4OM-1603
1-70
6. Head Change Procedure (Hard) : Chap.1
1202-002
6.2 Required Material List for Teaching and Precision
Adjustment (At the time of Head Change)
Product Item Part No. Q'ty Traching
Precision
Adjustment
Common
1 BARON 1
○
2 BARON Glass PCB 1
○
3 Adhesive Double Coated Tape 1
○
4 Offset Calculation Sheet 1
○
High-Speed Head Adjustment (For Single Head Mode)
1 0603 Master Chip Component 0914J10A 1
○
2 QFP Glass Jig 211D9639 1
○
3 GD28081 Feeder 1
○
4 HA09 Nozzle 1
○
5 HG31 Nozzle 15
○
6 Master Nozzle 1
○
Multi-Function Head Adjustment (In the Use of Feeder Cart)
1 QFP Glass Jig 8
○ ○
2 Jig Placement Plate 1
○
3 Jig Bracket (1) 1
○
4 Jig Bracket (2) 1
○
5 M3×10 Sems Screw 4
○
6 FA04 Nozzle 1(3)
○
7 FF01 Nozzle 1(3)
○ ○
T4A18
4OM-1603
1-71
7. Consumables and Servicing Parts : Chap.1
1202-007
7. Consumables and Servicing Parts
7.1 List of Consumables
This component list is for the components that would be worn within one year.
When any of these components are to be purchased, contact Marketing Dept. of
HITACHI High-Technologies or our sales agent.
Product Name Part No. Part Name Q'ty
Recommended
number per year
note (a)
Exploded
Illustration
Remarks
Nozzle (HV81C) HV81C--- ASSY, NOZZLE (HV81C) 30 30
Nozzle (HV03C) HV03C--- ASSY, NOZZLE (HV03C) 30 30
Nozzle (HB03C) HB03C--- ASSY, NOZZLE (HB03C) 30 30
Nozzle (HB04C) HB04C--- ASSY, NOZZLE (HB04C) 30 30
Nozzle (HA04C) HA04C--- ASSY, NOZZLE (HA04C) 30 30
Nozzle (HA05C) HA05C--- ASSY, NOZZLE (HA05C) 30 30
Nozzle (HA09C) HA09C--- ASSY, NOZZLE (HA09C) 30 30
Nozzle (PA05C) PA05C--- ASSY, NOZZLE (PA05C) 30 30
Nozzle (HG31C) HG31C--- ASSY, NOZZLE (HG31C) 30 30
Nozzle (HG51C) HG51C--- ASSY, NOZZLE (HG51C) 30 30
Nozzle (HG21C) HG21C--- ASSY, NOZZLE (HG21C) 30 30
Vacuum Filter 225B0572 AIR LINE EQPT 60 240 Fig. G1-5,
Fig. O1-1
Fluorine Sheet 212A2743 GUIDE 2 2 Fig. C2-1
Urethane Clamp
ASSY
0920715E
09207152
Sliding Type Clamper ASSY
Fixed Type Clamper ASSY
2
2
2
2
Fig. C2-5
Seal ASSY
Flat Ring
Set Bolt
0920715E
0920H159
0920H158
SEAL
Screw 01605B0
2
2
12
2
2
12
Fig. C2-6 Cutter Unit
Sliding Side
For the Roller
DISK ASSY
Cutter Blade
Cutter Blade Set Bolt
0920716D
0920H127
221A0231
DISK
BOLT, HEX-SCT
4
4
12
4
4
12
Fig. C2-6 Note (c)
Nozzle Filter 225A0045 Nozzle Filter 30
(15)
960
(480)
Fig. D1-1 Note (d)
Vacuum Filter 630 069
5816
AIR LIN EQPT 3 18 Fig. D1-1 Note (d)
T4A16
Note
(a) The recommended number of pieces is the value for reference only.
(b) Refer to "3. Maintenance Spots" for component replacement procedures.
(c) For the cutter blade replacement, consult with our service personnel
because it is a dangerous procedure.
When the cutter blade is replaced, also replace the bolt.
(d) The gures in brackets are applied for the multi-functional head.
4OM-1603
1-72
7. Consumables and Servicing Parts : Chap.1
7.2 List of Servicing Parts
This component list is for the components for which maintenance is required in
several years, for your reference.
Note
For the maintenance procedure for the important maintenance components,
consult with our service personnel because high skill is required for such
maintenance.
Block
Name
Product Name Part No. Part Name Q'ty
Recommended
# of years
Note(a)
Exploded
Illustration
Remarks
Head
Section
Solenoid Valve 23D10016 ACCESSORY,SV 30 3 Fig. G1-5
Nozzle Shaft ASSY 09163KOK
ASSY,GUIDE,LINEAR
30
Sets
- Fig. G1-5 Note (c)
Hexagon Socket
Head Cap Screw
M2×4
221AA121 BOLT,HEX-SCT 30 - Fig. G1-5 For Nozzle
Shaft Setup
Note (b)
O-Ring for Seal
Holder
226A0286
(SO-008-13)
0916D31E
(SO-010-12)
SEAL 30
90
2 Fig. G1-5
Nozzle Shaft Spring 0916DK2D SPRING,COMP 30 2 Fig. G1-5
Packing for Nozzle
DYR-2.5 Custom
226A0279 SEAL 60 - Fig. G1-5
O-Ring for Filter
SO-009-5A
0916D338 SEAL 60 2 Fig. G1-5
Line Sensor 23G00313 SENSOR,PELEC 2 2 Fig. G1-5
Diffusion Plate
(Outside)
213D1169
(*1)
0916D31G
(*2)
DISK 2 - Fig. G1-5 Note (c)
Diffusion Plate
(Inside)
213D1336
(*1)
0916D31F
(*2)
DISK 2 - Fig. G1-5 Note (c)
Hexagon Socket
Head Cap Screw
M1.6×4
221AA332 BOLT,HEX-SCT 14 - Fig. G1-5 For Diffusion
Plate Setup
Note (b)
Top Block 211G6373 BLOCK 30 - Fig. G1-5
Cam Follower (f2.5) 222H0163 CAMFOLLOWER 30 - Fig. G1-5
Hexagon Socket
Head Cap Screw
M1.6×3
221AA330 BOLT,HEX-SCT 60 - Fig. G1-5 For Top
Block Setup
Note (b)
Sensor PM-U24 23G20046 SENSOR,PHOTO 2 3 Fig. G1-3,
Fig. G1-4,
Fig. G1-5,
Fig. G1-6
Sensor PM-L24 23G10059 SENSOR,PHOTO 10 3
Slip Ring 0916D30T SLIP RING 2 2 Fig. G1-6
T4A17
1202-006
