
4b5701 Library cmpnt carriage type error
There are errors of the cmpnt carriage type of the library.
Please check the library, and then do Chng. program.
4b5801 Joint detect
A joint is detected.
Please perform consistency check.
4b5901 LISA Communication error
LISA communication has errors.
Please check the followings, PC condition, Hub condition and connection
condition to LAN cable for LISA.
4b5a01 Warning about Maintenance
The total number of the feeder shot exceeded the setting value. It is time to
perform the feeder maintenance.
-----
4b5a02 Warning about Maintenance
The feeder adsorption rate decreased and exceeded the previous notice setting
number. It is time to perform the feeder maintenance.
-----
4b6001 Time Synchronization error
The time difference with the server device is 24 hours and more. Time
synchronization has been stopped.
There is a possibility that the battery of CPU board was dead.
Please inspect the battery of CPU board.
Please check the system time.
4b6101 Bowl Feeder power shut-off
Main power breaker of bowl feeder(Block1) is shut off.
Please check the power breaker of bowl feeder(Block1).
4b6102 Bowl Feeder power shut-off
Main power breaker of bowl feeder(Block2) is shut off.
Please check the power breaker of bowl feeder(Block2).
4b6201 Feeder information output error
Itisafoldertooutputloadedfeederinformationle.
The server of output folder is not connected. Please take out and take in a feeder
after checking connection status.
-----
4b6202 Feeder information output error
Couldnotoutputloadedfeederinformationle.
The server of output folder is not connected. Please take out and take in a feeder
after checking connection status.
-----
