4OM-1603
2-31
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
802209 ACV Information
Device(Block2) Time-out of Feeder communication.
Please take out Feeder and then take it in again.
-----
802301 Splicing No Check Alarm
The seam passed the detection sensor as unregistered splicing.
Please register the splicing.
-----
802401 FeederCoverTapelledupalarm
ThestoragesectionofCoverTapelledwasdetected.
Please remove Tape from internal storage section.
-----
802501 Feeder Communication Error
Failed to displaying Operational Panel.
Please put the Cart down, or pull out and insert Feeder.
-----
802502 Feeder Communication Error
The communication processing of Feeder was not done in prescribed time.
-----
802601 Linear measure sensor
To set synchronized counting position of Head1 is failed.
-----
802602 Linear measure sensor
To set synchronized counting position of Head2 is failed.
-----
802603 Linear measure sensor
To reset DD origin position of Head1 is failed.
-----
802604 Linear measure sensor
To reset DD origin position of Head2 is failed.
-----
803001 FAN Stop alarm
Fan rotation error of the case(Block2). Please clean up Fan.
-----
803002 FAN Stop alarm
Fan rotation error of the case(Block1). Please clean up Fan.
-----
803003 FAN Stop alarm
Fan rotation error of the power G4(Upper). Please clean up Fan.
-----
803004 FAN Stop alarm
Fan rotation error of the power G4(Rear). Please clean up Fan.
-----
803005 FAN Stop alarm
Fan rotation error of the roof(Left). Please clean up Fan.
-----
1109-006
4OM-1603
2-32
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
803006 FAN Stop alarm
Fan rotation error of the roof(Left). Please clean up Fan.
-----
803028 FAN Stop alarm
Fan rotation error of Control Box. Clean up Fan.
-----
803101 Feeder Feeding Pitch Correction
Auto Correction is executed for Feeder Feeding Pitch is out of position.
-----
809201 Library tape width check
The tape width in library and the feeder are not in agreement.
Please check the library and feeder.
-----
809301 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.
-----
809c01 Motor system error
Communication not establish with Servo Amp (XY Beam).
Check following
1. Rotary sw of Servo Amp.
2. Condition of AC power.
3. Communication cable.
809c02 Motor system error
Servo Amp parameter error.
1. There is a possibility that Motor Communication Line is abnormal.
2. Parameter settings Error(0x21E).
809c03 Motor system error
Communication not establish with Servo Amp (Head).
Check following
1. Rotary sw of Servo Amp.
2. Condition of AC power.
3. Communication cable.
809d01 Recycleconveyorlledup
Recycle conveyor became Full. (Block1)
-----
809d02 Recycleconveyorlledup
Recycle conveyor became Full. (Block2)
-----
809e01 Automatic Teaching
PleaseskipitbecauseAutomaticmodicationTeachingisimpossibleinNozzle
position of Head1.
-----
809e02 Automatic Teaching
PleaseskipitbecauseAutomaticmodicationTeachingisimpossibleinNozzle
position of Head2.
-----
1109-006
4OM-1603
2-33
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
809f01 ConrmTraySafetyCover
There is no magazine. Magazine 1 (Lower).
-----
809f02 ConrmTraySafetyCover
Rack shutter of operator side is open. Magazine 1 (Lower)
-----
809f03 ConrmTraySafetyCover
Rack shutter of traverse side is open. Magazine 1 (Lower)
-----
809f04 ConrmTraySafetyCover
The Magazine is not set correctly. Magazine 1 (Lower)
Check lock lever of magazine.
-----
809f05 ConrmTraySafetyCover
There is no magazine. Magazine 2 (Upper).
-----
809f06 ConrmTraySafetyCover
Rack shutter of operator side is open. Magazine 2 (Upper)
-----
809f07 ConrmTraySafetyCover
Rack shutter of traverse side is open. Magazine 2 (Upper)
-----
809f08 ConrmTraySafetyCover
The Magazine is not set correctly. Magazine 2 (Upper)
Check lock lever of magazine.
-----
809f09 ConrmTraySafetyCover
Motor Error of Magazine(Lower) is detected.
-----
809f0a ConrmTraySafetyCover
Motor Error of Magazine(Upper) is detected.
-----
80a001 Recognition Error
Failed in the recognition of the part. Please retry pickup of the part.
-----
80a002 Recognition Error
Nozzle position teaching failure.
Check nozzle condition.
-----
80a101 Reading the Linear measure sensor Version
The operation for turning on is invalid.
Please do operation again after turning on completely.
-----
80b001 Automatic Teaching Error
Failed in the recognition. Carr it out again on the next time.
-----
