4OM-1603
3-149
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
604106 Teaching Placement-Height
Time-out of DD/NS-axis
-----
604107 Teaching Placement-Height
Error in calculating drive wave of HL-axis
-----
604108 Teaching Placement-Height
Error in calculating drive wave of NL-axis
-----
604109 Teaching Placement-Height
Time-out of starting HL/NL-axis movement
-----
60410a Teaching Placement-Height
Time-out of starting HL-axis movement
-----
60410b Teaching Placement-Height
Time-out of starting NL-axis movement
-----
60410c Teaching Placement-Height
Time-outofnishingHL/NL-axismovement
-----
60410d Teaching Placement-Height
Failed in measuring real time of linear measure sensor.
-----
60410e Teaching Placement-Height
ODD Noz is placed on Head, or error is detected during linear measure sensor.
-----
60410f Teaching Placement-Height
Flange of Nozzle is not detected within the predetermine range.(Not E/NR)
Please remeasure the height teach after teaching the head rotation on the angle
axis.
604110 Teaching Placement-Height
Flange of Nozzle is not detected within the predetermine range.(E/NR)
Please remeasure the height teach after teaching the head rotation on the angle
axis.
604111 Teaching Placement-Height
The height of Flange of Nozzle is not changed.(Nozzle pressed is not detected.)
-----
604112 Teaching Placement-Height
Program Error
-----
604113 Teaching Placement-Height
Offset is 1mm less than the set value.
-----
604114 Teaching Placement-Height
Offset is 1mm more than the set value.
-----
1109-006
4OM-1603
3-150
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
604115 Teaching Placement-Height
The value of Flowmeter is higher than 5.0V.
-----
604116 Teaching Placement-Height
The value of Flowmeter is lower than 4.7V.
-----
604117 Teaching Placement-Height
ThereisnomeasureddataofNoz1.ItisnecessarytomeasureNoz1rst.
-----
604118 Teaching Placement-Height
CannotmeasureitforXY-coordisnotdened.
-----
604119 Teaching Placement-Height
Error in Flowing Quantity
-----
604201 Chute(For adjustment when shipping up) Teaching Height
Error is detected before starting Detection on Linear Measure Sensor.(There is a
possibility that Linear measure sensor is broken, or Odd Noz is placed.)
-----
604202 Chute(For adjustment when shipping up) Teaching Height
Time-out of [OFF] signal of Linear measure sensor
-----
604203 Chute(For adjustment when shipping up) Teaching Height
Error in DD-axis
-----
604204 Chute(For adjustment when shipping up) Teaching Height
Error in NS-axis
-----
604205 Chute(For adjustment when shipping up) Teaching Height
Error in DD/NS-axis
-----
604206 Chute(For adjustment when shipping up) Teaching Height
Time-out of DD/NS-axis
-----
604207 Chute(For adjustment when shipping up) Teaching Height
Error in calculating drive wave of HL-axis
-----
604208 Chute(For adjustment when shipping up) Teaching Height
Error in calculating drive wave of NL-axis
-----
604209 Chute(For adjustment when shipping up) Teaching Height
Time-out of starting HL/NL-axis movement
-----
60420a Chute(For adjustment when shipping up) Teaching Height
Time-out of starting HL-axis movement
-----
1109-006
4OM-1603
3-151
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
60420b Chute(For adjustment when shipping up) Teaching Height
Time-out of starting NL-axis movement
-----
60420c Chute(For adjustment when shipping up) Teaching Height
Time-outofnishingHL/NL-axismovement
-----
60420d Chute(For adjustment when shipping up) Teaching Height
Failed in measuring real time of linear measure sensor.
-----
60420e Chute(For adjustment when shipping up) Teaching Height
Error in measuring Linear measure sensor
-----
60420f Chute(For adjustment when shipping up) Teaching Height
Flange of Nozzle is not detected within the predetermine range.(Not E/NR)
Please remeasure the height teach after teaching the head rotation on the angle
axis.
604210 Chute(For adjustment when shipping up) Teaching Height
Flange of Nozzle is not detected within the predetermine range.(E/NR)
Please remeasure the height teach after teaching the head rotation on the angle
axis.
604211 Chute(For adjustment when shipping up) Teaching Height
The height of Flange of Nozzle is not changed.(Nozzle pressed is not detected.)
-----
604212 Chute(For adjustment when shipping up) Teaching Height
Program Error
-----
604213 Chute(For adjustment when shipping up) Teaching Height
Offset is 1mm less than the set value.
-----
604214 Chute(For adjustment when shipping up) Teaching Height
Offset is 1mm more than the set value.
-----
604215 Chute(For adjustment when shipping up) Teaching Height
The value of Flowmeter is higher than 5.0V.
-----
604216 Chute(For adjustment when shipping up) Teaching Height
The value of Flowmeter is lower than 4.7V.
-----
604217 Chute(For adjustment when shipping up) Teaching Height
ThereisnomeasureddataofNoz1.ItisnecessarytomeasureNoz1rst.
-----
604218 Chute(For adjustment when shipping up) Teaching Height
CannotmeasureitforXY-coordisnotdened.
-----
604219 Chute(For adjustment when shipping up) Teaching Height
Error in Flowing Quantity
-----
