4OM-1603
3-62
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
43850E Multi-Tray (Block1)
Elevator2-aixs in not connected.
PleaseconrmAE-LINKwiringandPowerwiring.
438510 Multi-Tray (Block1)
Motor Breaker Trip Error
-----
438511 Multi-Tray (Block1)
Elevator Unit is not connected.
Please connect Elevator unit in Unit exchange menu.
438512 Multi-Tray (Block1)
All connectors of Elevator Unit are not connected.
PleaseconrmtheconnectiontoallconnectorofElevatorUnit
438513 Multi-Tray (Block1)
Failed to start-up Communication of SV-NET.
PleaseconrmAE-LINKwiringandPowerwiring.
438514 Multi-Tray (Block1)
Failed to turn on Multi-tray.(Time-out)
-----
438515 Multi-Tray (Block1)
(AtnishingAutoRun)Multi-trayoperation(Block1)isnotcompletedwithina
speciedtime.
Please push Emergency Stop button.
438516 Multi-Tray (Block1)
To discriminate the connected tray cart is failed.
Please press READY switch on Feeder Base again. Please contact to the service
when to output the error is continuous.
438517 Multi-Tray (Block1)
Timeout in discriminating the tray cart.
Please press READY switch on Feeder Base again. Please contact to the service
when to output the error is continuous.
438601 Multi-Tray (Servo Error) (Block1)
Error of Power Driver, Over-current
PleaseconrmMotorwiring,ExchangeMotorandDriver.
438602 Multi-Tray (Servo Error) (Block1)
Overload Alarm
PleaseconrmMotorwiring,ExchangeMotorandDriver.
438603 Multi-Tray (Servo Error) (Block1)
Speed Alarm
You need to re-adjust Motor Gain.
438604 Multi-Tray (Servo Error) (Block1)
Multi-rotation Error
PleaseconrmMotorwiring,ExchangeMotorandDriver.
438605 Multi-Tray (Servo Error) (Block1)
The value of Deviation Counter was over the set value
PleaseconrmthewiringofOriginSensor,orexchangeDriver.
4OM-1603
3-63
3. Error IDs and Remedial Procedures : Chap.3
1109-006
Error ID Error Name, Description, Cause, and Remedy
438606 Multi-Tray (Servo Error) (Block1)
Power Drive detected temperature error.
Ambient Temperature is too high. Or, exchange driver.
438607 Multi-Tray (Servo Error) (Block1)
Sensor Error
PleaseconrmMotorEncoderwiring.Or,exchangemotor
438608 Multi-Tray (Servo Error) (Block1)
High Drive voltage
Insufcientpowercapacity.Pleaseexchangedriver.
438609 Multi-Tray (Servo Error) (Block1)
Low drive voltage
PleaseconrmtheoperatingPowerwiringwhichisinsertedtodriver.
43860A Multi-Tray (Servo Error) (Block1)
Reading Error on permanent memory
Please exchange driver.
43860B Multi-Tray (Servo Error) (Block1)
Reading Error on permanent memory
Please exchange driver.
43860C Multi-Tray (Servo Error) (Block1)
CPU Error
Please exchange driver.
43860D Multi-Tray (Servo Error) (Block1)
Parameter Error
Pleaseconrmthechangedparameter.
43860E Multi-Tray (Servo Error) (Block1)
Alarm code readout failed
-----
438701 Elevator Recede position operating error (Block1)
Elevator pre-check error
-----
438702 Elevator Recede position operating error (Block1)
Error of calculating Elevator movement position
-----
438703 Elevator Recede position operating error (Block1)
Elevator Start Time-out
-----
438704 Elevator Recede position operating error (Block1)
Elevator movement error
-----
438705 Elevator Recede position operating error (Block1)
Elevator movement Time-out
-----
438801 Elevator comp. position operating error (Block1)
Elevator pre-check error
-----
4OM-1603
3-64
3. Error IDs and Remedial Procedures : Chap.3
1109-001
Error ID Error Name, Description, Cause, and Remedy
438802 Elevator comp. position operating error (Block1)
Error of calculating Elevator movement position
-----
438803 Elevator comp. position operating error (Block1)
Elevator Start Time-out
-----
438804 Elevator comp. position operating error (Block1)
Elevator movement error
-----
438805 Elevator comp. position operating error (Block1)
Elevator movement Time-out
-----
