4OM-1603

3-63

3. Error IDs and Remedial Procedures : Chap.3

1109-006

Error ID Error Name, Description, Cause, and Remedy

438606 Multi-Tray (Servo Error) (Block1)

Power Drive detected temperature error.

Ambient Temperature is too high. Or, exchange driver.

438607 Multi-Tray (Servo Error) (Block1)

Sensor Error

PleaseconrmMotorEncoderwiring.Or,exchangemotor

438608 Multi-Tray (Servo Error) (Block1)

High Drive voltage

Insufcientpowercapacity.Pleaseexchangedriver.

438609 Multi-Tray (Servo Error) (Block1)

Low drive voltage

PleaseconrmtheoperatingPowerwiringwhichisinsertedtodriver.

43860A Multi-Tray (Servo Error) (Block1)

Reading Error on permanent memory

Please exchange driver.

43860B Multi-Tray (Servo Error) (Block1)

Reading Error on permanent memory

Please exchange driver.

43860C Multi-Tray (Servo Error) (Block1)

CPU Error

Please exchange driver.

43860D Multi-Tray (Servo Error) (Block1)

Parameter Error

Pleaseconrmthechangedparameter.

43860E Multi-Tray (Servo Error) (Block1)

Alarm code readout failed

-----

438701 Elevator Recede position operating error (Block1)

Elevator pre-check error

-----

438702 Elevator Recede position operating error (Block1)

Error of calculating Elevator movement position

-----

438703 Elevator Recede position operating error (Block1)

Elevator Start Time-out

-----

438704 Elevator Recede position operating error (Block1)

Elevator movement error

-----

438705 Elevator Recede position operating error (Block1)

Elevator movement Time-out

-----

438801 Elevator comp. position operating error (Block1)

Elevator pre-check error

-----

4OM-1603

3-64

3. Error IDs and Remedial Procedures : Chap.3

1109-001

Error ID Error Name, Description, Cause, and Remedy

438802 Elevator comp. position operating error (Block1)

Error of calculating Elevator movement position

-----

438803 Elevator comp. position operating error (Block1)

Elevator Start Time-out

-----

438804 Elevator comp. position operating error (Block1)

Elevator movement error

-----

438805 Elevator comp. position operating error (Block1)

Elevator movement Time-out

-----

T4C6

4OM-1603

3-65

3. Error IDs and Remedial Procedures : Chap.3

1109-006

3.5 Tray Feeder (Block2)

Error ID Error Name, Description, Cause, and Remedy

440201 Tray Motor Error (Block2)

Elevator abnormal stop

-----

440202 Tray Motor Error (Block2)

Elevator abnormal stop

-----

440203 Tray Motor Error (Block2)

Traverse abnormal stop

-----

440301 Tray Rack Shutter open/close error (Block2)

The Rack Shutter did not open in prescribed time.

-----

440302 Tray Rack Shutter open/close error (Block2)

The Rack Shutter did not close in prescribed time.

Pleaseconrmwhetherthepaletteisnotcaughtintherackshutter.

440401 Tray Pallet Chuck open/close error (Block2)

The Pallet Chuck did not open in prescribed time.

-----

440402 Tray Pallet Chuck open/close error (Block2)

The Pallet Chuck did not close in prescribed time.

-----

441001 Tray Supply Operation Error (Block2)

-----

441002 Tray Supply Operation Error (Block2)

Tray steps No. disagreement of draw out(return operation)

-----

441003 Tray Supply Operation Error (Block2)

Tray steps No. disagreement of draw out(return operation)

-----

441004 Tray Supply Operation Error (Block2)

The operation mode is illegal. (system)

-----

441005 Tray Supply Operation Error (Block2)

TV axis's position is irregular

-----

441006 Tray Supply Operation Error (Block2)

Magazineclassicationdisagreement

Please carry out the check of ten steps of magazines, and 15-step type.

441101 Tray Pallet Returning Error (Block2)

Elevator pre-check error

-----

441102 Tray Pallet Returning Error (Block2)

Elevator movement position error

-----
