4OM-1603
2-12
2. Management Information : Chap.2
1109-006
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
018209 Multi-tray (Block1)
ZeroingofElevator1-axisisnotnished.Performzeroingofmulti-tray.
01820a Multi-tray (Block1)
ZeroingofElevator2-axisisnotnished.Performzeroingofmulti-tray.
01820b Multi-tray (Block1)
Pickup miss cmpnt(8mm) is detected.[B15417]
01820c Multi-tray (Block1)
Pickup miss cmpnt(14mm) is detected.[B15418]
01820d Multi-tray (Block1)
Pickup miss cmpnt(28mm) is detected.[B15419]
01820e Multi-tray (Block1)
Pallet Chuck claw is open.
01820f Multi-tray (Block1)
Pallet Error is detected.
018210 Multi-tray (Block1)
Magazine1 (Lower) Shutter on Traverse side is open.
018211 Multi-tray (Block1)
Magazine2 (Upper) Shutter on Traverse side is open.
018212 Multi-tray (Block1)
Access detecting Sensor (Right) : Cannot detect Elevator Unit
018213 Multi-tray (Block1)
Access detecting Sensor (Left) : Cannot detect Elevator Unit
018214 Multi-tray (Block1)
Pick-up miss cmpnt is detected.
018215 Multi-tray (Block1)
Traverse axis is not on origin. Please perform zeroing of multi-tray.
018216 Multi-tray (Block1)
Multi-tray is running. Please operate it after completion.
018217 Multi-tray (Block1)
Please supply Tray Cmpnt after all zeroing.
018301 Multi-tray (Block2)
Close the safety door of multi-tray, and press a button [READY] of it. When multi-
tray [READY] does not change to [ON], press the button [READY] of Feeder.
018302 Multi-tray (Block2)
Pallet of multi-tray is drawn out. Execute zeroing all, store the pallet.
018303 Multi-tray (Block2)
Pallet Error of Multi-tray is detected. Execute zeroing all, and store the pallet.
018304 Multi-tray (Block2)
Press [READY] button of Feeder base, and supply the power for Multi Tray.
018305 Multi-tray (Block2)
Close the safety door(Center) of multi-tray, and press [READY] button.
018306 Multi-tray (Block2)
Close the safety door(Lower) of multi-tray, and press [READY] button.
018307 Multi-tray (Block2)
Close the safety door(Upper) of multi-tray, and press [READY] button.
4OM-1603
2-13
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
018308 Multi-tray (Block2)
ZeroingofTraverse-axisisnotnished.Performzeroingofmulti-tray.
018309 Multi-tray (Block2)
ZeroingofElevator1-axisisnotnished.Performzeroingofmulti-tray.
01830a Multi-tray (Block2)
ZeroingofElevator2-axisisnotnished.Performzeroingofmulti-tray.
01830b Multi-tray (Block2)
Pickup miss cmpnt(8mm) is detected.[B15417]
01830c Multi-tray (Block2)
Pickup miss cmpnt(14mm) is detected.[B15418]
01830d Multi-tray (Block2)
Pickup miss cmpnt(28mm) is detected.[B15419]
01830e Multi-tray (Block2)
Pallet Chuck claw is open.
01830f Multi-tray (Block2)
Pallet Flying away is detected.
018310 Multi-tray (Block2)
Magazine1 (Lower) Shutter on Traverse side is open.
018311 Multi-tray (Block2)
Magazine2 (Upper) Shutter on Traverse side is open.
018312 Multi-tray (Block2)
Access detecting Sensor (Right) : Cannot detect Elevator Unit
018313 Multi-tray (Block2)
Access detecting Sensor (Left) : Cannot detect Elevator Unit
018314 Multi-tray (Block2)
Pick-up miss cmpnt is detected.
018315 Multi-tray (Block2)
Traverse axis is not on origin. Please perform zeroing of multi-tray.
018316 Multi-tray (Block2)
Multi-tray is running. Please operate it after completion.
018317 Multi-tray (Block2)
Please supply Tray Cmpnt after all zeroing.
018401 Multi-tray is not ready to zeroing (Block1)
Execute all zeroing.
018501 Multi-tray is not ready to zeroing (Block2)
Execute all zeroing.
018601 Warning of wiring error
Vacuum Pump 1CB Error
018602 Warning of wiring error
Monitor Error of DC load power
018603 Warning of wiring error
Beam1 CB Error Monitor Error
018604 Warning of wiring error
Beam2 CB Error Monitor Error
018701 Feeder Alternate
Illegal alternate setup of pattern program. Check the settings.
1109-006
4OM-1603
2-14
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
018702 Feeder Alternate
Invalid feeder in alternating. Set feeder valid
018801 XY Origin Offset
Illegal XY-Origin offset of Beam1.
Please retry to send Device data from NT, or execute teaching XY-Origin offset.
018802 XY Origin Offset
Illegal XY-Origin offset of Beam2.
Please retry to send Device data from NT, or execute teaching XY-Origin offset.
018901 Feeder communication
Feeder (Block1) is on communication.
Please wait for a second, and then operate again.
018902 Feeder communication
Feeder (Block2) is on communication.
Please wait for a second, and then operate again.
018a01 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.(Block1)
018a02 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.(Block2)
018b01 Library Tape Width check
Library Tape Width differs from Feeder. Please check Library and Feeder.(Block1)
018b02 Library Tape Width check
Library Tape Width differs from Feeder. Please check Library and Feeder.(Block2)
019001 Support Pin
Please move exchange position of support pin.
019002 Support Pin
Noz for exchanging support pin is not set, or Odd type noz is set.
019003 Support Pin
Arranging data in current differs from it of Support Pin of current pattern program.
Please set-up the support pin.
019004 Support Pin
When PCB size 216mm is exceeded, it is impossible to operate if Support pins of
Lane A remain. Please exchange Lane A, or take out it from machine.
019005 Support Pin
It is impossible to do operation for only Lane B because Support Pins of Lane A
remain. Please exchange Lane A, or take out it from machine.
019006 Support Pin
Operation for Lane A is impossible because Support Pins of Lane A have not been
installed. Please exchange Support pins or store them.
019007 Support Pin
It is impossible to do Operation for only Lane A because Support Pins of Lane B
remain. Please exchange Lane B, or take out it from machine.
019008 Support Pin
Support pins of Lane B remain on the base for Support pins of Lane A, so that it is
impossible to do Conveyor width. Please exchange Support pins or store them.
019009 Support Pin
Arrangement of Support Pins interferes in Conveyor. Please retry to arrange it.
