Safety Precautions
Safe-28
1OM-1603
1108-003
5. Alert Labels
No. Alert Labels and Description
(10)
CAUTION
Your hand might be caught in the moving section. Do not
put your hand into the cover opening during the machine
operation.
Pay attention to the moving
mechanisms!
10-0249-
Description
Do not put your hand inside the machine while the machine is running.
Otherwise, your hand may be trapped in the moving mechanisms, causing injury.
(11)
Description
Do not put your hand in the moving area while the feeder base is moving up or
down.
While the LED of a [FEEDER READY] switch is ickering, it indicates that the
feeder base is moving upward or downward.
(12)
Description
Strong permanent magnets are used in the moving sections of the X/Y beam.
•
Do not bring any metal of high magnetizability close to this. Otherwise, such
metal will easily be magnetized and attracted, causing an injury to the operator
or breakdown of the machine.
•
Do not bring any object such as a magnetic card or a watch close to the
magnets.Such an object can easily be affected by the magnetism. Otherwise, the
data of the magnetic car might be cleared or a watch, etc., may be damaged due
to the strong magnetism.
Safety Precautions
Safe-29
1OM-1603
1108-004
5. Alert Labels
No. Alert Labels and Description
(13)
Description
Do not drop a feeder. Otherwise, a foot injury will result or the feeder itself may be
damaged.
Carefully handle each feeder one by one and do not drop any.
(14)
Description
Do not drop a cutter. Otherwise, a foot injury will result or the cutter itself may be
damaged.
Carefully handle each cutter one by one and do not drop any.
(15)
10-0282-
Pay attention to the moving
mechanisms!
Do not put your hand in the moving area.
Otherwise, your hand might be caught in
the moving area and injured.
Description
Be careful not to get caught.
Otherwise, a serious injury such as injury on your hand might be caused.
Safety Precautions
Safe-30
1OM-1603
5. Alert Labels
1108-005
No. Alert Labels and Description
(16)
01-0035-
Description
Because the temperature of this section is very high, do not touch. Doing so might
cause a burn.
(17)
Description
Do not put any feeder sideways nor tools on the feeder bases. Otherwise, the
machine will break down.
(18)
Description
If you put your hand or a heavy object on the backup table while working inside the
machine, the backup table may become deformed due to an excessive load.
