4OM-1603
3-117
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b301c Cutter Error
Failed to start-up Communication of SV-NET
PleaseconrmAE-LINKwiringandPowerwiring.
4b301d Cutter Error
Failed to reset Alarm of Cutter-axis
----
4b301e Cutter Error
It returned to its Origin because Alarm of Cutter-axis was detected during
Positioning
Please check Feeder whose Number is close one indicated.
4b301f Cutter Error
Cannotturnontheservomotorofcutterunitwithinaspeciedtime.
----
4b3101 Cutter(Servo Error)
Error of Power Driver, Over-current
Check out motor wiring or exchange both motor and driver.
4b3102 Cutter(Servo Error)
Overload Alarm
Check out motor wiring or replace both motor and driver.
Either,Conrmwhetherthereischockedupwithcutterpieces.
Please check it because there is a possibility that the fuse in cutter-axis is
broken.
4b3103 Cutter(Servo Error)
Speed Alarm
Need to adjust motor gain again.
4b3104 Cutter(Servo Error)
Multi-rotation Error
Check motor wiring or exchange motor.
4b3105 Cutter(Servo Error)
The value of Deviation Counter was over the set value
Check the wiring of Origin sensor. Either, replace a driver.
Please check it because there is a possibility that the fuse in cutter-axis is broken.
4b3106 Cutter(Servo Error)
Power Drive detected temperature error.
Ambient Temperature is too high. Exchange driver.
4b3107 Cutter(Servo Error)
Sensor Error
ConrmthewiringofMotorEncoder.Either,exchangemotor
4b3108 Cutter(Servo Error)
High Drive voltage
Insufcientpowercapacity.Exchangedriver.
4b3109 Cutter(Servo Error)
Low drive voltage
PleaseconrmtheoperatingPowerwiringwhichisinsertedtodriver.
4b310a Cutter(Servo Error)
Reading Error on permanent memory
Exchange Driver
1109-006
4OM-1603
3-118
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b310b Cutter(Servo Error)
Reading Error on permanent memory
Exchange Driver
4b310c Cutter(Servo Error)
CPU Error
Exchange Driver
4b310d Cutter(Servo Error)
Parameter Error
PleaseconrmthechangedParameter
4b310e Cutter(Servo Error)
Alarm code readout failed
-----
4b310f Cutter(Servo Error)
Low driving voltage(Block1)(Feeder Base [ON])
-----
4b3110 Cutter(Servo Error)
Low driving voltage(Block2)(Feeder Base [ON])
-----
4b3111 Cutter(Servo Error)
Low driving voltage(Block1)(Feeder Base [OFF])
-----
4b3112 Cutter(Servo Error)
Low driving voltage(Block2)(Feeder Base [OFF])
-----
4b3201 Servo Motor Error
Error of processing Servo On
-----
4b3202 Servo Motor Error
Time-out of processing Servo On
-----
4b3203 Servo Motor Error
Error of processing Servo Off
-----
4b3204 Servo Motor Error
Time-out of processing Servo Off
-----
4b3205 Servo Motor Error
Time-out of processing Servo On(Block1)
Please restart the machine.
4b3206 Servo Motor Error
Time-out of processing Servo On(Block2)
Please restart the machine.
1109-006
4OM-1603
3-119
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b3301 Data Communication Error
failed in data expansion
There is a possibility of following errors
1. Communication Error
2. Data loss
Please contact the service when not repaired even if turns it on again.
4b3401 Nozzle check Error before Pickup(Detected before operating)
It stopped because the remains components on the nozzle or adhering matters on
the linear measure sensor of Light Emitter/Receiver were detected.
TheremainsComponentonanozzleorawandsoilonLightEmitter/Receiverof
Linear measure Sensor could be considered to adhere. Please clean it up.
4b3402 Nozzle check Error before Pickup(Detected before operating)
Error in Communication with Linear measure sensor.
PleaseconrmErrorfromLogRequestScreen(Unitadjustment->Linear
measureSensorScreen).Either,pleaseconrmwhethertheitemsofLS-RLS-
S(Device Check -> List) is Yellow. HLS communication cable could not be
connected and such like things.
4b3403 Nozzle check Error before Pickup(Detected before operating)
Error in Origin moving in HL/NL/L-axis
-----
4b3404 Nozzle check Error before Pickup(Detected before operating)
Error of nozzle check before pick-up
-----
4b3405 Nozzle check Error before Pickup(Detected before operating)
Error in discarding the remains detect component
-----
4b3406 Nozzle check Error before Pickup(Detected before operating)
Error of nozzle check before pick-up(program error)
-----
4b3501 Automatic Zeroing Error
Failed to zeroing automatically
Please restart.
4b3601 Receding Error
Motor Error on receding
-----
4b3602 Receding Error
Time-out on receding
-----
4b3701 Writing Origin position of License nozzle
Linear measure Sensor error is detected before operating.
-----
4b3702 Writing Origin position of License nozzle
Failed in getting Offset data
-----
4b3703 Writing Origin position of License nozzle
Failing in writing origin position of Noz.
-----
