4OM-1603 2-5 2. Management Information : Chap.2 Management Information Code Display Area A (The outline of the Management Information) Display Area B (The details of the Management Information) 010904 Feederbaseconrm…

100%1 / 379
4OM-1603
2-4
2. Management Information : Chap.2
2.2 Management Information List
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
010101 Emergency Stop
Press [POWER ON] button to activate Load Power circuit.
010103 Emergency Stop
Emergency Stop switch is pressed. Please cancel it.
010201 Air Pressure Drop
Air Pressure Drop is detected
010401 Safetycoverlockconrm
Please close and lock the safety cover.
010402 Safetycoverlockconrm
Operate after close and lock the safety cover. (LED on)
010403 Safetycoverlockconrm
Operate after close and lock the safety cover.
010404 Safetycoverlockconrm
The safety cover is in unlock. Please complete to unlock and operate it.
010503 Beam XY main circuit OFF
Beam XY main circuit Error
010801 Feederbaseconrm(Block1)
Set the feeder cart(Block1) and connect cable.
010802 Feederbaseconrm(Block1)
Cannot set Feeder Cart downward to detect Elevator Unit(Block1).
Operate after remove it .
010803 Feederbaseconrm(Block1)
Elevator Unit(Block1) is not connected.
Please connect to it with "Unit Exchange Menu".
010804 Feederbaseconrm(Block1)
Batch Connector of Elevator Unit(Block1) is not connected.
Please check connection.
010805 Feederbaseconrm(Block1)
Feeder cart (Block1) is not upper position.
Push Feeder Ready Switch.
010806 Feederbaseconrm(Block1)
Push Feeder Ready SW.
010807 Feederbaseconrm(Block1)
Feeder base power or Feeder power is "OFF". Please press "Feeder Ready"
switch(Block1), and put it up again after putting Feeder Cart(Block1) down.
010901 Feederbaseconrm(Block2)
Set the feeder cart and connect cable.(Block2)
010902 Feederbaseconrm(Block2)
Cannot set Feeder Cart downward to detect Elevator Unit(Block2).
Operate after remove it .
010903 Feederbaseconrm(Block2)
Elevator Unit(Block2) is not connected. Please connect to it with "Unit Exchange
Menu".
1109-006
4OM-1603
2-5
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
010904 Feederbaseconrm(Block2)
Batch Connector of Elevator Unit(Block2) is not connected.
Please check connection.
010905 Feederbaseconrm(Block2)
Feeder cart (Block2) is not upper position.
Push feeder ready sw.
010906 Feederbaseconrm(Block2)
Push feeder ready sw.
010907 Feederbaseconrm(Block2)
Feeder base power or Feeder power is "OFF". Please press "Feeder Ready"
switch(Block2), and put it up again after putting Feeder Cart(Block2) down.
011001 Empty Feeder (Block1)
Please set the feeder(Block1) that used by the pattern program.
011101 Empty Feeder (Block2)
Please set the feeder (Block2) that used by the pattern program.
010b01 Feeder is not ready (Block1)
Please turn on the Feeder Ready SW (Block1).
010c01 Feeder is not ready (Block2)
Please turn on the Feeder Ready SW (Block2).
010d01 Pattern program is abnormal
Please set the normal pattern program
010e01 Prod Chng is not ready
Conveyorwidthdoesnottproductiondata.
Execute conveyor width setup.
011401 Zeroingnotnish
Perform All zeroing
011402 Zeroingnotnish
Perform All zeroing
011403 Zeroingnotnish
Perform All zeroing
011404 Zeroingnotnish
Perform All zeroing
011405 Zeroingnotnish
Perform All zeroing
011406 Motor is not servo on
Perform All zeroing
011701 PCB positioning
Please position the PCB.
011702 PCB positioning
Set Pos PCB [Output Position].
011703 PCB positioning
Set Pos PCB [Input Position].
011704 PCB positioning
Please cancel PCB positioning after cancelling operation.
011705 PCB positioning
Please set PCB positioning [Input or Output] of [Lane A]
1109-006
4OM-1603
2-6
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
011706 PCB positioning
Please set PCB positioning. [Output position] of [Lane A].
011707 PCB positioning
Please set PCB positioning [Input position] of [Lane A].
011708 PCB positioning
Please set PCB Positioning [Input or Output] of [Lane B].
011709 PCB positioning
Please set PCB Positioning [Output position] of [Lane B].
01170a PCB positioning
Please set PCB positioning [Input position] of [Lane B].
01170b PCB positioning
Please set PCB positioning of input position on PCB transfer menu.
01170c PCB positioning
Please set PCB positioning of [Lane A] input position on PCB transfer menu.
01170d PCB positioning
Please set PCB positioning of [Lane B] input position on PCB transfer menu.
011901 Headunsettledcomp.conrmation
An unsettled component was detected. Please discard the component. In case of
the "Pauses" condition, perform the operation for interruption.
011a01 Nozzlestockerlowerlimitconrmation
Please perform All zeroing.
011c01 Nozzlearrangementconrmation
The nozzle arrangement of the Current Program differs from it of Head.
011c02 Nozzlearrangementconrmation
ThestoragespaceoftheNozzleisinsufcient.PleasesecureNozzleStockerthe
Nozzle storage space. (Block1)
011c03 Nozzlearrangementconrmation
ThestoragespaceoftheNozzleisinsufcient.PleasesecureNozzleStockerthe
Nozzle storage space. (Block2)
011c04 Nozzlearrangementconrmation
TheNozzleusedisinsufcient.PleasearrangetheNozzleused.(Block1)
011c05 Nozzlearrangementconrmation
TheNozzleusedisinsufcient.PleasearrangetheNozzleused.(Block2)
012a01 Tray shortage Comp (Block1)
Please supply Tray Cmpnt, close Tray Safety door and push Tray Ready
SW(Block1).
012a02 Tray shortage Comp (Block1)
There is the shortage components. Please supply the components.
012b01 Tray shortage Comp (Block2)
Please supply Tray Cmpnt, close Tray Safety door and push Tray Ready
SW(Block2).
012b02 Tray shortage Comp (Block2)
There is the shortage components. Please supply the components.
013101 Feeder set Err
A pickup miss comp is detected.(Block1)
